Graco MAGNUM XR Series Installation Instructions

Pump and gear/yoke replacement kits for airless sprayers

Download this manual

Installation Instructions

Important Safety Instructions

Read all warnings and instructions in this manual.

Save these instructions.

Pump and Gear/Yoke Replacement Kits for

XR Pump Replacement Kit 243533 and 245053

3000 psi (21 MPa, 207 bar)

XR Gear/Yoke Replacement Kit 243230 and 245062

WARNING

To reduce the risk of fluid injection or splashing in

the eyes or on the skin, relieve all fluid pressure in

the system before you install, remove, or replace

any parts. See the Pressure Relief Procedure in

the Operating Instructions manual 309225.

XR Series Airless Sprayers

GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441

Graco Inc. is registered to I.S. EN ISO 9001

309122 rev.E

This manual contains kit

installation instructions only.

To find your local

Graco/M

authorized

AGNUM

service center

D Call us at 1–888–541–9788

D Visit our website at

www.graco.com

Need help?

Do you have a question about the MAGNUM XR Series and is the answer not in the manual?

Page 1 See the Pressure Relief Procedure in the Operating Instructions manual 309225. GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 ECOPYRIGHT 2000, GRACO INC. Graco Inc. is registered to I.S. EN ISO 9001...
Page 2 Rod/Yoke Detail XR Pump Replacement Kit 243533 and 245053 o-rings eccentric bearing gear gear shaft yoke drive housing pump guide rods pump mounting pins cover pressure screw plastic washers control harness pressure control switch (not included with new pump in Kit 243533 or front cover 245053) Drive Train Detail...
Page 3 XR Pump Replacement Kit 243533 and 245053 CAUTION When repairing or cleaning the pump, never submerge the pump in water or allow fluid to enter the pressure control. Disassembly Installation D Read all Installation Notes in service drawing on 1. Thoroughly flush pump, if possible. facing page.
Page 4 All written and visual data contained in this document reflect the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. MM309122 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC.

243533245053243230245062
