Harbor breeze builder’s series ceiling fan

Advertisement

Harbor Breeze ® is a registered trademark
of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5
p.m., EST, Friday.
BUILDER'S SERIES
Purchase Date
1 1
ITEM #0373684
CEILING FAN
MODEL #40016
Español p. 18
8014 · 12/19/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40016 and is the answer not in the manual?

Questions and answers

Summary of Contents for Harbor Breeze 40016

  • Page 1 ITEM #0373684 BUILDER’S SERIES CEILING FAN Harbor Breeze ® is a registered trademark MODEL #40016 of LF, LLC. All Rights Reserved. Español p. 18 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Package Contents ......... . . 3 Hardware Contents.
  • Page 3: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Mounting Bracket Motor Assembly Motor Housing Blade Iron Blade Glass Shade Bulb...
  • Page 4: Hardware Contents

    HARDWARE CONTENTS (shown actual size) PART DESCRIPTION QUANTITY Blade Iron Screws 12 + 1 Extra Blade Washer 12 + 1 Extra Short Mounting Screw (preasssembled) Pull Chain Extension Wire Connector Blade Isolator Motor Screw 8 Preassembled + 1 Extra...
  • Page 5: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. 1. Before you begin installing the fan, disconnect the power by removing fuses or turning off circuit Breakers. CAUTION: Read all instructions and safety information before installing your new fan. Review the accompanying assembly diagrams.
  • Page 6: Preparation

    WARNING WARNING: To reduce the risk of fire or electric shock, do not use the fan with any solid state speed control device or control fan speed with a full range dimmer switch. WARNING: To reduce the risk of fire, electric shock, or personal injury, do not bend the blade arms when installing them, balancing the blades, or cleaning the fan.
  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS 1. Turn off circuit breakers and wall switch to the fan supply line leads. DANGER: Failure to disconnect power supply prior to installation may result in serious injury or death. 2. This fan can only be flushmounted to the ceiling; downrod mount and angle mount is not available for this fan.
  • Page 8 ASSEMBLY INSTRUCTIONS 4. Pass the 120-volt supply wires through the center hole in the mounting bracket (A). Install the mounting bracket (A) by raising it to a UL listed electrical box (not included) and securing with mounting screws and washers (not included). Note: It is very important that you use the proper hardware when installing the mounting bracket (A) as this will support the fan.
  • Page 9 ASSEMBLY INSTRUCTIONS There are 4 housing mounting screws preassembled on the periphery of the mounting bracket (A). Remove one pair of the screws that match the round holes of the motor housing (C) opposite each other, and loosen the remaining two screws. Mounting Screws 8.
  • Page 10: Wiring

    WIRING WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your house wire is larger than 12 gauges there is more than one house wire to connect to the two fan lead wires, consult an electrician for the proper size wire connectors to use.
  • Page 11 WIRING 1C. FAN AND LIGHT CONTROLLED BY TWO WALL SWITCHES: If you intend to control the fan and light with separate wall switches, connect BLACK wire from fan to BLACK wire from the independent wall switch for the fan. Connect BLUE wire from fan to the BLACK wire from the independent wall switch for the light.
  • Page 12: Final Installation

    FINAL INSTALLATION 1. Attach blade (E) to blade bracket (D) using the blade iron screws (AA) and blade washer (BB). Insert a blade iron screw (AA) into the blade bracket (D). Repeat for the two remaining blade iron screws (AA). Hardware Used Blade Iron Screw x 12...
  • Page 13: Light Kit Installation

    LIGHT KIT INSTALLATION 1. Install bulb (G). Note: Fan uses one 60-watt max. candelabra-base bulb. 2. Insert the glass shade (F) into the fixture. Tighten preassembled glass mounting screws manually until finger tight. Do not overtighten. Note: Loosen the thumbscrews before inserting the globe, then retighten securely.
  • Page 14: Operating Instructions

    OPERATING INSTRUCTIONS 1. The pull chain labeled FAN has four positions to control fan speed. One pull is HIGH, two is MEDIUM, three is LOW and four turns the fan OFF. 2. Use the fan reverse switch, located on the switch housing, to optimize your fan for seasonal performance.
  • Page 15: Care And Maintenance

    CARE AND MAINTENANCE At least twice each year, lower canopy to check down rod assembly, and then tighten all screws on fan. Clean motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean blades with a lint-free cloth. You may occasionally apply a light coat of furniture polish to wood blades for added protection.
  • Page 16: Limited Lifetime Warranty

    PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. Bulb(s) not installed correctly. 1. Re-install bulb(s). operated 2. Light kit wire plugs not 2. Make sure the male and female plugs in but lights connected properly. light kit fitter are connected properly. fail (if 3.
  • Page 17: Replacement Parts List

    REPLACEMENT PARTS LIST For replacement parts, call customer service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday. PART DESCRIPTION PART # Mounting Bracket 4L0000000024 Motor Housing 4L0000000025 Blade Iron 4L0000000026 Blade 4L0000000027...
