EC30 Series Elevator Door Controller
minutes until the elevator door controller is discharged completely before
conducting installation operations.

3.3.2 Wiring port description

No. Code
1 SW1
2 CN3
3 CN5
4 CN7
5 CN1
6 CN2
7 CN8
8 -

3.3.3 Drive circuit ports

Type
Drive main circuit input
(F7DEP-7.62-03P)
Drive main circuit output
(F7DEP-7.62-04P)
202407 (V1.0)
1
2
3
4
Port label
Power switch
L, N and PE
U, V, W and PE
+5V, GND, CS, CLK, DIN,
DOUT and +24V
COM, DI1, ...DI8
TA12, TB1, TC1, TB2, TC2,
TA34, TB3, TC3, TB4 and
TC4
USB
Display keys
Code
CN3-1
CN3-2
CN3-3
CN5-1
CN5-2
Port model
Rocker switch
F7DEP-7.62-03P
F7DEP-7.62-04P
F7D-3.81-07P
F7D-3.81-10P
F7D-3.81-10P
USB
-
Port
Name
label
L AC220V power input
N AC220V power input
PE Grounding terminal
Connect to U phase
U
of the motor
V Connect to V phase of
Installation guidelines
8
7
6
5
Function description
Power input
Power AC220V input
Motor
Encoder interface
Control input terminals
Control output terminal
External hand-held keypad
interface
Display key
operations/functions and
parameters.
Description
AC 1PH 220V input
Connect to 3PH
motor
11
