RDS-Med™ Quick Guide
C.
D.
F.
C.
B.
A.
E.
H.
G.
A. Navigation keys with direct
functions, select key (ON/OFF) in
the middle
B. Flashing light for alarm and
pulse rate
C. Detector (markings for center
line / center point of the detector)
D. Attach to bracket or alarm box
E. Display with radiation levels
and types, status and settings
symbols
F. Fixing lug for the wrist strap
G. Binder connector with pro-
tective cap for external probes,
cable connections and external
alarming devices
H. Charging contacts
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mirion Technologies RDS-Med
Summary of Contents for Mirion Technologies RDS-Med
- Page 1 RDS-Med™ Quick Guide A. Navigation keys with direct functions, select key (ON/OFF) in the middle B. Flashing light for alarm and pulse rate C. Detector (markings for center line / center point of the detector) D. Attach to bracket or alarm box E.
- Page 2 The RDS-Med™ features a select key in the middle of the keypad and surrounding navigation keys: up, down, left and right. POWER ON by pressing the select key for two seconds. POWER OFF by first pressing the select key so that the OFF selection is acti- vated.
- Page 3 MENU ITEM FUNCTION Switch the meter off. DOSE Check and reset the current accumulated dose. MaxDR Check and reset the maximum recorded dose rate since last reset. CHIRP Switch ON/OFF the visual and audible pulse indication. Check and change the dose rate and dose alarm levels and choose ALARM alarm mode single, dual or off.
- Page 4 LED off • Real time clock function with 3 hrs backup • Enclosure class IP67 • Configuration and firmware upgrade through CSW-Med™ Software with a USB cable-link RDS-Med Quick Guide, Doc. no. 209310517 v 1.0 Mirion Technologies (RADOS) Oy...
