Summary of Contents for VOGE FR150
- Page 1 Far & Beyond Q uality MOTORCYCLE OPERATION MANUAL FR150...
- Page 2 This book is a part of the motorcycle, keep it always on the vehicle even sell or lend. VOGE...
-
Page 3: Table Of Contents
Content list Ⅰ ......1 Side stand and main stand ......25 .Issues need pay attention to Ⅱ.Safe driving . - Page 4 ......34 Maintenance plan ........59 Adjustment for clutch lever .
-
Page 5: Ⅰ.issues Need Pay Attention To
Ⅰ.Issues need pay attention to This user manual has the warning marks as below, when you saw it, please follow these driving and maintenance procedure. Danger This mark indicates it may lead to bad injury even death. Warning This mark indicates it may lead to damage on motorcycle. Caution This mark means more effective and convenient point for driving. -
Page 6: Ⅱ.safe Driving
Please always adopt origin VOGE parts or our authorized ones. The parts nor from VOGE factory, inco rrect accessories or loading are bad for motorcycle performance even break laws, please take responsibility for your safety and that of others. -
Page 7: Checking Before Driving
Checking before driving Before driving,make the inspections as below to reduce accident or damage: •Steering system •Transmission chain turning signal through switch assembly -Handle bar turns freely without Without too much abrasion or damage. can normally work. Oil pressure alarm jamming. -
Page 8: Issues Need Pay Attention To During Driving
Issues need pay attention to during driving 1.Any driver must know well about the motorcycle, the incorrect sitting position or off set during driving may be bad for operation or control of motorcycle; When driving, the passenger need. stably sit on his seat without influence driver. Passenger is an animal is not allowed. -
Page 9: Driving On Road
Driving on road •Get on the motorcycle from left side and ride on. •Pick up the side stand. • Get the motorcycle upright to the ground, get the handle bar face front, keep its wheel face forward. • Tightly hold the clutch lever. •... -
Page 10: Braking And Parking
Braking and parking •Please decelerate first when braking to reduce the speed and use the front and rear brake at same time. •When the driving speed is low enough, get into low gear position, and tightly hold clutch lever. • Get the engine into neutral gear, the motorcycle brakes and completely stops. -
Page 11: Ⅲ. Main Parameters
Ⅲ. Main parameters Motorcycle parameters Engine parameters Single cylinder/water cooling/4 valves LxWxH 1955mm×755mm×1120mm Engine type Wheelbase 1290mm Bore x Stroke 57.3mm×58mm Seat height 795mm Displacement 149.6ml Ground clearance 145mm Compression ratio 11.3:1 （0.012-0.18）mm Curb weight 123kg Clearance of air inlet valve （0.22-0.28）mm Max. -
Page 12: Ⅳ. Structure Of Motorcycle
Ⅳ. structure of motorcycle Identification for motorcycle The Vehicle Id entification Number (VIN), En gine type numbe r and Delivery number Vehicle Identification Number (VIN) Engine type and Delivery number... -
Page 13: Head Part
Head part 1.Left back-view mirror . 2 Left switch . 3 Meter . 4 Ignition switch . 5 Front brake oil cup . 6 Right switch assy. and accelerator base . 7 Right back-view mirror . 8 Front brake lever . -
Page 14: Left Side
Left side 1.Mirror,rear view 2.Fuel tank 3.Left side armrest 4.Taillight 5.Rear turn signal 6.License plate lamp 7.Left pillion step body 8.Main stand 9.Side stand 10.Left footrest body 11.Gear change pedal 12.Filling-up port of coolant tank 13.Left side reflector 14.High beam of headlight 15. -
Page 15: Right Side
Right side 1.Right side armrest . 2 Passenger seat . 3 Rear disc-brake oil cup . 4 Driver seat 5.Front turn light 6.Right side reflector 7.Front brake disk 8.ABS gear ring . 9 Front brake caliper 10 Oil filling-up port and oil gauge 11 Right footrest body 12 Right pillion step body... -
Page 16: Lower Side Of Seat
Lower side of seat 1.Starting relay . 2 Battery . 3 Interface of diagnosis device . 4 Fuse case . 5 Accessories tool... -
Page 17: Ⅴ.operation
Ⅴ.Operation Ignition switch The ignition switch locates at the right front of middle plate, which in the same piece with steering lock. This model equipped electric and mechanical keys 2 pieces each, in which one is for spare using, please well keep it in place. The ignition lock/steering lock/seat lock are all could be opened by electric key, the mechanical key is for the seat lock on the tail part of left body. -
Page 18: Instrument And Its Indicating Light
Instrument and its indicating light 1.Left turning indicator 2.Engine malfunction alarm 3.Neutral indicator . 4 Voltage malfunction alarm light . 5 High beam indicator light 6.Speed indicator 7.ABS malfunction alarm light 8.Right turning indicator . 9 Photoelectric sensor 10 Fuel meter and low level alarm 11.Metric/Imperial shift button 12. - Page 19 Turn the ignition button to position “ ”, the meter starts its self-inspection The display screen lights up and starts self-inspection, then show you the current status of vehicl e. Alarm light “ ” for engine malfunction got on and that “ ”...
- Page 20 In motorcycle driving, in case the indicating light “ ” goes on or flashing, please stop usin g, then contact the VOGE dealers. Alarm light “ ” for malfunction in ABS When there was malfunction in ABS system, its indicator light “...
- Page 21 High beam indicator light “ ” When pushed headlight switch on left switch assembly up, the indicator light “ ” got on. When pressed overtaking switch on left switch assembly, the indicator light “ ” got on until you released the switch. Oil pressure alarm light “...
- Page 22 Negative display meter Rotation speed: The rotation speed of engine. (r/min-rotation speed/minute – The current turning circles per minute for crankshaft) Gear position: The current gear position of engine (Not neutral gear position). Driving speed: The current running speed of vehicle. (km/h – kilometers/hour, or mph –...
- Page 23 Caution During driving, the fuel in its tank is easy to get waving, when the residual fuel is not much, it may cause the indicating bar flashing, which is normal, please don’t worry. When you found the alarm light for fuel got yellow, which means the residual fuel in tank is about 1.5L.
-
Page 24: Steering Set Switch
Steering set switch 1.Clutch lever 2.Overtaking switch 3.High beam switch 4.Emergency kill switch 5.Front brake lever . 6 Electrical kill switch 7.Emergency button . 8 Horn switch 9.Turning signal switch High beam switch When pushed high beam switch forward to position “ ”, the high beam got on, mean while its indicator light “... - Page 25 Button “ ” for horn When pressing “ ”,the horn rings. Turning signal light switch When push the turning signal light switch on left switch assy. to the left “ ” ,the turning signal light at left side both front and rear are all on, the indicating light “...
-
Page 26: Usb Power Supply Socket
Danger In case shift kill switch to position “ ” during driving, it may lead to rear wheel lock up even accident. Please don’t operate kill switch during driving. Electrical starting button “ ”, when pressed down button “ ”, the circuit of engine gets connected, then start engine. -
Page 27: Abs System
ABS system 1.Deceleration and braking under normal situation, release the throttle first, tightly hold the han dle bar and then brake. When driving speed fell, to avoid engine stop working, hold clutch lever to get into low gear p osition. 2.Decelerate before turning, when passing the turning, do everything possible to keep an even speed, in case it is needed, slightly brake, the sudden braking is forbidden. -
Page 28: Gearshift Device
Gearshift device This model equipped gearshift device with 6 gear positions, whose gearshift details are shown as below: Step down Kick up Gearshift pedal •The gearshift device makes engine stale work within normal rotation speed. •Gearshift ratio is carefully designed according to engine performance, the driver shall select the most suitable gear position, please don’t drive in high speed while in low gear position. -
Page 29: Side Stand And Main Stand
Side stand and main stand The design for this model includes main and side stand, please choose the correct one according to actual conditions. Rear brake pedal Step down rear brake pedal, the rear wheel brakes, while its indicating light gets on. Caution Warning When the side stand is working and holding the... -
Page 30: Engine Starting
Engine starting Check if the kill switch for engine is at position “ ”. Insert the key into ignition switch and turn to position “ ”. Confirm if the engine is in neutral gear, whose indicator light “N” on meter will get on. When all conditions above got ready, tightly hold clutch lever by left hand for ensuring safety, the right hand could press electric starting button “... -
Page 31: Fuel Filling-Up
Danger The exhasut gas of motorcycle has carbon monoxide, which is without color, smell, but poisonous. In the place without smooth ventilation or indoors, start engine for idling too long is not allowed , to avoid poisoning. Fuel filling-up This alarm light reminds you fuel filling-up Caution: In case the fuel is not enough, it leads to engine starting failure, or abnormal power out put, under this case, keep driving will damage fuel pump. -
Page 32: Ⅵ.malfunctions
In case alarm light for oil gets on, while oil level is correct, that means there may have some other causes. In case keep driving, these causes may damage engine. In case you confirm the light is on while oil level is correct, please don’t drive any more and stop. Please contact VOGE dealer immediately. -
Page 33: Too Hot The Coolant
Too hot the coolant This alarm light on means too high the coolant temperature. When the engine overheated, continue the driving may damage the engine, so please follow the instructions below. Stop driving and engine until the indicating light off. Check coolant and heat radiator when the mo torcycle completely cool down. -
Page 34: Engine Starting Failure
Incorrect check and adjustment may damage your motorcycle and let you fail to find out the malfunction, which can’t get the service of Quality Guarantee. In case you don’t know much about the correct operation, please conta ct the VOGE dealer. -
Page 35: Ⅶ.grinding-In
Ⅶ.Grinding-in Grinding-in for new motorcycle The grinding -in period is important to working life and fuel consumption, so before driving, read the User Manual carefully. (The correct driving within the first 1000km is good for motorcycle performance and bring you fun of driving. Grinding-in for engine •No matter the engine is hot or cold, before starting, idly start the engine for enough time, to let oil spread to all positions need lubrication. -
Page 36: Grinding-In For Tire
Grinding-in for tire • The surface of new tire is smooth, so it is dangerous to driving too fast or at turning. To get the strongest gripping force, the grinding-in is important. •In the first 200km, you can drive at turning in low speed until all angles of tire tread completely grinded-in. •The protrusion on tire tread is dangerous, the grinding is a good way for avoid protrusion on tire tread. -
Page 37: Ⅷ.adjsutment
Ⅷ.Adjsutment Adjustment for back-view mirror Adjust the back-view mirror to correct position according to your own stature and driving posture. The mirror body 1 and case 2 could adjust by hand directly. Warning Danger Sit on the motorcycle and keep it Adjust the back-view mirror upright, make sure you can clearly during driving may reduce your... -
Page 38: Adjustment For Clutch Lever
Adjustment for clutch lever •When engine started, in case need braking or gear shift, tightly hold clutch lever to let friction plates of clutch separate to cut off the power transmission from engine. •The free play at end of clutch lever shall be within 5-8mm, in case it is incorrect, please adjust as below: -Remove low beam kit -Loosen locking nut 1. -
Page 39: Adjustment For Rear Brake Pedal
•When re-assembled, repeatedly press and release brake pedal, while confirming you can clearly feel the pressing point. •In case pressing point failed to be felt, please contact VOGE dealer. •In case adjustment is not correct, the brake pad and plate are always under stress, which may lead to their damage. -
Page 40: Adjustment For Headlight Dimmer
- Turn clockwise the high beam, the lighting gets higher, anticlockwise is getting lower. Low beam adjusting view figure High beam adjusting view figure Danger In case you don’t know much about the height of light, please contact the VOGE dealer. -
Page 41: Adjustment For Transmission Chain
Adjustment for transmission chain ·Too tight or loose the chain are both incorrect. ·Too loose the chain, is easy to lead to it dropping off and accident. ·Too tight the chain is bad for its working life, meanwhile getting resistance force stronger. The correct tightness for chain is shown as picture: In case the tightness of chain on your vehicle fails to meet the 10~15(mm) -
Page 42: Ⅸ.check, Repair And Maintenance
Ⅸ.Check, repair and maintenance The fuel The fuel parameter when you purchasing the motorcycle is the most fuel saving way or under a fixed speed, which is quite different to your actual driving, which may be higher than the fuel parameter for reference only. •The operations below may decrease the fuel consumption under correct driving: –The driving shall be gentle, stable and without sudden braking as possible, the re-start and accel eration may use more fuel. -
Page 43: Tool Box
Tool box The tool kit is put in its bag under seat, open the seat first, at its bottom, the tool bag could be seen. When used under bad conditions such as driving in rainy day or washed vehicle, please make corresponding lubrications. Moving parts and their maintenance For safe driving, keep the good lubrication for moving parts is a necessary work for getting its working life longer. - Page 44 The power charge for battery In case the ignition lock is off, while the voltage of battery is lower than 12.6V, we suggest charge the battery. •Charge the battery by stable DC power source or use the suitable power charger and strictly follow its instruction. Danger •The DC charging voltage shall be DC (14.5±0.3)V with stable current no more than 1A;...
-
Page 45: External Power Supply
Disassembly and re-assembly for battery •Before the disassembly and re-assembly, turn off the ignition switch first. •Remove the negative terminal first when disassembling the battery, Warning then the positive one. •Install the positive terminal first when re-assembling, then the negative Don’t put the battery up side down, otherwise the one. -
Page 46: Maintenance For Air Filter
Maintenance for air filter •The air filter locates under fuel tank, if it is blocked by dust, the air inlet may get harder, which reduce power output and increase fuel consumption. •In case driving under dusty condition, clean up and replace the element more frequent. •The cleaning up and replacement for air filter element: Remove the seat -Remove the 8 pieces of screw on the cover of air filter case, pull it out as a complete... -
Page 47: Oil In Engine
Oil in engine Check the oil level ·The inspection for oil level and oil filling-up are both on the right side cover of engine as picture on the right shows. •The checking for oil level: –Do this work when the engine is cold. –Keep the motorcycle upright. - Page 48 •Outlet the oil: –In case too high the oil level, please remove the oil drainage bolt by socket wrench(The oil drainage bolt is shown as picture 1), in the middle at bottom of engine. –After releasing an appropriate amount of engine oil, please reset and lock the engine oil bolts.
- Page 49 Replacement for engine oil • Replace the engine oil when maintenance period reached. • Replace the oil when engine is hot to totally drain off the old oil. • The replacement for oil: –Keep the motorcycle upright by parking stand. –Turn the cap of oil filling-up port anticlockwise.
- Page 50 Oil filling up for engine ·The oil drainage bolt and gasket are replaced and assembled. ·Fill up with fresh oil from oil filling port, whose amount shall be 1300mL. ·Start engine and idly run it for minutes. ·Stop engine and wait for a minute, remove oil gauge and check oil level, when checking oil level, the vehicle must be kept horizontal to ground vertically, in case the oil level is under lower scale mark, please fill up with fresh oil to middle place between lower and upper scale line.
-
Page 51: Coolant
When the expansion tank is totally dried up, don’t fill up coolant by yourself, because under this case, the air may already get into the cooling system and need to be exhausted, so please contact the VOGE dealer for maintenance. - Page 52 The replacement for coolant •The coolant drainage: –Keep the motorcycle upright by standing rack. –Lay a liquid tray under the engine. –Remove the water drainage bolt, because all the heat radiation system is connected, so all the coolant may flow out from this port. –After the old coolant drained off, install and fasten the water drainage bolt in place.
- Page 53 •In case the air temperature is lower than the one marked up on the label, please adopt the coolant fits for lower temperature. • The VOGE coolant is with ice point of -45°C of glycol so we suggest purchase or replace by Made in VOGE. Caution To keep the coolant performance, replace each two years.
-
Page 54: Brake Liquid
In case the filling-up of brake liquid is needed, open the cap of oil cup by UPPER or MAX yourself may let air and moisture in, which largely reduce the braking LOWER or MIN performance even failure, so please contact VOGE dealer to do this work. The specification of brake liquid Caution •When there is impurity or moisture in the brake liquid, please filter or replace,... -
Page 55: Driving Chain
The driving chain for this model is the one with oil seal, the place of chain’s pin has a special oil seal for sealing lubricant, this chain is the one without opening, so in case replacement is needed, please contact VOGE dealer. -
Page 56: Tire
Tire The tire connects the motorcycle and ground, it is very important, the incorrect specification and status is very bad for motorcycle performance. The tire pressure in tire Danger •The wrong tire pressure makes its working life shorter. The incorrect tire pressure is not only bad for •... - Page 57 •Seal the contact position between the wheel rim and tire lip of tubeless tire. •To avoid air leakage, the tubeless tire needs special tool and machine for disassembly and re-assembly. •The tire replacement need be done by VOGE dealer, they are skillful and with necessary tools or ma chine.
-
Page 58: Fuse Chip
Fuse chip Before replacing fuse chip, please know well the root cause Fuse case and make troubleshooting. .This model adopt fuse case (1 piece) F1 fuse chip for power charging 25A .All the specification and usage of fuse chip are marked up. -Fuse chip for power charging (25A): Control power supply F2 fuse chip for ignition lock 15A when the vehicle is charging. - Page 59 Caution In case the fuse chip usually burns out in short time, which indicates there is malfunction in elec trical system, please contact the VOGE dealer immediately. Danger •Please use the fuse chip with given specification, substitution such as aluminum sheet or iron wire are not allowed.
-
Page 60: Brake Pad
The correct replacement needs to remove the Limit for front pad: Limit for rear pad: wheels, so this work shall be done by VOGE dealer. •No matter the front or rear brake pads, replace them in pairs as a set, in case only replace one piece of them, it may make imbalance brake even accident. -
Page 61: Replacement For Secondary Fuel Filter
Replacement for secondary fuel filter •The secondary fuel filter is for filtering the impurity in fuel and stop it getting into fuel injector. •The nozzle for fuel injector is a fine work, easy to be blocked by impurities, in case it is, the blocked fuel injector can not work and makes engine starting failure. -
Page 62: Replacement For Lighting Signal
Replacement for lighting signal If there is no light signal, you may be in danger, because the light helps others easily pay attention to you and your motorcycle. Please replace the broken lights. The headlight, front position light, turning signal light, rear position light, brake light and registration plate light are all LED and sealed, in case broken, go to the service station for replacement. -
Page 63: Maintenance Plan
Maintenance plan The table below shows you the inspection for each periodic maintenance, whose interval of time and mileage, set whom reached first as standard, and make the inspection as table below every time. Periodic maintenance table Items Interval km×1000 Lubricant Lubrication element Check lubricant level... - Page 64 Routine inspection for torque of key fastening parts Ref. No. Fastening position Thread Qty. Torque (N.m) Front wheel axle 40±5N.m Lower pump of front disc brake and front shock absorbers 40±5N.m Lower pump of rear disc brake and rear fork 26±4N.m Engine and frame (Rear lower suspension) 40±5N.m...
- Page 65 •After a long driving in sandy weather or muddy road, the special maintenance is necessary. •We suggest this kind of work shall be done by VOGE dealer. •Correctly dispose the abandoned materials such as cleanser or waste oil, don’t let them to be pollutions.
-
Page 66: Ⅹ. Maintenance For The Motorcycle In Long Parking
Storage for motorcycle •In case the motorcycle needs to park for a period without driving, the special maintenance is nece ssary, which need some special tools, equipment or technologies, because of this, we suggest these works shall be done by VOGE dealers. -
Page 67: Protection For Motorcycle
Protection for motorcycle •According to the daily driving, usually wash the motorcycle and keep it clean and dry. •Wash up the dirt, bird shit, asphalt or salt on motorcycle surface as quick as possible. •Try best to cover the motorcycle by dry cloth, long time exposed under sunshine may make covering parts get aged or color fading. -
Page 68: Xi. Electrical Diagram
XI. Electrical diagram Battery c athode ABS d iagnosis K ECU-BAT/ECU DiagnosisKline Brake s witch/Brake s ignal CAN c ommuni c ati o n w i r e l o w CAN c ommuni c ati o n w i r e h i g h Fr o nt w heel s peed s ensor p ower s our c e Rear w heel s peed s ensor s i g nal MOT-BAT I g ni t i o n s w i t c h ( P os i t i v e t e r m i n al a f t e r l o cked) Front w heel s peed s ensor s i g nal... - Page 69 Maintenance download Facebook Facebook www.vogeglobal.com...
