IN485MIT001I000 Gateway

3. Quickstart Guide for the IN485MIT001I000 Gateway

IMPORTANT

Disconnect all systems from power before connecting them to the gateway.

Mount the gateway in the desired installation site. This gateway can be mounted over a DIN rail, a wall, or

inside the indoor unit (in some indoor unit models only). See details in

NOTE

DIN rail mounting inside a grounded cabinet or metal enclosure is recommended.

Connect the gateway to the BACnet network via its EIA-485 port.

Connect the gateway to the indoor unit using the supplied AC connection cable. See details in

Procedure (page

8).

Configure the gateway using the built-in DIP switches. See details in

Check the communication performance between the BACnet bus and the AC system through the gateway's

LED indicators. See details in

The Intesis gateway is ready to be used in your system.

Page 4 of 55

LED Indicators (page

11).

Quickstart Guide for the IN485MIT001I000 Gateway

Mounting (page

7).

Connection

DIP switches (page

9).

USER MANUAL Version 1.2.6
