the continuous capture.
To halt saving acquired images for the selected stage, press <Freeze> directly. The
time stops increasing.
Press <Freeze> again to continue.
To end the current acquisition, press <Store> on the control panel.
To select another continuous stage, press <Stage XXX> key.
Suspending is not allowed under continuous exam.
When acquisition is complete for each stage, the system advances to the next stage. If
the stage is non-continuous, the system displays the stage views. When image
acquisition is completed for all views and continuous stages, the system switches to
Select Mode.
6. To start or restart the timer, press <Stage Timer>/<Exam Timer> on the soft menu to turn it on.
The Stage time is displayed to the right side of each stage in the protocol list, while the
Exam time is displayed in the left side of the screen.
Each saved image will be marked with two times T1 and T2. T1 refers to the total time of
the whole acquisition, while T2 indicates the time the acquisition lasted for a certain stage.
7. To end the acquisition and review the acquired images, click [End Acquisition].
NOTE:
When the acquisition is ended, no additional stress echo image acquisition can be
performed for the same exam.
The following stages and controls are available while Stress Echo is active.
Soft Keys (OLED)
Stage
Available Softkey (OLED) Controls
Acquire
End acquisition
Suspend SE. If SE is
suspended, pressing
Protocol key or
programmable key
assigned to SE will re-
enter exam
Reference Image On/Off
End SE
Text On/Off
Playback Speed +/-
z.one pro Instructions
Available Onscreen Controls
Delete Unselected
Resting images
available for
selection
Acquisition pause
Exam timer on/off
Stage timer on/off
Mode
Stages
Views
Post images available for
selection
End Acquisition
93 |
