Argo GREENSTYLE DUAL 9000 UI Service Manual

Multisplit air conditioners-r32 inverter, indoor/outdoor unit
Hide thumbs Also See for GREENSTYLE DUAL 9000 UI:
Table of Contents

Advertisement

Quick Links

Download this manual
GREENSTYLE
MULTISPLIT AIR
CONDITIONERS – R32
SERVICE MANUAL
INDOOR UNIT
OUTDOOR UNIT
GREENSTYLE DUAL 9000 UI
GREENSTYLE DUAL 14000 UE
GREENSTYLE DUAL 12000 UI
Please read this manual carefully before installing and using the air conditioner, and retain
for future reference.
V 04/21
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GREENSTYLE DUAL 9000 UI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo GREENSTYLE DUAL 9000 UI

Summary of Contents for Argo GREENSTYLE DUAL 9000 UI

  • Page 1 MULTISPLIT AIR CONDITIONERS – R32 SERVICE MANUAL INDOOR UNIT OUTDOOR UNIT GREENSTYLE DUAL 9000 UI GREENSTYLE DUAL 14000 UE GREENSTYLE DUAL 12000 UI Please read this manual carefully before installing and using the air conditioner, and retain for future reference.

  • Page 2: Table Of Contents

    CONTENTS CONTENTS ........................2 Part1 General Information ..................4 1. Unit appearance .......................4 2. Accessories Included ......................5 Part2 Features ........................ 6 1. Outdoor Units ........................6 2. Wall Mounted ........................8 3. WIFI Control ........................9 Part3 Piping System ....................10 1. 14K ..........................10 Part4 Dimension......................
  • Page 3 2. Capacity amendment of different ambient temperature ..........14 3. Long piping length ......................16 4. Capacity amendment of different piping length .............17 5. Equivalent Pipe length conversion .................18 Part7 Controller ......................19 1. Controller ........................19 2. Wifi Module ........................21 Part8 Explosive View ....................24 1.

  • Page 4: Part1 General Information

    Part 1 General Information 1. Unit appearance 1.1 Wall - Mounted Picture Capacity Range / Mode 09 K Btu/h GREENSTYLE 9000 UI 12 K Btu/h GREENSTYLE 12000 UI 1.2 Outdoor Unit 1 drive 2 - 14k Capacity (Btu) GREESTYLE DUAL 14000 Picture...

  • Page 5: Accessories Included

    2. Accessories Included 2.1 Outdoor Units QUANTITY N° Name Installer manual Drainage connector Pipe adaptor copper nuts 2.2 Indoor Units QUANTITY N° Name Wall Mounted User manual Remote control Batteries for Remote Control Touch screen wired Control Panel screw Drainage tube Pipe adaptor Thermal insulation pipe...

  • Page 6: Part2 Features

    Part 2 Features 1. Outdoor Units Environmental-friendly Refrigerant R32 The GWP value of R32 is smaller, so the effect on the greenhouse effect is smaller. The ODP value of R32 is 0, so it’s no harm to our planet’s ozone layer. High Efficiency Equipped with high efficiency DC Inverter compressor, adjustable fan motor and advanced 180°...
  • Page 7 Energy Saving Cutting-edge DC inverter of sine wave control and active PFC technology realize low noise and economical operation. Space-Saving Installation Up to 5 indoor units can be connected to a single outdoor unit, which reduces the number of outdoor units required so as to save installation space. Besides, each indoor unit can controlled individually and they even needn’t to be installed at the same time.

  • Page 8: Wall Mounted

    2 Wall Mounted Wall Mounted type A/C is installed by the wall, compared with Floor & Standing type A/C, it has following advantages: Wall mounting installation combining with the decoration, makes the room more elegant; Flexible installation in anywhere in the wall and swing blowing, makes you feel more comfortable.

  • Page 9: Wifi Control

    3 WIFI Control The optional WiFi modular makes it possible to monitor and control your AC while on the road through APP on your mobile phone or pad.

  • Page 10: Part3 Piping System

    Part 3 Piping System OUTDOOR INDOOR FILTER SERVICE VALVE Tdef TLq-A CONDENSER FILTER PMVA TLq-B FILTER PMVB EVAP B EVAP A SOUND REDUCER Tas-B LPS1 Tas-A...

  • Page 11: Part4 Dimension

    Part 4 Dimension 1. Indoor Unit Physical Dimension GREENSTYLE 9000 UI GREENSTYLE 12000 UI Length Height Width 2. Outdoor Unit (822) (545)

  • Page 12: Part5 Electrical Principle Diagram

    Part 5 Electrical Principle Diagram 1 Wall Mounted (09K,12K) Controlling board 0693 1132600700...

  • Page 13: Outdoor Unit

    Outdoor Unit Temperature Sensor Electronic Expansion Valve Notes: 4-Way Dotted line part in the (T1) (T2) (T3) (T4) (T5) (T11) (T12) (T13)(T14) (T31) (T32) Valve frame may not be used. T151 T201 T202 T203 T501 T201 T202 T203 T204 T201 T202 Metal PMV3 Tao Ts Tdef Tcm Td1...

  • Page 14: Part6 Capacity Amendment

    Part 6 Capacity Amendment 1. Operation range Cooling capacity (KBtu/h) Power supply 220-240V~/50Hz Voltage 187~242V Cooling -10~52℃ Ambient temperature Heating -15~24℃ 2. Capacity amendment of different ambient temperature 2.1 Amendment coefficient of Cooling capacity under different indoor/outdoor DB/WB temperature K1 Outdoor air inlet DB temperature℃...
  • Page 15 2.2 Amendment coefficient of Heating capacity under different indoor/outdoor DB/WB temperature K2 Outdoor air inlet DB temperature℃ temp.℃ 0.93 0.97 1.06 1.08 1.14 1.25 0.87 0.93 0.97 1.06 1.08 1.14 0.87 0.93 0.97 1.06 1.08 1.14 0.71 0.87 0.93 0.97 1.06 1.08 0.62...

  • Page 16: Long Piping Length

    3. Long piping length Cooling capacity (KBtu/h) Φ Liquid pipe 6.35*2 Connection Pipe(mm) Φ Gas pipe 9.52*2 Max. length for all rooms (m) Max. length for one IU (m) Max. height difference between IU and OU (m) Max. height difference between IUs (m) Caution: 1.

  • Page 17: Capacity Amendment Of Different Piping Length

    4. Capacity amendment of different piping length 4.1 Amendment coefficients of heating and cooling capacity under different height drop Different Cooling Capacity modified coefficients at different height: Equivalent pipe Note: H = Height of Outdoor Unit － Height of Indoor Unit Different Heating Capacity modified coefficients at different height: Equivalent pipe Note:...

  • Page 18: Equivalent Pipe Length Conversion

    5. Equivalent Pipe length conversion Equivalent pipe length means converting pipe elbow to straight pipe length after considerate the pressure loss. Bend and Oil Loop Conversion tablet Bend（m） Type Oil Loop(m) Pipe Dia.(mm) 6.35 0.10 9.52 0.18 12.70 0.20 15.88 0.25 19.05 0.35...

  • Page 19: Part7 Controller

    Part 7 Controller Controller POWER button: Switch the unit ON/OFF. MODE button: Select mode , push the button one time, then the operation modes will change in turn as Auto-Cooling-Dehumidify-Heating TEMP + button and TEMP - button: Temperature adjustment range: 16~32 FAN button: Change the fan speed will change in turn as: Low-Medium-High-Auto SWING button: Press this button for the first time when operation, it will start the swing function.
  • Page 20 12-hour clock including “A.M.” and “P.M.” time; press the button again to complete the setting. The “OFF” setting is the same methods. Remark: When setting functions such as mode, temperature, air port and air velocity, display screen displays all presetting parameters and remains constant; after reaching presetting time, air conditioner will automatically start as per presetting state.

  • Page 21: Wifi Module

    2. Wifi Module WiFi Module Configuration ① APP Download Mobile terminal scan the following dimensional code to download APP, or search “AC Freedom” in APPSTORE and Google store ② Light Commercial WIFI Module Installation Connect the WIFI module communication wire to WIFI interfaces of main PCB, as shown below: The WIFI module should be placed in the return air or some other place in WIFI area.
  • Page 22 Note:If the configuration fails or you change the password of wireless router, you need to reset the WIFI module to reconnect: Turn on the power of the module, then repeat the steps above for APP configuration. AC management ① Modify AC name and locking function ②...
  • Page 23 Technical Parameters  Working temperature：0~50℃；  Working environment humidity：20~90%RH；  Dimensions：78 X 52 X 15.5  Configuration cable wire length：1500mm...

  • Page 24: Part8 Explosive View

    Part 9 Explosive View Wall Mounted 09K, 12K...
  • Page 25 Material code Part name 11220502004342 Decro panel 11320135000018 Air louver（Horizontal） 11220508000139 Filter 11320096000104 Screw cover 11320076000084 Medium frame wiring cover 11320002000305 Medium frame 11320085000094 Guide vane linkage 11320017000125 Left-right swing blade 11320127000007 Step motor bracket 11320091000014 Crank link 11320085000081 Guide vane linkage B 11320062000028 Bearing fixing bracket 11224003000649...

  • Page 26: Part9 Pcb Instruction

    Part 10 PCB Instruction Outdoor Unit PCB 14K,18K Main PCB and Driver modular...
  • Page 27 Drive Modular Board...

  • Page 28: Part10 Trouble Shooting

    Part 11 Trouble Shooting WM: wall mounted unit 1. Fault code list 1.1 Temp. sensor fault NO.8) Code display in IDU Fault code description Possible reason Damage of the room temperature sensor on the indoor unit Fault with the room Poor contact of the room temperature sensor temperature sensor on on the indoor unit...
  • Page 29 Code display in IDU Fault code description Possible reason Damage of the Environmental temperature sensor on the outdoor unit Fault with the Poor contact of the Environmental environmental temperature temperature sensor on the outdoor unit sensor on the outdoor unit Damage of wiring of the Environmental temperature sensor on the outdoor unit Damage of the main PCB on the outdoor unit...
  • Page 30 Damage of the driver PCB on the outdoor Communication error between unit the driver PCB and main PCB of Damage of the main PCB on the outdoor the outdoor unit unit poor wiring 1.3 IDU fault NO.3) Code display in IDU Fault code description Possible reason Float switch disconnected or poor wiring...
  • Page 31 1.5 ODU components fault NO.12) Code display in IDU Fault code description Possible reason High pressure Switch System dirty blocking Protection Damage of High Voltage Pressure Switch Lack of the refrigerant Low pressure switch Stop valve unopened protection damage of low press switch Damage of four-way valve Fault of four-way valve Damage to coil of four-way valve...

  • Page 32: Failure Analysis

    2. Failure analysis 2.1【E5】Communication failure between indoor and outdoor unit...
  • Page 33 Outdoor protection (phase sequence)
  • Page 34 2.2【P2】high pressure protection Cooling high pressure protection...
  • Page 35 Heating high pressure protection...
  • Page 36 2.3【H6】low pressure protection Cooling low pressure protection Heating low pressure protection...
  • Page 38 2.4【P5】High exhaust temperature protection Cooling exhaust temperature protection...
  • Page 39 Heating exhaust temperature protection...
  • Page 40 2.5【H8】four way valve failure protection...
  • Page 41 2.6 Sensor failure protection...
  • Page 42 REGULATION (EU) No. 517/2014 - F-GAS The unit contains R32, a fluorinated greenhouse gas with global warming potential (GWP) = 675. Do not release R32 into the atmosphere. GREENSTYLE DUAL 14000 UE - Kg. 1,07 = 0,722 Tonn CO equiv. www.argoclima.com...

This manual is also suitable for:

Greenstyle dual 12000 uiGreenstyle dual 14000 ue
