Network port.
2.
Serial Port - eSATAp
3.
USB Port
4.
High definition
multimedia interface.
Front I/O Panel
No.
1.
USB Port
2.
CW Port
3.
ECG Port
z.one pro Instructions
Name
Used for connecting router, ultrasound
workstation, server, etc.
Used for connecting storage device.
Used for connecting storage device.
Used for connecting TV, projector,
ultrasound workstation video capture
card, etc.
1
2
3
Name
Used for connecting storage device.
Used for connecting a pencil probe.
Connects to ECG leads, to directly obtain
the ECG signals of the patient.
Connects the signal output port of ECG
monitoring device.
1
2
3
4
Function
Function
10 |
P a g e
