Harbor Breeze® is a registered trademark
of LF, LLC. All Rights Reserved.
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also
contact us at partsplus@lowes.com or visit www.lowespartsplus.com.
RR20391
MARINA COVE II
1
ITEM
#0275422
2889554
MODEL #JP18BZ3
JP18TI3
Español p. 14
ATTACH YOUR RECEIPT HERE
4009218
Advertisement
Table of Contents
Related Manuals for Harbor Breeze MARINA COVE II
Summary of Contents for Harbor Breeze MARINA COVE II
- Page 1 ITEM #0275422 2889554 MARINA COVE II MODEL #JP18BZ3 JP18TI3 Harbor Breeze® is a registered trademark of LF, LLC. All Rights Reserved. Español p. 14 ATTACH YOUR RECEIPT HERE Purchase Date 4009218 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-251-1003, 8 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information ....................... Package Contents .......................4 Hardware Contents ......................Preparation .......................... Assembly Instructions ......................6 Operating Instructions ...................... Care and Maintenance ......................12 Troubleshooting .........................12 Limited Lifetime Warranty ....................13 SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS • Do not discard fan carton or foam inserts. Should this fan need to be returned to the factory for repairs, it must be shipped in its original packaging to ensure proper protection against damage that might exceed the initial cause for return. - Page 3 SAFETY INFORMATION WARNING To reduce the risk of fire, electrical shock or personal injury, use the metal wall mounting bracket provided with the fan. Secure the wall mounting bracket directly to the building structure on a wood stud or wood post or beam. Do not install directly to drywall. The wood stud or wood post and its support must be able to support the moving weight of the fan (at least 50 lbs.).
-
Page 4: Package Contents
PACKAGE CONTENTS PART DESCRIPTION PART DESCRIPTION QUANTITY QUANTITY Fan Assembly Front Cage Screw (preassembled) Wall Mounting Bracket Pull Chain Front Cage (preassembled) Blade Assembly Power Cord Back Cage (preassembled) Blade Assembly Nut Decorative Nut (preassembled) (preassembled) Back Cage Screw (preassembled) Fuse (Included) IMPORTANT REMINDER: You must use the parts provided with this fan for proper installation... -
Page 5: Hardware Contents
Wood Screw Qty. 4 + 1 extra PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Turn off circuit breakers and wall switch to the fan supply line leads. DANGER: Failure to disconnect power supply prior to installation may result in serious injury or death. This fan assembly (A) can only be mounted on an indoor wall or on an enclosed porch or enclosed patio wall. - Page 7 ASSEMBLY INSTRUCTIONS 4. Use 3/32-in. drill bit (not included) to drill pilot holes at marked locations. Then, install wall Stud mounting bracket (B) to mounting surface with wood screws (AA). WARNING: It is very important that you use the proper hardware when installing the wall mounting bracket (B) as this will support the fan assembly (A).
- Page 8 ASSEMBLY INSTRUCTIONS Remove the three back cage screws (G) from the outer edge of the motor on fan assembly (A) Align the three holes on the outer edge of the motor on fan assembly (A) with the three holes in the center of the back cage (E). Install the three back cage screws (G) previously removed into each of the three holes in the center of the back cage (E) to...
- Page 9 ASSEMBLY INSTRUCTIONS Turn blade assembly nut (F) clockwise to remove from shaft on fan motor. Partially loosen preassembled set screw on blade assembly (D). Place blade assembly (D) over motor shaft and lock pin, making sure to align gap on the Shaft Lock blade assembly (D) with lock pin on motor.
- Page 10 ASSEMBLY INSTRUCTIONS Remove all six front cage screws (H) from edge of back cage (E). Hook Place hook at top of front cage (C) over edge at top of back cage (E). NOTE: Make sure hook engages and all front and back cage holes match up; this will allow the front cage (C) and the back cage (E) to hang together while you re-insert the front cage screws (H) into the the front and back cage holes.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS It is recommended you test the fan before finalizing installation. Restore power from circuit box. Test fan speeds with preassembled wall control. Start at the Off position (no blade movement). One turn of the dial will set the fan to HIGH (H). Two turns will set the fan to MEDIUM (M). -
Page 12: Care And Maintenance
CARE AND MAINTENANCE At least twice each year tighten all screws on fan assembly and front cage. Clean fan assembly with only a soft brush or lint-free cloth to avoid scratching the finish. IMPORTANT: Shut off main power supply before beginning any maintenance. The three-prong plug is installed with a fuse (L) that is a vital safety device. -
Page 13: Limited Lifetime Warranty
LIMITED LIFETIME WARRANTY The distributor warrants this fan to be free from defects in workmanship and materials present at time of shipment from the factory for Lifetime limited from the date of purchase. This warranty applies only to the original purchaser. The distributor agrees to correct any defect at no charge or, at our option, replace the ceiling fan with a comparable or superior model.
