AirLive
ONU-10XG(S)-AX304P-2.5G
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONU-10XG-AX304P-2.5G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AirLive ONU-10XG-AX304P-2.5G

Summary of Contents for AirLive ONU-10XG-AX304P-2.5G

  • Page 1 AirLive ONU-10XG(S)-AX304P-2.5G USER MANUAL...

  • Page 2: Table Of Contents

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Contents Chapter 1 Product Introduction ..................1 1.1 Product Description ......................1 1.2 Special features ....................... 2 1.3 Technical parameters ...................... 2 1.4 Application chart ......................3 1.5 Panel description ......................3 Chapter 2 Quick Installation ....................6 2.1 Standard Packing Contents ....................
  • Page 3 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.4 Security .......................... 41 3.4.1 URL Filtering ......................41 3.4.2 Firewall ........................41 3.4.3 Login Privilege ....................... 42 3.4.4 MAC Filtering ......................42 3.4.5 IP/Port Filtering ...................... 43 3.5 Application ........................46 3.5.1 VoIP Basic Settings ....................46 3.5.2 VoIP Advance Settings ...................
  • Page 4 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 4.4.1 Requirement ......................77 4.4.2 Steps ........................77 4.5 Internet, IPTV and VOIP service mixed ................82 4.5.1 Requirement ......................82 4.5.2 Steps ........................83 4.6 WLAN service ......................... 87 4.6.1 Requirement ......................88 4.6.2 Steps ........................88 4.7 Update image ........................

  • Page 5: Chapter 1 Product Introduction

    Chapter 1 Product Introduction 1.1 Product Description The 10G PON ONU-10XG(S)-AX304P-2.5G developed by AirLive comes in two models a XG-PON and XGS-PON, providing multiple rate Ethernet ports of 2.5GE/GE. It enables fast and stable networking for multiple devices, ensuring a seamless user experience within homes and effortlessly meeting the demands of 4K/8K, VR, and other services.

  • Page 6: Special Features

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 1.2 Special features ⚫ Plug and play, integrated auto detecting, auto configuration, and auto firmware upgrade technology. ⚫ Integrated TR069 remote configuration and maintenance function. ⚫ Support rich VLAN, DHCP Server/Relay and IGMP/MLD snooping multicast feature.

  • Page 7: Application Chart

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 1.4 Application chart Figure 1-4-1: Application chart, when using XG-Pon it will be 10G DL/2.5GUL 1.5 Panel description Interface panel Figure 1-5-1: Interface panel Name Function DC 12V Connect with power adapter. DC 12V, 2A. Connect to OLT by SC type fiber connector, single mode optical fiber cable.
  • Page 8 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Press RST 6 seconds for reboot, greater than 6 seconds for restoring user default configuration, greater than 12 seconds for restoring factory configuration as default. The blue LAN1 is a 2.5GE port and the yellow LAN2-4 are 1GE ports.
  • Page 9 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Device is power off or not registered to the soft-switch. PHONE Device has registered to the soft-switch. Flash The port is working. USB device is connected, but without ongoing data transmission. Device is powered off or USB device is not connected.

  • Page 10: Chapter 2 Quick Installation

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Chapter 2 Quick Installation 2.1 Standard Packing Contents When you receive our products, please check carefully to make sure that our products do not have some defects. If something is wrong after shipping, please contact carrier;...

  • Page 11: Set Up Connection

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 4. Check all signal levels and services on all the ONU communication ports. Unit Installation Adjustment Installing the ONU on a horizontal surface (Bench top) Put the ONU on a clean, flat, sturdy bench top. You must keep the clearance for all sides of the unit to more than 10cm for heat dissipation.

  • Page 12: Chapter 3 Configuration

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Chapter 3 Configuration After finishing the basic connection configuration, you can use its basic function. In order to satisfy individuation service requirements, this chapter provides you parameter modification and individuation configuration description. 3.1 Login The device is configured by the web interface. The following steps will enable you to login: 1、Conform “2.2 Quick Installation”...

  • Page 13: Status

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.2 Status This part shows the main information of the product. 3.2.1 Device Info This page shows the device basic information, such as device model, device SN, hardware version, and firmware version , PON S/N, CPU usage, memory usage and quick guide.
  • Page 14 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.2.2.1 IPv4 Connection Info This page shows IPv4 WAN connection information that you have configured. Figure 3-2-3: IPv4 WAN Information 3.2.2.2 IPv6 Connection Info This page shows IPv6 WAN connection information that you have configured. Figure 3-2-4: IPv6 WAN Information 3.2.2.3 VoIP Information...

  • Page 15: Pon Info

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.2.2.4 TR069 Status This page shows the request status and configuration status of TR069 connection. Figure 3-2-6: TR069 connection Status 3.2.3 PON Info This page shows the PON information, including connection information, FEC information, temperature, voltage, current, optical power, and statistics of the packet on send or receive direction.
  • Page 16 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-2-8: Connection Info 3.2.3.2 Laser Device Info This page shows the laser device information, including temperature, voltage, current, optical power. Figure 3-2-9: Laser Device Info...

  • Page 17: User Info

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.2.3.3 Link Performance Info This page shows statistics of the packet on send or receive direction. Figure 3-2-10: Link Performance Info 3.2.4 User Info This page shows the user information for LAN, including LAN, WLAN IP, LAN...
  • Page 18 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-2-11: User info 3.2.4.1 WLAN Interface This page shows WLAN information, including SSID name, channel, whether enable security or not. Figure 3-2-12: WLAN Interface 3.2.4.2 Associated Clients The page shows the clients information associated with the WLAN, including the packet on send or receive direction, Send Rate, RSSI, Expired Time and SSID-Name.
  • Page 19 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.2.4.3 WLAN Interface Statistics The page shows the statistics of the WLAN in the sending and receiving directions. Figure 3-2-14: WLAN Interface Statistics 3.2.4.4 LAN Interface This page shows LAN address and LAN gateway. Figure 3-2-15: LAN Interface 3.2.4.5 LAN Interface Statistics...
  • Page 20 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.2.4.6 Active DHCP Clients This page shows the lease information of the DHCP server. Figure 3-2-17:Active DHCP Clients 3.2.4.7 EasyMesh Device Details Table Figure 3-2-18: EasyMesh Device Details Table...

  • Page 21: Network

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.3 Network 3.3.1 WAN This page is used to set up WAN connections, create a bridge or routing type WAN, and set the NAT type. Figure 3-3-1:WAN 3.3.1.1 WAN Config This page allows you to add or modify WAN connections. You can’t add any WAN...
  • Page 22 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-2:WAN config Parameters Illustration This is the list table of WAN connection name. If you want to create a new WAN connection, please select “Add New Wan” and input other parameters at the same time and then click “Submit” button. If you want...
  • Page 23 AirLive ONU-10XG(S)-AX304P-2.5G User Guide IPv6: WAN connections use IPv6 protocol. IPv4 / IPv6: WAN connections use both IPv4 and IPv6 protocol. DHCP: Automatically obtain an IP address from your ISP IP Mode Static: Set the IP address manually PPPoE: Select this option if your ISP uses PPPoE unchecked: In this wan connection, the packets transmitted by the PON port without VLAN tag.

  • Page 24: Lan

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.3.2 LAN This page allows you to set up LAN, including IP, enable DHCP server, and reserve IP address for specific devices. Figure 3-3-4: LAN 3.3.2.1 IPv4 LAN Configuration This page allows you to do some LAN settings, such as LAN IP address, DHCP server.
  • Page 25 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Parameters Illustration IP Address LAN IP address. Subnet Mask LAN IP mask. Disable DHCP DHCP Server is disabled. Server Enable DHCP Server Enable ONU DHCP server. Start IP Address: The start IP address of address pool.

  • Page 26: Mtu

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-7: IPv6 configuration 3.3.2.4 RA Configuration This page allows you to do RA configuration. Figure 3-3-8: RA configuration 3.3.3 MTU This page allows you to set system MTU. Figure 3-3-9: MTU...

  • Page 27: Wlan (2.4G)

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.3.4 WLAN (2.4G) This page is used to configure WIFI (2.4G) parameters. On each page, after configured you should click “Submit” button to save it. it is recommended to configure the Band to 2.4GHz (B+G+N+AX). Figure 3-3-10: 2.4G 3.3.4.1 2.4G WLAN Basic Setting...
  • Page 28 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-11: 2.4 G WLAN Basic Setting Parameter Illustration Disable WLAN Enable or Disable WLAN. Interface Band Choose 2.4G WiFi band. This device supports 802.11ax. SSID SSID Name. It is used to distinguish from other WLAN.
  • Page 29 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-12: WLAN Security 3.3.4.3 Multiple AP This page allows you to configure multiple AP parameters. They are turned off by default. Figure 3-3-13:Multiple AP 3.3.4.4 WLAN advanced These settings are only for more technically advanced users who have sufficient knowledge about WLAN.

  • Page 30: Wlan (5G)

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-14: WLAN Advanced 3.3.4.5 WPS These settings allows you to configure WPS setting. Figure 3-3-15: WPS Settings 3.3.5 WLAN (5G) This page is used to configure WIFI (5G) parameters. On each page, after configured you should click “Submit” button to save it. And this device supports WiFi6, if the terminal device also supports WiFi6, it is recommended to configure the Band to 5GHz (A+N+AC+AX).
  • Page 31 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-16: 5G 3.3.5.1 5G WLAN Basic Setting This page allows you to configure wireless basic settings. Basic settings include wireless switch, SSID name, channel width, channel number, radio power and so on. Figure 3-3-17: 5G WLAN Basic Setting...
  • Page 32 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Parameter Illustration Disable WLAN Enable or Disable WLAN. Interface Band Choose 5G WiFi band. This device supports 802.11ax. SSID SSID Name. It is used to distinguish from other WLAN. Cancel Broadcast Disable or Enable transmit broadcast in WLAN.
  • Page 33 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.3.5.4 WLAN advanced These settings are only for more technically advanced users who have a sufficient knowledge about WLAN. These settings should not be changed unless you know what effect the changes will have on your Access Point.

  • Page 34: Binding Settings

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.3.6 Binding Settings This page is used to configure binding mode, which contains port binding and VLAN binding. When using port binding, traffic of the LAN port will transmit to the WAN which binds this port; when using VLAN binding, traffic of the LAN port will transmit to the WAN which configured the same VLAN.
  • Page 35 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.3.7.1 ACS Client Configuration This page allows you to configure ACS connection parameters. Figure 3-3-24: ACS Client Configuration Parameter Illustration Server URL Server provider’s ACS server. Username Authentication username for ONU connects to ACS server. Password Authentication password for ONU connects to ACS server.
  • Page 36 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-25: LOID configuration 3.3.7.3 PonPwd Config GPON PLOAM Password is used for the registration and distribution of the new device, please do not change it. Restart the gateway if changing the Password causes business to malfunction.

  • Page 37: Qos

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-28: STUN Config 3.3.8 Qos This page allows you to configure QoS config, QoS Classification and QoS Traffic Control. Figure 3-3-29: Qos 3.3.8.1 Qos Config This page is used to configure the QoS policy and Queue. If select PRIO of policy, the lower numbers imply greater precedence.
  • Page 38 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-30: QoS Config 3.3.8.2 QoS Classification This page is used to configure the QoS classification. Click on the "Add" button to add the network traffic control type rules. Figure 3-3-31: QoS Classification Figure 3-3-32: QoS rule...
  • Page 39 AirLive ONU-10XG(S)-AX304P-2.5G User Guide parameter illustration IP protocol version Select IPv4 or IPv6. Flow control type name Input this rule name. Specify IP Priority Tags Select queue. Specify DSCP Tag Select DSCP tag. If the WAN port 802.1p is enabled, set the 802.1p If 802.1p is set in the WAN, set the 802.1p value.
  • Page 40 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-33: QoS Traffic Control Figure 3-3-34: QoS Traffic Control Shaping Rule parameter illustration Total Bandwidth Limit Select whether to enable the total bandwidth limit. Enable Total Bandwidth Limit Input the total bandwidth that you want to limit.

  • Page 41: Time

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Source Mask Iput the source subnet mask. Destination IP Input destination IP address. Destination Mask Input the destination subnet mask. Source Port Input source port. Destination Port Input destination port. Rate Limit Input the limit rate.
  • Page 42 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-3-36: Route 3.3.10.1 RIP Configuration This page allows you to configure RIP function. Figure 3-3-37: RIP configuration Parameter Illustration RIP switch.
  • Page 43 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Interface WAN connection for transmitting or receiving RIP messages. Receive Mode The version of RIP messages that have been received. Send Mode The version of RIP messages that have been sent. RIP configuration RIP configuration that has been added.
  • Page 44 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Subnet Mask Destination network mask. Gateway The gateway IP address. It is used to determine the optimal route when searching for a Metric route. Its value range is 0~16. Interface Select the wan interface you want to add static route...

  • Page 45: Security

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.4 Security 3.4.1 URL Filtering This page allows you to configure URL filter. URL filter is taking effect when the wan connection is in router mode. In other words, when the wan connection is in bridge mode, the URL filter cannot be taken effect.

  • Page 46: Login Privilege

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-4-2: Security Classify Parameter Illustration Low: Protect nothing. Firewall Level High: Forbid ICMP Input, Forbid Port Scan, Denial of Service protections. 3.4.3 Login Privilege This page is used to configure the access control and common ports on the upstream and downstream directions.

  • Page 47: Ip/Port Filtering

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-4-4: MAC Filtering Parameter Illustration Enable Mac Address unchecked: Disable Mac Filter. Filtering checked: Enable Mac Filter. Black List: MAC Address in the list will be forbidden and others will be accessed. Filtering Mode White List: Mac Address in the list will be accessed and others will be forbidden.
  • Page 48 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-4-6: Port Filter -Incoming Parameter Illustration IP Address Filtering Switch of IP/port filtering. Black List: Rule in the list will be forbidden and others will be accessed. Filter Mode White List: Rule in the list will be accessed and others will be forbidden.
  • Page 49 AirLive ONU-10XG(S)-AX304P-2.5G User Guide when using single IP address. Destination IP Input the destination IP address you want to configure in the Address rule. Destination Subnet Input the mask of destination IP address. Only need to Mask configure when using single IP address.

  • Page 50: Application

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.5 Application 3.5.1 VoIP Basic Settings This page allows you to do VoIP basic configurations. Figure 3-5-1: VoIP Basic Configuration...

  • Page 51: Voip Advance Settings

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Parameter Illustration Server Type SIP server type, soft switch and IMS. Primary SIP Register Primary SIP register server address. Address Standby SIP Register Secondary SIP register address. Address Port The port of SIP protocol, default port is 5060.
  • Page 52 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-5-2-a: VoIP Advance Settings...
  • Page 53 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-5-2-b: VoIP Advance Settings Parameter Illustration SIP Local Port Set local port of SIP messages. RTP Start Port Set beginning port of RTP messages. Packet Time Set packet time of RTP messages, in millisecond. DTMF Mode Set DTMF mode.
  • Page 54 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Echo Suppression Enable or disable echo suppression function. Settings Enable or disable voice activation detection function. T.38 Enable or disable T.38 fax mode. Sync Phone time Enable or disable sync phone time Caller ID mode Set caller ID mode.

  • Page 55: Multicast Setting

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Busy Forward Enable or disable busy forward. Busy Forward Num Set busy forward number. No Answer Forward Enable or disable no answer forward. No Answer Forward Set no answer forward number. No Answer Forward Set no answer forward time.
  • Page 56 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-5-4: IGMP Snooping 3.5.3.2 IGMP Proxy This page allows you to enable IGMP proxy for a specified WAN connection. IGMP proxy takes effect for route mode WAN. Figure 3-5-5: IGMP Proxy 3.5.3.3 MLD Snooping This page allows you to enable or disable the MLD snooping function for IPv6, just like the IGMP snooping for IPv4.

  • Page 57: Advance Nat

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-5-7: MLD Proxy 3.5.3.5 IPTV This page allows you to configure multicast VLAN for WAN connections. Click the corresponding WAN name to add VLAN. Figure 3-5-8:IPTV Figure 3-5-9: Multicast VLAN 3.5.4 Advance NAT This page allows you to configure some advanced NAT settings such as Application...
  • Page 58 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-5-10: Advance NAT 3.5.4.1 ALG This page shows the ALG settings, such as h.323, SIP, RTSP, IPSEC, FTP, L2TP and so Figure 3-5-11: ALG configuration...
  • Page 59 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.5.4.2 DMZ Hosts This page allows you to configure DMZ server. Figure 3-5-12: DMZ configuration 3.5.4.3 Virtual Server Configuration This page allows you to configure virtual server. After you click the “Add” button, you will see the configuration page.

  • Page 60: Others

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide You can select the “delete” checkbox and then click the “Delete Selected” button to remove service items from the service table. 3.5.5 Others This page allows you to configure some other settings, including Dynamic DNS, UPnP,...
  • Page 61 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-5-17: DDNS configuration Parameter Illustration DDNS Provider Choose DDNS service provider. Hostname Set host name of the device. Interface The interface of accessing by DDNS. Username The username which is used to access DDNS server.
  • Page 62 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-5-19: FTP configuration 3.5.5.4 USB Config This page is used to configure USB. Figure 3-5-20: USB configuration...

  • Page 63: Management

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.6 Management 3.6.1 User Manage This page allows you to change login password of current user. Figure 3-6-1: User management 3.6.2 Device Manage This page allows you to manage devices, including upgrade, restart, restore factory default configuration, etc...
  • Page 64 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.6.2.1 Upgrade Image This page allows you to upgrade the device. You can select the upgrade firmware and click "Upgrade" to upgrade device. Please keep the power on, otherwise this device will be damaged. It will reboot automatically when finish upgrade.
  • Page 65 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-6-4: Timely reboot 3.6.2.4 Load Default This page allows you to restore the device to default settings. You can click “Restore Default” or "Restore factory configuration" button to restore settings of the device. "Restore Default" button restore the LAN parameter, "Restore Factory configuration"...
  • Page 66 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 3-6-7: Download configuration Management 3.6.2.6 Upload Configuration Management This page allows you to restore the configurations of ONU. "Upload" button can upload the configuration file to device . "Upload As Default" button can upload your configuration file as default configuration .

  • Page 67: Log Manage

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.6.3 Log Manage This page allows you to make some settings on the system log including record, view, download logs Figure 3-6-10: Log Manage 3.6.3.1 System Log This page allows you to set up log level and display level, and log server as well.
  • Page 68 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Display Level Log display level, include Emergency, Alert, Critical, Error, Warning, Notice, Informational, Debugging. Storage Mode Can select to store the log in local or remote server. 3.6.3.2 LOG Info This page allows you to view and clear the log information.

  • Page 69: Diagnostics

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.7 Diagnostics 3.7.1 Network diagnostics 3.7.1.1 Network diagnostics This page is used for ping test and tracert test. You can diagnose connection status between ONU and other devices. Please note that when the traceroute is running, do not perform the traceroute test again.
  • Page 70 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3.7.2.1 Loopback Test This page is used to configure loopback detect function. By default, loop detection is turned on. Figure 3-7-3: Loopback detect settings 3.7.2.2 Port Loopback Detect State This page is used to show the loop status of each port.

  • Page 71: Chapter 4 Examples

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Chapter 4 Examples 4.1 Internet service There are two configuration methods for Internet service. One works on bridge mode and another works on route mode. 4.1.1 Requirement 1) ONU works on bridge mode, service VLAN is 9. User surf the Internet via LAN port 1.
  • Page 72 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-1-1: Add a bridge WAN connection 2) Surf the Internet Connect PC to LAN 1 port. After get IP address from DHCP server in the network, the PC can surf the Internet. 4.1.2.2 Route mode for Internet service 1) Add a WAN connection Choose “Network >...

  • Page 73: Iptv Service

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-1-2: Add a route WAN connection 2) Surf the Internet Connect PC to LAN port 1. The PC gets IP address from ONU and ONU gets IP address from DHCP server in the network, and then you can surf the Internet.

  • Page 74: Steps

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide ONU works on route mode for IPTV service, VLAN is 30. 4.2.2 Steps Before configuring, make sure ONU has registered and been authorized successfully. Connect PC to one LAN port of ONU directly with twisted cable.
  • Page 75 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 2) Enable IGMP snooping Choose “Application > Multicast Setting > IGMP Snooping Configuration” in navigation menu. Check down IGMP snooping. IGMP snooping is checked by default. It will not be mentioned in the rear examples. Figure 4-2-2: Enable IGMP snooping 3) Add multicast snooping VLAN Choose “Application >...
  • Page 76 AirLive ONU-10XG(S)-AX304P-2.5G User Guide  Enable VLAN and VLAN ID is 30.  Service mode is INTERNET.  Bind port 2.  Other parameters keep default. Figure 4-2-4: Add a route WAN connection 2) Enable IGMP proxy Choose “Application > Multicast Setting > IGMP Proxy” in navigation menu.Enable...

  • Page 77: Voip Service

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-2-5: Enable IGMP proxy 3) Add multicast proxy VLAN Choose “Application > Multicast Setting > IPTV” in navigation menu. Click on choose the relevant WAN connection and add multicast VLAN, the result is as shown in the figure.

  • Page 78: Steps

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide username and the password are the same as phone numbers. 4.3.2 Steps Before configuring, make sure HGU has registered and been authorized successfully. Connect PC to one LAN port of HGU directly with twisted cable. 1) Add a WAN connection Choose “Network >...
  • Page 79 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 2) Configure VoIP general parameters Choose “Application > VoIP Basic Settings” in navigation menu. Set up VoIP general parameters as following shows.  Choose which region VoIP service is used for. Different regions have different Dial tones, ringing tones etc.
  • Page 80 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-3-2: VoIP Basic settings...

  • Page 81: Internet And Iptv Service Mixed

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3) Look up register status Choose “Status > WAN Info > VoIP Info” in navigation menu. You can use VoIP service when register status is successful. Figure 4-3-3: VoIP registering status 4.4 Internet and IPTV service mixed This example introduces how to achieve Internet service and IPTV service at the same time.
  • Page 82 AirLive ONU-10XG(S)-AX304P-2.5G User Guide  Service mode is INTERNET.  Bind port 1.  Other parameters keep default. Figure 4-4-1: Add a route mode WAN Add a bridge mode WAN connection, enable VLAN and VLAN ID is 20, service mode...
  • Page 83 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-4-2: Add a bridge mode WAN 2) Add IGMP snooping VLAN Choose “Application > Multicast Setting > IPTV ” in navigation menu. Click the relevant WAN connection and add multicast VLAN. Figure 4-4-3:Add multicast VLAN...
  • Page 84 AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3) Surf the Internet Connect PC to LAN port 1. The PC gets an IP address from ONU and ONU gets an IP address from DHCP server in the network, and then you can surf the Internet.
  • Page 85 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-4-4: Add a route mode WAN connection 2) Enable IGMP proxy Choose “Application > Multicast > IGMP Proxy” in navigation menu. Enable IGMP proxy and choose the relevant WAN connection .

  • Page 86: Internet, Iptv And Voip Service Mixed

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-4-5: Enable IGMP proxy 3) Add Multicast VLAN Choose “Application > Multicast Setting > IPTV ” in navigation menu. Click the relevant WAN connection and add multicast VLAN. Figure 4-4-6:Add multicast VLAN. 4) Surf the Internet Connect PC to LAN port 1.

  • Page 87: Steps

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Username and password of SIP account: 12345678,12345678. 4.5.2 Steps Before configuring, make sure HGU has registered and been authorized successfully. Connect PC to one LAN port of HGU directly with twisted cable. 1) Add WAN connection Choose “Network >...
  • Page 88 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Add a bridge mode WAN connection for IPTV service. Enable VLAN and its VLAN ID is 1100. Service mode is other. Bind LAN 2. Figure 4-5-2: Add a WAN connection for IPTV service Add a route mode WAN connection for VOIP service. Choose IPv4 and static; fill up the IP...
  • Page 89 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-5-3: Add a WAN connection for VOIP service 2) Configure VOIP general parameters Choose “Application > VOIP Basic Settings” in navigation menu. Configure VOIP general parameters as the following shows.  “Region” contains many countries or regions. Different regions have their own dial tone and ringing tone, etc.
  • Page 90 AirLive ONU-10XG(S)-AX304P-2.5G User Guide  Figure 4-5-4: VOIP general settings...

  • Page 91: Wlan Service

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 3) Add IGMP snooping VLAN Choose “Application > Multicast Setting > IPTV ” in navigation menu. Click the relevant WAN connection and add multicast VLAN. Figure 4-5-5:Add multicast VLAN. 4) Surf the Internet Connect PC to LAN port 1. The PC gets an IP address from HGU and HGU gets an IP address from DHCP server in the network, and then you can surf the Internet.

  • Page 92: Requirement

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 4.6.1 Requirement 1) HGU works on Route mode, HGU gets IP by DHCP mode,VLAN ID is 11. 2) Only enable SSID 1, its name is “xyz”. Network authentication method is WPA- PSK, and encryption method is TKIP+AES.
  • Page 93 AirLive ONU-10XG(S)-AX304P-2.5G User Guide  Figure 4-6-1: Add a route WAN connection 2) Configure WLAN basic parameters Choose “Network > 2.4G > 2.4G WLAN Basic Setting” in navigation menu. Enable wireless and modify SSID1’s name to xyz. For other parameters, just configure the suitable...
  • Page 94 AirLive ONU-10XG(S)-AX304P-2.5G User Guide Figure 4-6-2: WLAN basic settings 3) Configure network authentication Choose “Network > 2.4G > WLAN Security” in navigation menu. Select the SSID, and set up WPA+WPA2 for its network authentication method and AES for its encryption method.

  • Page 95: Update Image

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide 4) Surf the Internet Search SSID named xyz with a laptop, double-click to connect and enter the correct password. If client has WPS function, you can connect client to AP by pressing Pair button in HGU.

  • Page 96: Chapter 5 Faq

    AirLive ONU-10XG(S)-AX304P-2.5G User Guide Chapter 5 FAQ 1. Q: All indicators are not lit? A: (1) The indicator LED hasn't come up yet, you need to wait about two minutes. (2) Power is off or power adapter is bad. 2. Q: Why PON/LOS indicator flashing red? A: (1) There is no optical signal.

This manual is also suitable for:

Onu-10xgs-ax304p-2.5g

Table of Contents
