instructions carefully and familiarize yourself with the different parts.
please contact Atlantic Furniture at customerservice@atlanticfurniture.com or 1-800-955-3726
PARTS LIST
1
HEADBOARD PANEL
4 PCS
BOARDS
2
LEFT LEG
1 PC
3
RIGHT LEG
1 PC
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Attach the legs (2) and (3) to headboard panel boards (1),
using JCB M6 X 35mm (A).
Tighten with the Allen wrench (C).
A
A
FOR BED FRAME ASSEMBLY follow assembly instructions included with your bed frame.
If you purchased a wood headboard to attach to metal bed frame, please refer to page 2.
Before assembling your headboard, please read through these
ATTENTION! If you receive a damaged or defective item,
Instructions apply for bed sizes
A
JCB M6 X 35mm - 16 pcs
Spare - 1 pc
B
JCB M8 X 15mm ( 5/8") - 4 pcs
Assembly headboard to open bed frame
1
3
C
Allen wrench - 1pc
Spare - 1pc
A
2
READY
TO
ASSEMBLE
HARDWARE
HARDWARE FOR METAL BED FRAME
D
JCB M6 X 25mm (1") - 4 pcs
Spare - 1 pc
E
Flat washer - 4 pcs
Spare - 1 pc
F
Split washer - 4 pcs
Spare - 1 pc
Adult assembly
Adult assembly
A
JCB M6 X 35mm
Page 1 of 2
