INSTRUCTIONS–PARTS LIST
Parts
INSTRUCTIONS
HYDRAULIC–OPERATED
Bulk Oil Transfer Packages
Model No. 244632, 1:1 Dynastar Wall Mount
1500 psi (10.5 MPa, 105 bar) Maximum Hydraulic Input Pressure
1500 psi (10.5 MPa, 105 bar) Maximum Fluid Outlet Pressure
Model No. 244633, 1/4:1 Dynastar Wall Mount
1500 psi (10.5 MPa, 105 bar) Maximum Hydraulic Input Pressure
375 psi (2.6 MPa, 26 bar) Maximum Fluid Outlet Pressure
Model No. 244634, 1:1 Powerstar Wall Mount
1500 psi (10.5 MPa, 105 bar) Maximum Hydraulic Input Pressure
1500 psi (10.5 MPa, 105 bar) Maximum Fluid Outlet Pressure
Model No. 244678, 1:1 Dynastar 55 Gal. Bung Mount
1500 psi (10.5 MPa, 105 bar) Maximum Hydraulic Input Pressure
1500 psi (10.5 MPa, 105 bar) Maximum Fluid Outlet Pressure
KEEP FOR REFERENCE.
See pump and motor manuals (supplied)
for important safety warnings and instal-
lation, operation, and service instructions.
Bulk Supply
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
ECOPYRIGHT 2001, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
First choice when
quality counts.t
TI1375A
309352
Rev. A
