Safety and warnings
Important: Elevated operating ambient
temperature: If installed in a closed environment,
make sure the operating ambient temperature is
compatible with the specified maximum ambient
temperature.
Note: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Technical specifications
Table 2: Technical specifications
Specification Description
Physical and power specifications
Ethernet ports 5 x 10/100/1000Base-T
Console port 1 x micro USB
USB ports Not supported
Indicators • 1 x fault LED
• 1 x Wi-Fi LED
• 1 x status LED
• 1 x cellular LED
Power • 12 V AC/DC power adapter, barrel
plug, center positive
• PoE: port 5, 15.4 W (802.3af class 3)
Temperature • Operating: 0°C to 40°C (32°F to
104°F)
• Storage: -45°C to 85°C (-49°F to
185°F)
Weight Approximately 600 g (1.3 lbs)
Dimensions Excluding Wi-Fi antennas and DIN rail
mount:
• Width: 210 mm (8.25 in.)
• Depth: 115 mm (4.5 in.)
• Height: 38 mm (1.5 in.)
Table 2: Technical specifications
Specification Description
Wireless LAN
Modes IEEE 802.11 a/b/g/n/ac
Modulation DSSS, OFDM, DBPSK, DQPSK, CCK, 16-
QAM, 64-QAM, 256-QAM
Frequency • 2.4 GHz ISM radio band
band
• 5 GHz U-NII-1, U-NII-2A, U-NII-2C, U-
NII-3 bands
Transmission • 802.11b: 1, 2, 5.5, 1 1 Mbps
rate
• 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
Mbps
• 802.11n: Up to 150 Mbps-single
• 802.11n: Up to 300 Mbps-2x2 MIMO
• 802.11ac: Up to 192.6 Mbps (20MHz
channel)
• 802.11ac: Up to 400 Mbps (40MHz
channel)
• 802.11ac: Up to 866.7 Mbps (80MHz
channel)
Transmit • 802.11a: 13 dBm ± 2 dBm @54 Mbps
power
• 802.11b: 17 dBm ± 2 dBm @11 Mbps
• 802.11g: 16 dBm ± 2 dBm @54 Mbps
• 802.11n: (2.4 GHz, 20 MHz, MCS7): 16
dBm ± 2 dBm
• 802.11n: (2.4 GHz, 40 MHz, MCS7): 14
dBm ± 2 dBm
• 802.11n: (5 GHz, 20 MHz, MCS7): 13
dBm ± 2 dBm
• 802.11n: (5 GHz, 40 MHz, MCS7): 12
dBm ± 2 dBm
• 802.11ac (2 0MHz, MCS8): 13 dBm ±
2 dBm
• 802.11ac (40 MHz, MCS9): 12 dBm ±
2 dBm
• 802.11ac (80 MHz, MCS9): 10dBm ±
2dBm
Note: Transmit power may be lim-
ited depending on regional SKU.
Supported • 2.4 GHz US, CA, JP, EU: 1-11
channels
• 2.4 GHz JP, EU only: 12, 13
• 5 GHz US, CA, JP, EU: 36, 38, 40, 42,
44, 46, 48, 52, 54, 56, 58, 60, 62, 64,
100, 102, 104, 106, 108, 110, 112,
116,132, 134, 136, 140
• 5 GHz US, JP, EU: 118, 120, 122, 124,
126, 128
• 5 GHz US, CA: 138, 149, 151, 153, 155,
157, 159, 161, 165,169, 173
Performance specifications
Throughput • Encrypted: 84 Mbps, 12k PPS
• Bypass: 165 Mbps, 16k PPS
