IN485MIT001I000 Gateway

10. Error Codes

Error Error CodeM Error in
Code RC
-1 CommError
0 0
1102 1102 1102
1108 1108 1108
1110 1110 1110
1300 1300 1300
1302 1302 1302
1503 1503 1503
1504 1504 1504
1504 1504 1504
1509 1509 1509
1520 1520 1520
2500 2500 2500
2502 2502 2502
2503 2503 2503
4030 4030 4030
4100 4100 4100
4101 4101 4101
4102 4102 4102
4103 4103 4103
4108 4108 4108
4118 4118 4118
4124 4124 4124
4210 4210 4210
4220 4220 4220
4230 4230 4230
5101 5101 5101
5102 5102 5102
5102 5102 5102
5104 5104 5104
5105 5105 5105
5106 5106 5106
5107 5107 5107
5110 5110 5110
5202 5202 5202
5300 5300 5300
6600 6600 6600
Page 54 of 55
Description
- AC unit is offline
- No error
Discharge Temperature high
Internal thermostat detector working
(49C)
Outdoor unit fail
Pressure low
Pressure high (High pressure probe
working 63H)
Protection against freeze or battery high
temperature
Protection against freeze or battery high
temperature
Overheating protection
High pressure error (ball valve closed)
Super heating anomaly due to low temp.
of discharge. (TH4)
Erroneous operation of drain pump
Erroneous operation of drain pump
Drain sensor anomaly (DS)
Serial transmission error
Compressor pause due to excess of
current (initial block)
Compressor pause due to excess of
current (overload)
Phase detection opened
Antiphase detection
Phase opened in phase L2 or connector
51CM opened
Error in the antiphase detector (electronic
board)
Connector 49L opened
Cut due to overcurrent of compressor
Voltage anomaly
Radiator panel temperature anomaly
(TH8)
Ambient temperature probe anomaly
(TH1), indoor unit
Liquid probe anomaly (TH2)
Cond/Evap probe anomaly (TH5)
Error detection in discharge temperature
Outdoor probe error TH3
Outdoor probe error TH7
Outdoor probe error TH6
Outdoor probe error TH8
Connector 63L opened
Current probe error
MNET duplicated address definition
