Daktronics RTX-11 1 Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
201 Daktronics Drive PO Box 5128 Brookings, SD 57006
tel 800-325-8766 fax 605-697-4700
www.daktronics.com
RTX-11X1/1801 Series
DAKT-0200-04
Display Manual
DD3084433
Customer: ______________________
Contract: _______________________
Model Number: _________________
Serial Number: __________________
Activation Date: _________________
Rev 0—05 January 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTX-11 1 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Daktronics RTX-11 1 Series

Summary of Contents for Daktronics RTX-11 1 Series

  • Page 1 RTX-11X1/1801 Series DAKT-0200-04 Display Manual DD3084433 Rev 0—05 January 2016 Customer: ______________________ Contract: _______________________ Model Number: _________________ Serial Number: __________________ Activation Date: _________________ 201 Daktronics Drive PO Box 5128 Brookings, SD 57006 tel 800-325-8766 fax 605-697-4700 www.daktronics.com...
  • Page 2 No part of this book covered by the copyrights hereon may be reproduced or copied in any form or by any means—graphic, electronic, or mechanical, including photocopying, taping, or information storage, and retrieval systems—without written permission of the publisher. Daktronics is a registered trademark of Daktronics, Inc. All other trademarks are property of their respective companies.

  • Page 3: Table Of Contents

    Table of Contents Section 1: How to Use This Manual ........................1 Resources ................................1 Numbering Conventions............................. 1 Part Number ..............................1 Module Number ............................2 Section Number ............................. 2 Model Number .............................. 2 Important Safeguards ............................2 Section 2: Mechanical Installation ........................
  • Page 4 Troubleshooting ..............................27 Section 5: Replacement Parts ..........................29 Replacement Parts List ............................29 Daktronics Exchange and Repair & Return Programs ................. 29 Exchange Program ............................29 Before Contacting Daktronics ........................29 Repair & Return Program .......................... 30 Shipping Address............................30 Daktronics Warranty &...

  • Page 5: How To Use This Manual

    Refer to Drawing B-3046757 in Appendix A for the locations of internal display components. Daktronics identifies manuals by the DD number located on the cover page of each manual. For example, this manual would be referred to as DD3084433. Please list the model number, display serial number, and the date this display became operational in the blanks provided on the front page of this manual.

  • Page 6: Module Number

    Module Number Figure 3 illustrates how Daktronics numbers modules on a ribbon display. A101 A105 A102 A103 A104 A202 A205 A201 A203 A204 A301 A303 A302 A304 A305 Figure 3: Module Number (Front View/Display Face) Section Number Figure 4 illustrates how Daktronics numbers sections on a ribbon display.

  • Page 7: Mechanical Installation

    Daktronics is not responsible for display mounting decisions made by others. Upper wall clips (vary contract to contract)

  • Page 8: Display Preparation

    Display or Display Section Lifting Single Section Daktronics equips each section with two lift lugs for lifting the sections into position. To expose these lift lugs, use the " hex security bit (Daktronics part number TH-1170) supplied in the toolkit to release all beverage shroud latches and open the beverage shroud.

  • Page 9: Weight Approximations

    Open the beverage shroud to access the lift lugs. The beverage shroud may be removed for lifting if necessary. The lift lugs are located one to two module 45° minimum widths inward, depending on the section size, from each end of the section. They are recessed into the section and need to be lifted up prior to lifting the Preferred Acceptable...

  • Page 10: Display Mounting

    Display Mounting This manual covers only general mounting topics. Refer to the contract-specific Shop Drawing for specific mounting instructions. It is the installer’s responsibility to ensure the installation meets local codes and standards. All hardware installation processes must meet the approved, stamped drawings from a professional engineer. Carefully read all bullet points below before proceeding with the installation steps.
  • Page 11 Activate the latches behind the right module column of each section until the seam is tight. Use a " hex T-handle (Daktronics part number TH-1088) to rotate the upper latch clockwise and the lower latch Figure 14: Display Attached to Wall counterclockwise.

  • Page 12: Corner Or Gap Mounting

    To mount a corner or gap, follow the steps below while referring to Figure 19: Use the supplied #10 self-tapping screws Conduit clip (Daktronics part number HC-1554) to attach the transition caps with pass-through holes (located in the border box attached to the front...

  • Page 13: Wing Section Installation

    Attach one plastic conduit clip at least 2" from one end of the conduit. Refer to Figure 20. Insert the 2" flexible conduit pieces into the pass-through hole in the border, leaving at least 6" sticking out of the section. Minimum 2"...
  • Page 14 Set the wing at the necessary angle to engage the left and right sections. The hinge adds a gap (seam) between the module columns, which is necessary for top-access module removal via the module pan sliders. Refer to Figure 24. Secure the retainer nuts and screws in the upper and lower support brackets into the left vertical of the wing to keep the wing from rotating.

  • Page 15: Border Attachment

    Refer to the contract-specific Shop Drawing for proper placement. End/transition cap: Use a " nutdriver (Daktronics part number TH-1156) to secure the #10 self-tapping screws (HC-1554) at a quantity of six and attach the caps. Refer to Figure 29 and Figure 30.
  • Page 16 This Page Intentionally Left Blank...

  • Page 17: Electrical Installation

    Code and/or other applicable local codes. This includes proper grounding and bonding of the sign. This display is suitable for wet locations. Daktronics engineering staff must approve any changes that may affect the weathertightness of the display. If any modifications are made to the weathertightness of the display, detailed drawings of the changes must be submitted to Daktronics engineering staff for evaluation and approval, or the warranty will be null and void.

  • Page 18: Common Connectors

    These connectors are not found in every display. Water-Tight SATA Cable Connector Daktronics uses a wide variety of SATA cables and SATA cable connectors. Figure 33 illustrates one of the most commonly used SATA cable connectors. To disconnect the SATA cable connector, squeeze the locking clips inward and pull the plug out of the jack.

  • Page 19: Display Power

    The material of an earth-ground electrode differs from region to region and varies with conditions present at the site. Consult local grounding codes. Daktronics does not recommend using the support structure as an earth-ground electrode; concrete, primer, corrosion, and other factors make the support structure a poor ground.

  • Page 20: Main Disconnect

    Main Disconnect Refer to the contract-specific System Riser Diagram to determine who must supply a fused main distribution/disconnect, surge suppressor, and the necessary wiring for power distribution to multiple display termination panels. The disconnect mechanism must be located in direct line of sight from the display it controls. This allows workers to keep the disconnect mechanism in view while performing display maintenance.

  • Page 21: Display Power Up

    To perform a display continuity check, follow the steps below: Remove the cover from the termination panel. Use an ohmmeter and place one probe on the neutral terminal and another probe to each of the taps on the breaker wire terminal. Repeat the same test for each breaker. Place one probe to the earth ground and one to each of the breaker wire terminals and repeat for each breaker.

  • Page 22: Plr Redundancy Testing

    PLR Redundancy Testing To test the PLR redundancy, use the contract-specific VIP-5160 Config Drawing to verify where the PLRs are located. Disconnect the fiber cable from Fiber Port A on the first PLR and verify all modules still display content correctly;...

  • Page 23: Maintenance & Troubleshooting

    TH-1202 Interconnects sections These tools are found in the toolkit (Daktronics part number 0A-1755-0001) attached to the top of the first shipping frame of each task/display face. Toolkits include other items not on this list, and additional replacement tools may be ordered directly from Daktronics. Refer to Section 5.2.

  • Page 24: Components

    Top-access displays allow a technician to access internal components from a platform on the rear of the section at the top of the display. The module pans slide vertically out of position, allowing access into the sections. Refer to Figure 38 and Figure 39. Module pan slides up Figure 38: Removing Front Modules...

  • Page 25: Video Image Processor

    Video Image Processor Figure 42 illustrates a Video Image Processor (VIP). A VIP is an interface that drives video to the display while also dimming, providing gamma and color controls, and displaying test patterns. Figure 42: VIP Refer to the DD2773152 VIP-5X6X Operator’s Manual for further information.

  • Page 26: Module Pan

    Disconnect power to the display. Use a " hex security bit (Daktronics part number TH-1170) to release the beverage shroud security latches. The beverage shroud may be left on in a flipped-up position or removed by rotating it up and unhooking the spring-loaded hinge pins.
  • Page 27 3. Clip one end of the module pan safety lanyard to the closest lift lug in the top perimeter and the other end into the handle of the module pan in need of service. Refer to Figure 49 and Figure 50. Figure 49: Lift Lug Figure 50: Module Pan Handle 4.

  • Page 28: Module

    Module RTX-11X1 Figure 53 and Figure 54 show front and rear views of an RTX-11X1 module. Figure 53: RTX-11X1 Module Front Figure 54: RTX-11X1 Module Rear To remove an RTX-11X1 module from a display, refer to Figure 55 while following the steps below: Figure 56: Accessing Module Latch Figure 55: Removing RTX-11X1 Module Disconnect power to the display.

  • Page 29: Rtx-1801

    3. Pull the module from the display just far enough to reach around to the back of the unit. 4. Attach one end of a safety lanyard to the rings on either the top or bottom of the module and the other end to a secure location within the display to prevent the module from falling if dropped.
  • Page 30 Disconnect power to the display. Access the module. Front access: Position the module access tool (Daktronics part number TH-1212) so the arrows on the handle point up. Use slight thumb pressure to insert the tool into the module until it clicks. Refer to Figure 60 and Figure 61.

  • Page 31: Prolink Router

    ProLink Router To remove a PLR from a display, follow the steps below: 1. Disconnect power to the display. Remove 2. Use a " hex security bit (Daktronics part number Hinge with Phillips TH-1170) to release the beverage shroud security screwdriver latches.
  • Page 32 This Page Intentionally Left Blank...

  • Page 33: Replacement Parts

    & return program. Exchange Program Daktronics unique Exchange Program is a quick service for replacing key parts in need of repair. If a part requires repair or replacement, Daktronics sends the customer a replacement, and the customer sends the defective part to Daktronics. This decreases display downtime.

  • Page 34: Repair & Return Program

    Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service.
  • Page 35 Glossary Lanyard Attachment Ring: a ring found on the back of each module. The lanyard attaches to the ring to keep the module from falling to the ground. Latch Release: a device that holds the module firmly to the display frame. There are two per module, one on the top and one on the bottom.
  • Page 36 This Page Intentionally Left Blank...

  • Page 37: Appendix A: Drawings

    Appendix A: Drawings Refer to Section 1.1 for information regarding how to read the drawing number. These drawings offer general information pertaining to most RTX displays and are listed in alphanumeric order. Any contract-specific drawings take precedence over the general drawings. Power Entrance;...
  • Page 38 This Page Intentionally Left Blank...

  • Page 39: Appendix B: Supplementary Documents

    IF POWER GOES LEFT, INSTALL W-2683 (39 IN-LBS) (IF NOT ALREADY INSTALLED) W-2683 WILL BE PULLED TO THE BUS HARNESS CONNECTION BOX IN FIRST COLUMN AND THE BUS HARNESS CONNECTION WILL BE MADE INSIDE OF THAT BOX FIELD TERMINATE AT THESE LOCATIONS OR ANY CORRESPONDING OPEN LOCATIONS FOR...
  • Page 42 THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE BROOKINGS, SD 57006 REMOVE ATTACHED FAN GUARD AND DISPOSE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. DO NOT SCALE DRAWING ATTACH FANS TO BOTTOM PLATE OF CABINET...
  • Page 43 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE BROOKINGS, SD 57006 EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. DO NOT SCALE DRAWING RTX A2 PROJ: LAYOUT;...
  • Page 44 DAKTRONICS, INC. THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. RTX A2 BLOCK DIAGRAM; RTX A2, 2-HIGH ACAMPBE...
  • Page 45 DAKTRONICS, INC. THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. RTX A2 BLOCK DIAGRAM; RTX A2, 3-HIGH ACAMPBE...
  • Page 46 DAKTRONICS, INC. THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. RTX A2 BLOCK DIAGRAM; RTX A2, 4-HIGH ACAMPBE...
  • Page 47 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE BROOKINGS, SD 57006 EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. DO NOT SCALE DRAWING RTX A2/B1...
  • Page 48 DAKTRONICS, INC. THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. RTX A2/B1 RTX-1XY1 SATA ROUTING OPTIONS ACAMPBE...
  • Page 49 DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS work performed on-site meets or WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. exceeds all local and national electric RTX A2 codes for wiring and specifcations.
  • Page 50 This Page Intentionally Left Blank...
  • Page 51 This section includes the following: DD1402020 Ribbon Board Cabinet Lifting Instructions Quick Guide • DD3246225 RTX-11X1/1801 Series Power Numbers • DD3246273 RTX-11X1/1801 Series Sectional Installation & Service Quick Guide • ED-14158 Face Cleaning Procedures for Daktronics LED Matrix Displays • Supplementary Documents...
  • Page 52 This Page Intentionally Left Blank...
  • Page 53 Note: Maximum fork center-to-center (c-c) spacing must not exceed 36 inches. Using a forklift for overhead lifting is acceptable only in crane-unloading configurations. Refer to Figure 1. DD1402020 Rev 2 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 12 March 2015 tel: 800-325-8766 fax: 605-697-4700...
  • Page 54 Note: Maximum fork center-to-center (c-c) spacing must not exceed 36 inches. Using a forklift for overhead lifting is acceptable only in crane-unloading configurations. Refer to Figure 3. DD1402020 Rev 2 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 12 March 2015 tel: 800-325-8766 fax: 605-697-4700...
  • Page 55 4x3 – 96x72 4x4 – 112x112 4x4 – 96x96 4x5 – 112x140 4x5 – 96x120 4x6 – 112x168 4x6 – 96x144 DD3246225 Rev 0 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 18 December 2015 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
  • Page 56 4x3 – 72x54 4x4 – 88x88 4x4 – 72x72 4x5 – 88x110 4x5 – 72x90 4x6 – 88x132 4x6 – 72x108 DD3246225 Rev 0 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 18 December 2015 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
  • Page 57 12.9 1545 4x5 – 144x180 1548 12.9 1545 4x6 – 180x270 1848 15.4 1853 4x6 – 144x216 1848 15.4 1853 DD3246225 Rev 0 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 18 December 2015 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
  • Page 58 4x3 – 96x72 4x4 – 96x96 1236 10.3 1236 4x5 – 96x120 1548 12.9 1545 4x6 – 96x144 1848 15.4 1853 DD3246225 Rev 0 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 18 December 2015 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
  • Page 59 Figure 10: Interconnecting Figure 2: Closed Beverage Shroud Figure 3: Open Beverage Shroud Sections Sections Figure 7: Rear Section Clips DD3246273 Rev 0 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 04 January 2016 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
  • Page 60 Figure 20: Setting Wing at hole located in the border. Appropriate Angle DD3246273 Rev 0 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 04 January 2016 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
  • Page 61 & Entrance (power) harness Coil (fiber) Sectional termination Coil (power) panel Figure 30: Fiber Cable Figure 31: Fiber Patch Panel DD3246273 Rev 0 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 04 January 2016 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
  • Page 62 Disconnect power to the display. Figure 42: Disconnected Cables Front access: Position the module access tool (Daktronics part number TH-1212) so the arrows on the handle point up. Use slight thumb Use a " hex security bit (Daktronics part number TH-1170) to release pressure to insert the tool into the module until it clicks.
  • Page 63 Face Cleaning LED Matrix Displays 1 of 4 This document outlines materials and methods used in cleaning Daktronics LED matrix displays. The procedures apply to all LED matrix screens, including Galaxy , HD-X, ProAd , ProStar , DVX, RTX, DBN, DVN, RTN, DB-4xxx, ®...
  • Page 64 Work from top to bottom safely within reach from a lift or a stage. Take care not to damage LEDs or the plastic louvers by catching the cloth on them. ED-14158 Rev 05 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006-5128 12 September 2014 tel 605-697-4000 or 800-325-8766 Fax 605-697-4700 www.daktronics.com...
  • Page 65 70% alcohol isopropyl rubbing alcohol (Figure 2) • High-performance microfiber cloth (Figure 3) Figure 2: Alcohol Figure 3: Microfiber Cloth ED-14158 Rev 05 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006-5128 12 September 2014 tel 605-697-4000 or 800-325-8766 Fax 605-697-4700 www.daktronics.com ® daktronics...
  • Page 66 Examine display and touch up areas as needed. Refer to Figure 7. Dirty Clean Module Module Figure 7: Touch Up ED-14158 Rev 05 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006-5128 12 September 2014 tel 605-697-4000 or 800-325-8766 Fax 605-697-4700 www.daktronics.com ® daktronics...

  • Page 67: Appendix C: Daktronics Warranty & Limitation Of Liability

    Appendix C: Daktronics Warranty & Limitation of Liability This section includes the Daktronics Warranty & Limitation of Liability statement. Daktronics Warranty & Limitation of Liability...
  • Page 68 This Page Intentionally Left Blank...
  • Page 69 DAKTRONICS WARRANTY & LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser and End User agree to be bound by and accept these terms and conditions. Unless otherwise defined herein, all terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
  • Page 70 In no event shall Daktronics be liable for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the Purchase Price of the Equipment. The End User’s remedy in any dispute under this Warranty shall be ultimately limited to the Purchase Price of the Equipment to the extent the Purchase Price has been paid.
