Logic Pro; Cubase - Solid State Logic SSL UC1 User Manual

Product Overview & Features

Logic Pro

STEP 1: Go to Preferences > MIDI and select the Inputs tab. In this list, ensure that SSL V-MIDI Port 1 is ticked (presuming DAW
1 is being configured to drive the Transport). Versions of Logic preceding 10.5 may not have the 'Inputs' tab available. If so, you
can skip this step, as all MIDI ports are turned on by default.
STEP 2: Go to the Control Surfaces > Setup. Click New > Install... from the drop-down list in the top-left of the window. From this
list, choose Mackie Designs | Mackie Control | Logic Control and click the Add button. Click on the image of the Mackie Control
that has been added to the window and in the device setup options list on the left-hand side, configure the Output Port to SSL
V-MIDI Port 1 Destination and set the Input Port to SSL V-MIDI Port 1 Source.
STEP 3: In SSL 360° on the CONTROL SETUP page configure DAW 1 as Logic Pro from the dropdown list and also select DAW
1 (Logic Pro) in the TRANSPORT LINKED TO list below.
STEP 1 : Enable SSL V-MIDI Port 1 in Logic Pro.
STEP 3 : On the CONTROL SETUP tab, set DAW 1 to Logic Pro in DAW CONFIGURATION and also set
TRANSPORT LINED TO as DAW 1 (Logic Pro).
40
STEP 2: Add a Mackie Control and configure the Output
and Input Port to SSL V-MIDI Port 1.
SSL UC1 User Guide

Cubase

STEP 1: Open Cubase. Go to Studio > Studio Setup... Click the
+ symbol in the top-left of the window and select Mackie Control
from the drop-down list. Set the MIDI Input to SSL V-MIDI Port 1
Source and set MIDI Output to SSL V-MIDI Port 1 Destination.
Click Apply.
STEP 2: Next, go to Studio Setup > MIDI Port Setup and
deactivate (un-tick) the In 'ALL MIDI Inputs' option for your SSL
V-MIDI Ports and click OK. This will ensure that MIDI Instrument
Tracks set to receive from ALL MIDI Inputs do not pickup MIDI
data.
STEP 3: In SSL 360° on the CONTROL SETUP page configure
DAW 1 as Cubase from the drop-down list and also select DAW 1
(Cubase) in the TRANSPORT LINKED TO list below.
STEP 2 : Disable (un-tick) In 'ALL MIDI Inputs' for SSL V-MIDI Ports
STEP 3 : On the CONTROL SETUP tab, set DAW 1 to Cubase in DAW CONFIGURATION and also set TRANSPORT
LINED TO as DAW 1 (Cubase).
SSL UC1 User Guide
Product Overview & Features
STEP 1 : Go to Studio > Studio Setup. Add a Mackie
Control and configure the MIDI Input to SSL V-MIDI
Port 1 Source and MIDI Output to SSL V-MIDI Port 1
Destination.
41
