7.3.12. AirDirectionUD_command (Multistate Output Object Type)

It sets the indoor unit's vertical air direction (up-down).
Property Identifier Property Datatype
Object_Identifier BACnetObjectIdentifier
Object_Name CharacterString
Object_Type BACnetObjectType
Present_Value Unsigned
Description CharacterString
Device_Type CharacterString
Status_Flags BACnetStatusFlags
Event_State BACnetEventState
Reliability BACnetReliability
Out_Of_Service BOOLEAN
Number_Of_States Unsigned
State_Text BACnetArray[N] of CharacterString
Priority_Array BACnetPriorityArray
Relinquish_Default Unsigned
Time_Delay Unsigned
Notification_Class Unsigned
Feedback_Value Unsigned
Event_Enable BACnetEventTransitionBits
Acked_Transitions BACnetEventTransitionBits
Notify_Type BACnetNotifyType
Event_Time_Stamps BACnetArray[N] of BACnetTimeStamp
Profile_Name CharacterString
Table 10. Air direction up-down status
Present_Value
1
2
3
4
5
6
7
Page 28 of 55
Value
(Multistate Output, 2)
AirDirectionUD_command
MULTISTATE_OUTPUT (14)
1 .. 7
-
-
{FALSE, FALSE, FALSE, FALSE}
STATE_NORMAL (0)
NO_FAULT_DETECTED (0)
FALSE
7
Check the Air direction command table below
-
-
-
-
-
-
-
-
-
-
State_Text
Auto
Pos1
Pos2
Pos3
Pos4
Pos5
Swing
Objects and Properties
ASHRAE Gateway
R R
R R
R R
R W
O -
O -
R R
R R
O R
R R
R R
O R
R R
R R
O -
O -
O -
O -
O -
O -
O -
O -
