AirLive ONU-10XG-1004-10G User Manual

Hide thumbs Also See for ONU-10XG-1004-10G:
Table of Contents

Advertisement

Quick Links

Download this manual
AirLive
ONU-10XG(S)-1004-10G
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONU-10XG-1004-10G and is the answer not in the manual?

Questions and answers

Related Manuals for AirLive ONU-10XG-1004-10G

Summary of Contents for AirLive ONU-10XG-1004-10G

  • Page 1 AirLive ONU-10XG(S)-1004-10G USER MANUAL...

  • Page 2: Table Of Contents

    AirLive ONU-10XG(S)-1004-10G User Guide Contents Chapter 1 Product Introduction ..................1 1.1 Product Description ......................1 1.2 Special features ....................... 2 1.3 Technical parameters ...................... 2 1.4 Application chart ......................3 1.5 Panel description ......................3 Chapter 2 Quick Installation ....................6 2.1 Standard Packing Contents ....................
  • Page 3 AirLive ONU-10XG(S)-1004-10G User Guide 3.4.2 Firewall ........................33 3.4.3 Login Privilege ....................... 34 3.4.4 MAC Filtering ......................34 3.4.5 IP/Port Filtering ...................... 35 3.5 Application ........................38 3.5.1 Multicast Setting ..................... 38 3.5.2 Advance NAT ......................40 3.5.3 Others ........................42 3.6 Management .........................

  • Page 4: Chapter 1 Product Introduction

    Chapter 1 Product Introduction 1.1 Product Description The 10G PON AirLive ONU-10XG(S)-1004-10G developed by AirLive comes in two models a XG-PON and XGS-PON, providing multiple rate Ethernet ports of 10GE/GE. It enables fast and stable networking for multiple devices, ensuring a seamless user experience within homes and effortlessly meeting the demands of 4K/8K, VR, and other services.

  • Page 5: Special Features

    AirLive ONU-10XG(S)-1004-10G User Guide 1.2 Special features ⚫ Plug and play, integrated auto detecting, auto configuration, and auto firmware upgrade technology. ⚫ Integrated TR069 remote configuration and maintenance function. ⚫ Support rich VLAN, DHCP Server/Relay and IGMP/MLD snooping multicast feature.

  • Page 6: Application Chart

    AirLive ONU-10XG(S)-1004-10G User Guide 1.4 Application chart Figure 1-4-1: Application chart, when using XG-Pon it will be 10G DL/2.5G UL 1.5 Panel description Interface panel Figure 1-5-1: Interface panel Name Function ON/OFF Power switch. DC 12V Connect with power adapter. DC 12V, 1A.
  • Page 7 AirLive ONU-10XG(S)-1004-10G User Guide The silver LAN1 is 10GE port and the yellow LAN2-5 are 1GE port. LAN1-5 Connect PC or other devices to GE port by Cat5 cable, RJ-45 connector and connect to 10GE port by Cat6a cable, RJ-45 connector.
  • Page 8 AirLive ONU-10XG(S)-1004-10G User Guide Port is connected properly (LINK). LAN1-5 Port is not connected properly. Blink Port is sending or/and receiving data (ACT). USB device is connected, but without ongoing data transmission. Device is powered off or USB device is not connected.

  • Page 9: Chapter 2 Quick Installation

    AirLive ONU-10XG(S)-1004-10G User Guide Chapter 2 Quick Installation 2.1 Standard Packing Contents When you receive our products, please check carefully to make sure that our products do not have some defects or not. If something is wrong after shipping, please contact carrier;...

  • Page 10: Set Up Connection

    AirLive ONU-10XG(S)-1004-10G User Guide 4. Check all signal levels and services on all the ONU communication ports. Unit Installation Adjustment Installing the ONU on a horizontal surface (Bench top) Put the ONU on a clean, flat, sturdy bench top. You must keep the clearance for all sides of the unit to more than 10cm for heat dissipation.

  • Page 11: Chapter 3 Configuration

    AirLive ONU-10XG(S)-1004-10G User Guide Chapter 3 Configuration After finishing the basic connection configuration, you can use its basic function. In order to satisfy individuation service requirements, this chapter provides you with the parameter modification and individuation configuration description. 3.1 Login The device is configured by the web interface.

  • Page 12: Status

    AirLive ONU-10XG(S)-1004-10G User Guide 3.2 Status This part shows the main information of the product. 3.2.1 Device Info This page shows the device basic information, such as device model, device SN, hardware version, and firmware version , PON S/N, CPU usage, memory usage and quick guide.
  • Page 13 AirLive ONU-10XG(S)-1004-10G User Guide 3.2.2.1 IPv4 Connection Info This page shows IPv4 WAN connection information that you have configured. Figure 3-2-3: IPv4 WAN Information 3.2.2.2 IPv6 Connection Info This page shows IPv6 WAN connection information that you have configured. Figure 3-2-4: IPv6 WAN Information 3.2.2.3 TR069 Status...

  • Page 14: Pon Info

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-2-5: TR069 connection Status 3.2.3 PON Info This page shows the PON information, including connection information, FEC information, temperature, voltage, current, optical power, and statistics of the packet on send or receive direction. Figure 3-2-6: PON Info 3.2.3.1 Connect information...
  • Page 15 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-2-7: Connection Info 3.2.3.2 Laser Device Info This page shows the laser device information, including temperature, voltage, current, optical power. Figure 3-2-8: Laser Device Info...

  • Page 16: User Info

    AirLive ONU-10XG(S)-1004-10G User Guide 3.2.3.3 Link Performance Info This page shows statistics of the packet on send or receive direction. Figure 3-2-9: Link Performance Info 3.2.4 User Info This page shows the user information for LAN, including LAN IP, LAN packets and...
  • Page 17 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-2-10: User info 3.2.4.1 LAN Interface This page shows LAN address and LAN gateway. Figure 3-2-11: LAN Interface 3.2.4.2 LAN Interface Statistics This page shows the statistics of received or sent packets of the LAN interface.
  • Page 18 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-2-12: LAN Interface Statistics 3.2.4.3 Active DHCP Clients This page shows the lease information of the DHCP server. Figure 3-2-13: Active DHCP Clients...

  • Page 19: Network

    AirLive ONU-10XG(S)-1004-10G User Guide 3.3 Network 3.3.1 WAN This page is used to set up WAN connections, create a bridge or routing type WAN, and set the NAT type. Figure 3-3-1:WAN 3.3.1.1 WAN Config This page allows you to add or modify WAN connections. You can’t add any WAN...
  • Page 20 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-2:WAN config Parameters Illustration This is the list table of WAN connection name. If you want to create a new WAN connection, please select “Add New Wan” and input other parameters at the same time and then click “Submit”...

  • Page 21: Lan

    AirLive ONU-10XG(S)-1004-10G User Guide PON port with VLAN tag. VLAN ID: input the VLAN ID you want to set. 802.1p: select the port priority you want to set. MTU: max transfer unit. Default Value: 1492 in route PPPoE mode, 1500 in other modes.
  • Page 22 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-4: LAN 3.3.2.1 IPv4 LAN Configuration This page allows you to do some LAN settings, such as LAN IP address, DHCP server. Figure 3-3-5: IPv4 configuration Parameters Illustration IP Address LAN IP address. Subnet Mask...
  • Page 23 AirLive ONU-10XG(S)-1004-10G User Guide Disable DHCP DHCP Server is disabled. Server Enable DHCP Server Enable ONU DHCP server. Start IP Address: The start IP address of address pool. End IP Address: The end IP address of address pool. Lease Time: Lease time of the IP address.

  • Page 24: Mtu

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-7: IPv6 configuration 3.3.2.4 RA Configuration This page allows you to do RA configuration. Figure 3-3-8: RA configuration 3.3.3 MTU This page allows you to set system MTU.

  • Page 25: Binding Settings

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-9: MTU 3.3.4 Binding Settings This page is used to configure binding mode, which contains port binding and VLAN binding. When using port binding, traffic of the LAN port will transmit to the WAN which binds this port;...
  • Page 26 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-11: TR069 3.3.5.1 ACS Client Configuration This page allows you to configure ACS connection parameters. Figure 3-3-12: ACS Client Configuration...
  • Page 27 AirLive ONU-10XG(S)-1004-10G User Guide Parameter Illustration Server URL Server provider’s ACS server. Username Authentication username for ONU connects to ACS server. Password Authentication password for ONU connects to ACS server. Enable Certificate Whether needs certificates or not. Periodic Report Switch of inform interval.
  • Page 28 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-14: Password configuration 3.3.5.4 CA Certificate This page is used to upload CA certificate. Choose a CA certificate file and click “Certificate Import” button to upload. Figure 3-3-15: Upload CA certificate 3.3.5.5 STUN This page is used to set the STUN server parameter. It can make your ONU to connect the ACS pass through NAT.

  • Page 29: Qos

    AirLive ONU-10XG(S)-1004-10G User Guide 3.3.6 Qos This page allows you to configure QoS config, QoS Classification and QoS Traffic Control. Figure 3-3-17: Qos 3.3.6.1 Qos Config This page is used to configure the QoS policy and Queue. If select PRIO of policy, the lower numbers imply greater precedence.
  • Page 30 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-19: QoS Classification Figure 3-3-20: QoS rule parameter illustration IP protocol version Select IPv4 or IPv6. Flow control type name Input this rule name. Specify IP Priority Tags Select queue. Specify DSCP Tag Select DSCP tag.
  • Page 31 AirLive ONU-10XG(S)-1004-10G User Guide Mode Selection Select the general mode or the application type. Physical LAN Port Select the physical LAN port to which this rule applies. Protocol Select Protocol. DSCP Check Select DSCP Check mark. 802.1p Priority Input 802.1p Priority.
  • Page 32 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-22: QoS Traffic Control Shaping Rule parameter illustration Total Bandwidth Limit Select whether to enable the total bandwidth limit. Enable Total Bandwidth Limit Input the total bandwidth that you want to limit. IP Version Select IPv4 or IPv6.

  • Page 33: Time

    AirLive ONU-10XG(S)-1004-10G User Guide 3.3.7 Time This page allows you to configure time related parameters of your router. After you have selected the check box, select the time server and time zone you want to set and then click the “Submit” button to save.
  • Page 34 AirLive ONU-10XG(S)-1004-10G User Guide 3.3.8.1 RIP Configuration This page allows you to configure RIP function. Figure 3-3-25: RIP configuration Parameter Illustration RIP switch. Interface WAN connection for transmitting or receiving RIP messages. Receive Mode The version of RIP messages that have been received.
  • Page 35 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-3-26: Static route Figure 3-3-2: Static Route configuration Parameter Illustration Enable Switch of static route. Destination Destination network address. Subnet Mask Destination network mask. Gateway The gateway IP address. It is used to determine the optimal route when searching for a Metric route.

  • Page 36: Security

    AirLive ONU-10XG(S)-1004-10G User Guide 3.4 Security 3.4.1 URL Filtering This page allows you to configure URL filter. URL filter is taking effect when the wan connection is in router mode. In other words, when the wan connection is in bridge mode, the URL filter cannot be taken effect.

  • Page 37: Login Privilege

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-4-2: Security Classify Parameter Illustration Low: Protect nothing. Firewall Level High: Forbid ICMP Input, Forbid Port Scan, Denial of Service protections. 3.4.3 Login Privilege This page is used to configure the access control and common ports on the upstream and downstream directions.

  • Page 38: Ip/Port Filtering

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-4-4: MAC Filtering Parameter Illustration Enable Mac Address unchecked: Disable Mac Filter. Filtering checked: Enable Mac Filter. Black List: MAC Address in the list will be forbidden and others will be accessed. Filtering Mode White List: Mac Address in the list will be accessed and others will be forbidden.
  • Page 39 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-4-6: Port Filter -Incoming Parameter Illustration IP Address Filtering Switch of IP/port filtering. Black List: Rule in the list will be forbidden and others will be accessed. Filter Mode White List: Rule in the list will be accessed and others will be forbidden.
  • Page 40 AirLive ONU-10XG(S)-1004-10G User Guide when using single IP address. Destination IP Input the destination IP address you want to configure in the Address rule. Destination Subnet Input the mask of destination IP address. Only need to Mask configure when using single IP address.

  • Page 41: Application

    AirLive ONU-10XG(S)-1004-10G User Guide 3.5 Application 3.5.1 Multicast Setting This page allows you to configure multicast-related parameter. Figure 3-5-1: Multicast Setting 3.5.1.1 IGMP Snooping Configuration This page allows you to enable or disable the IGMP Snooping function. Figure 3-5-2: IGMP Snooping 3.5.1.2 IGMP Proxy...
  • Page 42 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-5-3: IGMP Proxy 3.5.1.3 MLD Snooping This page allows you to enable or disable the MLD snooping function for IPv6, just like the IGMP snooping for IPv4. Figure 3-5-4: MLD Snooping 3.5.1.4 MLD Proxy This page allows you to enable MLD proxy for IPv6, just like enable IGMP proxy for IPv4.

  • Page 43: Advance Nat

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-5-6:IPTV Figure 3-5-7: Multicast VLAN 3.5.2 Advance NAT This page allows you to configure some advanced NAT settings such as Application Firewall, DMZ host, virtual server. Figure 3-5-8: Advance NAT 3.5.2.1 ALG This page shows about ALG settings, such as h.323, SIP, RTSP, IPSEC, FTP, L2TP and...
  • Page 44 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-5-9: ALG configuration 3.5.2.2 DMZ Hosts This page allows you to configure DMZ server. Figure 3-5-10: DMZ configuration 3.5.2.3 Virtual Server Configuration This page allows you to configure virtual server. After you click the “Add” button, you...

  • Page 45: Others

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-5-11: Add Virtual Server Figure 3-5-12: Virtual Server configuration You can select the “delete” checkbox and then click the “Delete Selected” button to remove service items from the service table. 3.5.3 Others This page allows you to configure some other settings, including Dynamic DNS, UPnP,...
  • Page 46 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-5-13: Other 3.5.3.1 Dynamic DNS Dynamic DNS services allow you to change a dynamic IP address to a static host name in any multiple domains, allowing your router to be more easily accessed from different locations on the Internet.
  • Page 47 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-5-15: DDNS configuration Parameter Illustration DDNS Provider Choose DDNS service provider. Hostname Set host name of the device. Interface The interface of accessing by DDNS. Username The username which is used to access DDNS server.
  • Page 48 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-5-17: FTP configuration 3.5.3.4 USB Config This page is used to configure USB. Figure 3-5-18: USB configuration...

  • Page 49: Management

    AirLive ONU-10XG(S)-1004-10G User Guide 3.6 Management 3.6.1 User Manage This page allows you to change login password of current user. Figure 3-6-1: User management 3.6.2 Device Manage This page allows you to manage devices, including upgrade, restart, restore factory default configuration, etc...
  • Page 50 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-6-2: Device Manage 3.6.2.1 Upgrade Image This page allows you to upgrade the device. You can select the upgrade firmware and click "Upgrade" to upgrade device. Please keep the power on, otherwise this device will be damaged.
  • Page 51 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-6-4: Device reboot 3.6.2.3 Timely Reboot This page is used to configure timely reboot.The device will reboot at the set time, but the function will take effect only after the synchronization time. Figure 3-6-4: Timely reboot 3.6.2.4 Load Default...
  • Page 52 AirLive ONU-10XG(S)-1004-10G User Guide 3.6.2.5 Current Configuration Management This page allows you to backup the configurations of ONU. "Download" button can download the current configuration file to your PC. "Cancel self custom default" button can remove your previous default configuration which uploaded before.

  • Page 53: Log Manage

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-6-9: Upload when End Maintain 3.6.3 Log Manage This page allows you to make some settings on the system log including record, view, download logs Figure 3-6-10: Log Manage 3.6.3.1 System Log This page allows you to set up log level and display level, and log server as well.

  • Page 54: Other Manage

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-6-11: Log settings Parameters Illustration Log Level Log record level, include Emergency, Alert, Critical, Error, Warning, Notice, Informational, Debugging. Display Level Log display level, include Emergency, Alert, Critical, Error, Warning, Notice, Informational, Debugging. Storage Mode Can select to store the log in local or remote server.
  • Page 55 AirLive ONU-10XG(S)-1004-10G User Guide Figure 3-6-13: Device Type Config...

  • Page 56: Diagnostics

    AirLive ONU-10XG(S)-1004-10G User Guide 3.7 Diagnostics 3.7.1 Network diagnostics 3.7.1.1 Network diagnostics This page is used for ping test and tracert test. You can diagnose connection status between ONU and other devices.Please note that when the traceroute is running, do not perform the traceroute test again.
  • Page 57 AirLive ONU-10XG(S)-1004-10G User Guide 3.7.2.1 Loopback Test This page is used to configure loopback detect function.By default, loop detection is turned on. Figure 3-7-3: Loopback detect settings 3.7.2.2 Port Loopback Detect State This page is used to show the loop status of each port.

  • Page 58: Chapter 4 Examples

    AirLive ONU-10XG(S)-1004-10G User Guide Chapter 4 Examples 4.1 Internet service There are two configuration methods for Internet service. One works on bridge mode and another works on route mode. 4.1.1 Requirement 1) ONU works on bridge mode, service VLAN is 9. User surf the Internet via LAN port 1.
  • Page 59 AirLive ONU-10XG(S)-1004-10G User Guide Figure 4-1-1: Add a bridge WAN connection 2) Surf the Internet Connect PC to LAN 1 port. After get IP address from DHCP server in the network, the PC can surf the Internet. 4.1.2.2 Route mode for Internet service 1) Add a WAN connection Choose “Network >...

  • Page 60: Iptv Service

    AirLive ONU-10XG(S)-1004-10G User Guide Figure 4-1-2: Add a route WAN connection 2) Surf the Internet Connect PC to LAN port 1. The PC gets IP address from ONU and ONU gets IP address from DHCP server in the network, and then you can surf the Internet.
  • Page 61 AirLive ONU-10XG(S)-1004-10G User Guide Connect PC to one LAN port of ONU directly with twisted cable. 4.2.2.1 Bridge mode for IGMP 1) Add a WAN connection Choose “Network > WAN > WAN Config” in navigation menu. Add a bridge mode WAN connection as the following parameters.
  • Page 62 AirLive ONU-10XG(S)-1004-10G User Guide Figure 4-2-2: Enable IGMP snooping 3) Add multicast snooping VLAN Choose “Application > Multicast Setting > IPTV” in navigation menu. Click on choose the relevant WAN connection and add multicast VLAN, the result is as shown in the figure.
  • Page 63 AirLive ONU-10XG(S)-1004-10G User Guide  Other parameters keep default. Figure 4-2-4: Add a route WAN connection 2) Enable IGMP proxy Choose “Application > Multicast Setting > IGMP Proxy” in navigation menu.Enable IGMP proxy and choose the relevant WAN connection. Figure 4-2-5: Enable IGMP proxy 3) Add multicast proxy VLAN Choose “Application >...

  • Page 64: Internet And Iptv Service Mixed

    AirLive ONU-10XG(S)-1004-10G User Guide choose the relevant WAN connection and add multicast VLAN, the result is as shown in the figure. Figure 4-2-6: Add multicast proxy VLAN 4) Join multicast group User sends an IGMP report message through LAN port 2 after got an IP address from ONU.
  • Page 65 AirLive ONU-10XG(S)-1004-10G User Guide  Choose DHCP. (Provided by ISP)  Enable VLAN and VLAN ID is 10.  Service mode is INTERNET.  Bind port 1.  Other parameters keep default. Figure 4-3-1: Add a route mode WAN Add a bridge mode WAN connection, enable VLAN and VLAN ID is 20, service mode...
  • Page 66 AirLive ONU-10XG(S)-1004-10G User Guide Figure 4-3-2: Add a bridge mode WAN 2) Add IGMP snooping VLAN Choose “Application > Multicast Setting > IPTV ” in navigation menu. Click the relevant WAN connection and add multicast VLAN. Figure 4-3-3:Add multicast VLAN 3) Surf the Internet Connect PC to LAN port 1.
  • Page 67 AirLive ONU-10XG(S)-1004-10G User Guide watch IPTV. 4.3.2.2 Route mode for mixed service 1) Add WAN connection Choose “Network > WAN > WAN Config” in navigation menu. Add a route mode WAN connection as the following parameters.  Protocol mode is IPv4.

  • Page 68: Update Image

    AirLive ONU-10XG(S)-1004-10G User Guide Choose “Application > Multicast > IGMP Proxy” in navigation menu. Enable IGMP proxy and choose the relevant WAN connection . Figure 4-3-5: Enable IGMP proxy 3) Add Multicast VLAN Choose “Application > Multicast Setting > IPTV ” in navigation menu. Click the relevant WAN connection and add multicast VLAN.
  • Page 69 AirLive ONU-10XG(S)-1004-10G User Guide Figure 4-4-1: Update software...

  • Page 70: Chapter 5 Faq

    AirLive ONU-10XG(S)-1004-10G User Guide Chapter 5 FAQ 1. Q: All indicators are not lit? A: (1) The indicator LED hasn't come up yet, you need to wait about two minutes. (2) Power is off or power adapter is bad. 2. Q: Why PON/LOS indicator flashing red? A: (1) There is no optical signal.
