GREENSTYLE
MULTISPLIT AIR
CONDITIONERS – R32
USER MANUAL and INSTALLATION GUIDE
INDOOR UNIT
OUTDOOR UNIT
GREENSTYLE DUAL 9000 UI
GREENSTYLE DUAL 14000 UE
GREENSTYLE DUAL 12000 UI
Please read this manual carefully before installing and using the air conditioner, and retain for future reference.
V 11/20
38

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GREENSTYLE DUAL 14000 UE and is the answer not in the manual?

Questions and answers

Related Manuals for Argo GREENSTYLE DUAL 14000 UE

Summary of Contents for Argo GREENSTYLE DUAL 14000 UE

  • Page 1 USER MANUAL and INSTALLATION GUIDE INDOOR UNIT OUTDOOR UNIT GREENSTYLE DUAL 9000 UI GREENSTYLE DUAL 14000 UE GREENSTYLE DUAL 12000 UI Please read this manual carefully before installing and using the air conditioner, and retain for future reference. V 11/20...

  • Page 2: Table Of Contents

    INDEX General warnings………………………………………………………….……..…..40 Safety precautions……………………………………………………..………..…...41 Notices for usage…………………………………………………………………..…43 Description of parts………………………………………………….………..…..45 Remote controller Guide…………………..……………………………………...…46 Wifi Guide…………………………………………………………………………..51 Clean and care…………………………………………………………….………….55 Troubleshooting……………………………………………………..………..….……57 Notices for installation..………………………………………………………...…..59 Indoor unit installation……………………………………………………………..64 Outdoor unit installation………………………………………………..…..……..67 Maintenance notes………………………………………………...……………...….71...
  • Page 3 Appliance filled with flammable gas R32. Before using the appliance, read the owner’s manual. Before installing the appliance, read the installation manual. Before repairing the appliance, read the service manual. The Refrigerant • To realize the function of the air conditioner unit, a special refrigerant circulates in the system. The refrigerant is the fluoride R32 = GWP (Global warming potential).

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 5 Incorrect repairs may cause fire or explosion. Contact a qualified service technician for all service requirement. Don't install air conditioner in a place where there is flammable gas or liquid. The distance between them should above 1m. It may cause fire even explosion. Don't use air conditioner in Don't put hands or any objects into lightning storm weather.

  • Page 6: Notices For Usage

    Don’t open the windows and doors for long time when the air conditioner is running. Don’t stand on the top of the outdoor unit or place heavy things Don’t use the air conditioner for on it. This cloud cause personal other purposes, such as drying injuries or damage the unit.
  • Page 7 NOTES FOR HEATING FUNCTION When the heating function is started, the indoor unit fan will not work immediately to avoid the introduction of • insufficiently hot air into the environment. When the outdoor temperature is very low and the humidity is high, ice may form on the heat exchanger of the outdoor •...

  • Page 8: Description Of Parts

    DESCRIPTION OF PARTS INDOOR UNIT Emergency button OUTDOOR UNIT...

  • Page 9: Remote Controller Guide

    Note: All the illustrations in this manual are for explanation purpose only. Your air conditioner may be slightly different. The actual shape shall prevail. They are subject to change without notice for future improuvement. REMOTE CONTROL USER GUIDE GENERAL WARNINGS 1.
  • Page 10 5. lf the remote controller does not work normally, remove the batteries far 30 seconds before reinstall them. lf that doesn't work, replace the batteries. 6. When replacing the batteries, do not mix the new batteries with old ones or mix batteries of different types, which could cause failure of the remote controller.
  • Page 11 1. ON/OFF button With this button you can turn the unit on or off. This button can also be used to reset the timer and the SLEEP function. 2. °C/ °F button Press this button to select the temperature unit of measurement, the selectable units are Fahrenheit (° F) or Celsius (° C) which is the default unit.
  • Page 12 5. iFEEL button Pressing this button activates the IFeel function. The LCD screen shows the room temperature and when the function is canceled it shows the set temperature. This function is not active in AUTO and FAN mode. 6. TIMER button When the air conditioner is on, press this button to deactivate the TIMER function, or when it is off to activate it.
  • Page 13 Note: HEAT mode is not available for cool only units. 11. SLEEP button By pressing the SLEEP button, the indoor unit light flashes. After setting the Sleep mode, in the cooling function, the temperature will increase by 1 ° C in one hour, then it will automatically increase by 1 °...

  • Page 14: Wifi Guide

    If you press this button in COOL mode, the unit will activate the ECO mode which has the lowest electricity consumption and that is automatically deactivated after 8h. If you change the mode or turn off the remote control, the function ECO will be automatically canceled.
  • Page 15 INTRODUCTION The AC system is equipped with remote control technology, with the WI-FI module inside the machine connected to the display panel and the command to run the AC transmitted. The AC system is in constant connection with a wireless router or access point attached to the Internet.
  • Page 16 Fig.3 RESET AC WI-FI MODULE For first time configuration or after changing the connected wireless router is, the WI-FI module inside the air conditioner needs to be reset, following the indications here below: When AC is running, press “HEALTH” button 8 times, reset successfully after twice “beep” sounds. (see Fig.4) Fig.4 Note: If the device is not connected successfully, please reset the air conditioner Wi-Fi in the same way.
  • Page 17 SMARTPHONE, PAD OR OTHER MOBILES TERMINALS CONNECT TO WIFI OR HOTSPOT Activate the WI-FI function of the mobile device and connect it to a wireless router or an access point Note: A wireless router is required for the WI-FI function to work. CONFIGURATION OF DEVICES After the control software is downloaded and installed on the mobile terminal, configure the AC devices according to the following figure:...
  • Page 18  To lock a device, simply touch the “Locking Device” icon. Once a device is locked, other users won't be able to search for it, thus preventing it from hostile control. After the configurations of the AC device names, icons and locking status are complete, touching “Save”...

  • Page 19: Clean And Care

    6. Please check whether the Wi-Fi password input is correct when APP configuration: you can check show password to confirm when input the WI-FI password. CLEAN AND CARE Before the cleaning of the air conditioner, it must be shut down and the electricity must be cut off for more than 5 •...
  • Page 20 Clean the air filter Use a vacuum cleaner or water to rinse the filter, and if the filter is very dirty (for example, with greasy dirt), clean it with warm water (below 45°C) with mild detergent, and then put the filter in the shade to dry in the air. Mount the air filter Reinstall the dried filter in reverse order of removal, then cover and lock the panel.

  • Page 21: Troubleshooting

    TROUBLESHOOTING Do not repair the air conditioner by yourself as wrong maintenance may cause electric shock or fire or explode, please contact the authorized service center and let the professionals conduct the maintenance, and checking the following items prior to contacting for maintenance can save your time and money. PHENOMENON TROUBLESHOOTING •...
  • Page 22 A slight "click" sound • Due to temperature changes, panel and other parts will swell, causing the sound of friction. → This is normal, not a fault. is heard at the of start-up or shut-down • The sound of fan or compressor relay switched on or off. When the defrosting is started or stop running, it will create sound.→...

  • Page 23: Notices For Installation

    NOTICES FOR INSTALLATION Safety operation of flammable refrigerant Qualification requirement for installation and maintenance All workers who engage with the refrigeration system should bear the valid certification awarded by the • authoritative organization, and the qualification recognized by the industry for dealing with the refrigeration system.
  • Page 24 Use refrigerant filling appliances specialized for R32. Make sure that different kinds of refrigerant don’t • contaminate one another. The refrigerant tank should be kept upright when filling with the refrigerant. • Stick the label on the system after filling is finished. •...
  • Page 25 REQUIREMENTS FOR INSTALLATION Avoid places of inflammable or explosive gas leakage or where there are strongly aggressive gases. • Avoid places subject to strong artificial electric/magnetic fields. • Avoid places subject to noise and resonance. • Avoid severe natural conditions (e.g. heavy lampblack, strong sandy wind, direct sunshine or high temperature heat •...
  • Page 26 Minimum Cross-Sectional Area of Power cable and interconnection cord. • The size of the interconnection cord, power cable, fuse, and switch needed is determined by the maximum current • of the unit. The maximum current is indicated on the nameplate located on the side panel of the unit. Refer to this nameplate to choose the right cable, fuse, or switch.
  • Page 27 Disconnect the power supply before carrying out any work on the electrical circuit or carrying out any safety work. For models with a plug, make sure the plug is easily accessible after installation. Do not connect the power before installation is complete. Do not use the appliance if the power cable or plug are damaged.

  • Page 28: Indoor Unit Installation

    The connection method of the air conditioner and the power cable and the interconnection method of each • independent element shall be subject to the wiring diagram affixed to the machine. The model and rating value of the fuse shall be subject to the silkscreen on corresponding controller or fuse sleeve. •...
  • Page 29 Depending on the position of the unit, the piping may be routed sideway from the left or the right (Fig 1), or vertically from the back (Fig 2) (depending on the pipe length of the indoor unit). DRAIN PIPE CONNECTION 1.
  • Page 30 FIXING THE INDOOR UNIT 1. Hang the indoor unit on the peg board, and move the unit from left to right to ensure that the hook is properly positioned in the peg board. 2. Push toward the lower left side and the upper right side of the unit toward the peg board, until the hook is embedded in the slot and makes a "click"...
  • Page 31 INSTALLATION FOR OUTDOOR UNIT DIMENSION DRAWING OF OUTDOOR UNIT INSTALLATION REFRIGERANT CONNECTIONS Use equipment and connecting pipes suitable for R32 refrigerator. MODEL Standard refrigerant charge piping length Maximum length of pipes with additional charge Minimum/Maximum length piping per unit 5/25 Additional charge g/m Maximum height difference between indoor units...
  • Page 32 Maximum height difference between indoor and outdoor unit Always write the additional refrigerant charge on the data label affixed to the unit outside. INSTALL THE CONNECTION PIPE Connect the Outdoor Unit with Connecting Pipe: Aim the counter-bore of the connecting pipe at the stop valve, and tighten the Taper nut with fingers. Then tighten the Taper nut with a torque wrench.
  • Page 33 Wiring diagrams Indoor unit Controlling board 0693 1132600700 Outdoor unit Ele c tro n ic Exp a n sio n Va lve Te m p e ra tu re Se n so r No te s: 4-Wa y Do tte d lin e p a rt in th e (T1) (T2) (T3) (T4) (T5) (T11) (T12) (T13) (T14) (T31) (T32)
  • Page 34 Connection between outdoor unit and indoor unit. NOTE: The diagram are for reference only. Please refer to the detailed wiring diagram adhered on the unit which you purchased. VACUUMING ★Exclusive R32 refrigerant pump must be used in making R32 refrigerant vacuum. Before working on the air conditioner, remove the cover of the stop valve (gas and liquid valves) and be sure to retighten it afterward (to prevent the potential air leakage)

  • Page 35: Maintenance Notes

    CHECK AFTER INSTALLATION ★ Electrical Safety Check 1. If the supply voltage is as required. 2. If there is any faulty or miss connection in each of the power, signal and grounding wires. 3. If the grounding wire of the air conditioner is securely grounded. ★...
  • Page 36 APPENDICES Piping configuration Connecting pipe diameter Additional refrigerant Liquid pipe (mm) Gas pipe (mm) (g/m) 6.35 9.52 Procedure for extending the piping N.B.: Improper extension of piping is the main cause of refrigerant leaks. Proceed as shown below: 1. Cut the pipe 5.
  • Page 37 REGULATION (EU) No. 517/2014 - F-GAS The unit contains R32, a fluorinated greenhouse gas with global warming potential (GWP) = 675. Do not release R32 into the atmosphere. GREENSTYLE DUAL 14000 UE - Kg. 1,07 = 0,722 Tonn CO equiv. www.argoclima.com...
