- Page 1 AirLive ONU-10XG(S)-AX304P-2.5G Quick Installation Guide V1.0...
- Page 2 AirLive ONU-10XG(S)-AX304P-2.5G QIG_V1.0 1. Indicator and Interface Description 1.1 Product Picture Figure 1. ONU-10XG(S)-AX304P-2.5G 1.2 Application Chart Figure 2. Application Chart (when using XG model the speed will be 10G DL / 2.5G UL) 1.3 Panel Lights Figure 3. Panel Lights...
- Page 3 AirLive ONU-10XG(S)-AX304P-2.5G QIG_V1.0 Mark Status Description Green: Device is registered to PON system. Orange: Device is powered up. REGISTRAT Power off or device is not registered to PON ION/OPTIC PON/LOS system. AL SIGNAL Green: Device is registering. Blink Red: Device does not receive optical signal.
- Page 4 AirLive ONU-10XG(S)-AX304P-2.5G QIG_V1.0 Press down WPS pair button to begin pairing. The Blue LAN1 is a 2.5GbE port and the yellow LAN2-4 is 1GE port. LAN1-4 Connect to PC or other devices with Ethernet port by Cat5/Cat5E cable, RJ-45 connector.
