AirLive WN-151ARM User Manual

Wireless 11b/g/n 150mbps adsl2/2+ router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WN-151ARM
Wireless 11b/g/n 150Mbps
ADSL2/2+ Router
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WN-151ARM and is the answer not in the manual?

Questions and answers

Related Manuals for AirLive WN-151ARM

Summary of Contents for AirLive WN-151ARM

  • Page 1 WN-151ARM Wireless 11b/g/n 150Mbps ADSL2/2+ Router User’s Manual...
  • Page 2 OvisLink Corp. has made the best effort to ensure the accuracy of the information in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide. Please use with caution. All information is subject to change without notice All Trademarks are properties of their respective holders. AirLive WN-151ARM User’s Manual...

  • Page 3: Federal Communication Commission Interference Statement

    (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. AirLive WN-151ARM User’s Manual...
  • Page 4 United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland. EU Countries Not intended for use None. The specification is subject to change without notice. AirLive WN-151ARM User’s Manual...

  • Page 5: Table Of Contents

    Routing ............................85 Upgrade Firmware........................90 Modem Mode ......................... 91 Appendix A - Troubleshooting ....................97 Appendix B - Wireless LAN......................100 Appendix C - Specifications ...................... 104 Appendix D - Wireless Network Glossary ................107 AirLive WN-151ARM User’s Manual...

  • Page 6: Introduction

    Introduction Congratulations on the purchase of your new AirLive WN-151ARM. This device is an all-in-one device that combines the function of high-speed DSL modem, wireless-N access point and a single port Ethernet router. It supports the latest ADSL2+ standard and allows you to access the Internet and surf the Web at double the speed previously available through ADSL2.

  • Page 7: Features

    Shared Internet Access: • All users on the LAN or WLAN can access the Internet through the WN-151ARM, using only a single external IP Address. The local (invalid) IP Addresses are hidden from external sources. This process is called NAT (Network Address Translation).
  • Page 8 Define what data is recorded in the Logs, and optionally send log data to a Syslog Server. Log data can also be E-mailed to you. VPN Pass through Support: • PCs with VPN (Virtual Private Networking) software using PPTP, L2TP and IPSec are transparently supported - no configuration is required. AirLive WN-151ARM User’s Manual...
  • Page 9 WPS push button and the WPS will do the setup for you. WDS: • WDS (Wireless Distribution System) allows the Wireless Access Point to act as a Wireless Bridge. Both Point-to-Point and Multi-Point Bridge modes are supported. AirLive WN-151ARM User’s Manual...
  • Page 10 Restore (upload) a previously-saved configuration file from your personal computer to WN-151ARM. Remote Management. • The WN-151ARM can be managed from any PC on your LAN or Wireless LAN. And, if the Internet connection exists, it can also (optionally) be configured via the Internet. Network Diagnostics: •...
  • Page 11 Protection against DoS attacks: DoS (Denial of Service) attacks can flood your Internet connection with invalid packets and connection requests, using so much bandwidth and so many resources that Internet access becomes unavailable. The WN-151ARM incorporates protection against DoS attacks.

  • Page 12: Front Panel And Rear Panel

    Front Panel and Rear Panel Front-mounted LEDs AirLive WN-151ARM User’s Manual...
  • Page 13 WLAN (Blue) Wireless client is connected The wireless LAN is disabled or no wireless client is connected Wireless traffic is being Blinking transmitted/received Internet (Blue) Internet connection established No Internet connection Blinking Data is being transmitted/received AirLive WN-151ARM User’s Manual...
  • Page 14 No ADSL connection Blinking ADSL is synchronizing Push Button Push the WPS button on the device and your client device to perform WPS function which it can perform an easy way to create an encryption-secured wireless connection. AirLive WN-151ARM User’s Manual...

  • Page 15: Rear Panel

    Rear Panel AirLive WN-151ARM User’s Manual...
  • Page 16 To restore the factory default value, press and hold the Reset Button for five (5) seconds, until the Status LED is lit, then release the Reset Button and wait for it to reboot. Press and release to reboot the device. Power ON/OFF Push the button to switch power ON/OFF AirLive WN-151ARM User’s Manual...

  • Page 17: Packing List

    • 1 x 2dBi Dipole Antenna • Power Adapter When you open the package, make sure all of the above items are included. If there’s anything missing in the package, please contact your dealer of purchase. AirLive WN-151ARM User’s Manual...

  • Page 18: Installation

    TCP/IP protocol must be installed on all PCs • For Internet Access, an Internet Access account with an ISP, and a DSL connection. • To use the Wireless Access Point, all Wireless devices must be compliant with the IEEE 802.11b/g/n standard. Procedure AirLive WN-151ARM User’s Manual...
  • Page 19 Use standard LAN cables to connect PCs to the Switching ports on the WN-151ARM. Both 10BaseT and 100BaseT connections can be used simultaneously. 3. Connect ADSL Cable Connect the supplied ADSL cable from to the ADSL port on the WN-151ARM (the RJ11 connector) to the ADSL terminator provided by your phone company. 4. Power Up Connect the supplied power adapter to the WN-151ARM and plug into a power outlet.

  • Page 20: Setup

    Assigning a Password to protect the configuration data. Use the table below to locate detailed instructions for the required functions. To Do this: Refer to: Chapter 4: Check WN-151ARM operation and status. Operation and Status Use any of the following Advanced features: Chapter 5: •...
  • Page 21 The WN-151ARM must be properly setup and powered ON. • If the WN-151ARM's default IP Address (192.168.1.254) is already used by another device, the other device must be turned OFF until the WN-151ARM is allocated a new IP Address during configuration. AirLive WN-151ARM User’s Manual...
  • Page 22 1. After installing the WN-151ARM in your LAN, start your computer. If your computer is already running, restart it. 2. Start your WEB browser. 3. In the Address box, enter "HTTP://" and the IP Address of the WN-151ARM, as in this example, which uses the WN-151ARM's default IP Address: http://192.168.1.254 4.

  • Page 23: Setup Wizard

    Setup Wizard If this is the first time you connect to the WN-151ARM, it is recommended to run the Setup Wizard to configure the ADSL and Internet Connection. 1. Click the Setup Wizard link on the main menu 2. On the first screen, select Auto-detect or Manual Selection, then click "Next"...
  • Page 24 3. If Manual Selection is selected, you will see the VC 1 screen shown below. Enter the VPI and VCI values provided by your ISP, then click "Next". Figure: Setup Wizard - VC1 Figure: Setup Wizard - Internet Access AirLive WN-151ARM User’s Manual...
  • Page 25 6. On the final screen of the Wizard, run the test and check that an Internet connection can be established. 7. If the connection test fails: • Check all connections, and the front panel LEDs. • Make sure the data is input correctly. AirLive WN-151ARM User’s Manual...
  • Page 26 Use the menu bar on the left of the screen, and the "Back" button on your Browser, for navigation. • Changing to another screen without clicking "Save" does NOT save any changes you may have made. You must "Save" before changing screens or your data will be ignored. AirLive WN-151ARM User’s Manual...

  • Page 27: Lan Screen

    Figure 1: LAN Screen LAN Screen TCP/IP IP address for the WN-151ARM, as seen from the local LAN. Use the default IP Address value unless the address is already in use or your LAN is using a different IP address range. In the latter case, enter an unused IP Address from within the range used by your LAN.
  • Page 28 You can only use one (1) DHCP Server per LAN segment. If you wish to use another DHCP Server, rather than the WN-151ARM's, the following procedure is required. • Disable the DHCP Server feature in the WN-151ARM. This setting is on the LAN screen. • Configure the DHCP Server to provide the WN-151ARM's IP Address as the Default Gateway.

  • Page 29: Wireless Screen

    The WN-151ARM will automatically accept 802.11b, 11g and 11n connections without complicated settings. To change the WN-151ARM's default settings for the Wireless Access Point feature, use the Wireless link on the main menu to reach the Wireless screen. An example screen is shown below.
  • Page 30 Select the correct domain of your location. It is your responsibility to Region ensure: • That the WN-151ARM is only used in domains for which is licensed. • That you select the correct domain, so that only the legal channels for that domain can be selected.
  • Page 31 AP PIN Code Use the default displayed value or click the Regenerate button to regenerate new pin code. Enter the client’s PIN code in the field and click Input Client PIN Code OK to add the client device. AirLive WN-151ARM User’s Manual...
  • Page 32 Note: This function can only be available when client’s wireless card also supports WMM feature. Bandwidth Select the desired bandwidth from the list. Note: Do not modify the default value if you aren’t familiar with this function. AirLive WN-151ARM User’s Manual...
  • Page 33 WDS work properly, the access points must use the same channel, SSID, as well as the wireless encryption method. MAC Address List Enter the MAC address of the AP that you wish to build up the WDS connection. AirLive WN-151ARM User’s Manual...

  • Page 34: Wireless Security

    Each user must have a "user login" on the Radius Server. • Each user's wireless client must support 802.1x and provide the login data when required. • All data transmission is encrypted using the WPA standard. Keys are automatically generated, so no key input is required. AirLive WN-151ARM User’s Manual...
  • Page 35 Other stations must have the same key. Passphrase If desired, you can generate a key from a phrase, instead of entering the key value directly. Enter the desired phrase, and click the "Generate Keys" button. AirLive WN-151ARM User’s Manual...
  • Page 36 The PSK must be from 8 to 63 characters in length. Encryption The WPA-PSK standard allows different encryption methods to be used. Select the desired option. Wireless Stations must use the same encryption method. WPA2-PSK Wireless Security Figure: WPA2-PSK AirLive WN-151ARM User’s Manual...
  • Page 37 The PSK must be from 8 to 63 characters in length. Encryption The Mixed WPA-PSK/WAP2-PSK standard allows different encryption methods to be used. Select the desired option. Wireless client station must use the same encryption method. AirLive WN-151ARM User’s Manual...
  • Page 38 Enter the shared key. Data is encrypted using a key derived from the Shared Key network key. Other Wireless Stations must use the same key. The key must be from 8 to 63 characters in length. Encryption The encryption method is TKIP. Wireless Stations must also use TKIP. AirLive WN-151ARM User’s Manual...
  • Page 39 The name assigned to the Trusted Wireless Station. Use this when adding or editing a Trusted station. The MAC (physical) address of the Trusted wireless client station. Use Address this when adding or editing a Trusted client station. AirLive WN-151ARM User’s Manual...
  • Page 40 To add a Trusted Station which is not in the "Other Wireless Stations" list, Add (Update) enter the required data and click this button. When editing an existing Wireless Station, this button will change from Add to Update. Clear Clear the Name and Address fields. AirLive WN-151ARM User’s Manual...

  • Page 41: Password Screen

    You will be prompted for the password when you connect, as shown below. Figure: Password Dialog • The "User Name" is always admin • Enter the password for the WN-151ARM, as set on the Password screen above. AirLive WN-151ARM User’s Manual...

  • Page 42: Mode Screen

    (Since the modem is transparent, it does not examine the traffic to determine whether the traffic is for the LAN or the WAN.) • For details on using Modem Mode, see Chapter 8. AirLive WN-151ARM User’s Manual...

  • Page 43: Operation And Status

    Operation and Status Operation - Router Mode Once both the WN-151ARM and the computers are configured, operation is automatic. However, there are some situations where additional Internet configuration may be required. Refer to Chapter 6 - Advanced Features for further details.
  • Page 44 Operation - Router Mode Use the Status link on the main menu to view this screen. Figure: Status Screen AirLive WN-151ARM User’s Manual...
  • Page 45 The Network Mask (Subnet Mask) for the IP Address above. This shows the status of the DHCP Server function. The value will be DHCP Server "On" or "Off". MAC Address This shows the MAC Address for the WN-151ARM, as seen on the LAN interface. AirLive WN-151ARM User’s Manual...
  • Page 46 Click this button to open a sub-window and view a detailed description of Details the current connection. This will open a sub-window, showing all LAN and Wireless devices Attached Devices currently on the network. Refresh Screen Update the data displayed on screen. Help The description of Status item. AirLive WN-151ARM User’s Manual...
  • Page 47 Network Mask The Network Mask associated with the IP Address above. Buttons If not connected, establish a connection to your ISP. Connect Disconnect If connected to your ISP, hang up the connection. Close this window. Close AirLive WN-151ARM User’s Manual...
  • Page 48 If your access method is "Direct" (no login), with a Dynamic IP address, a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure: Connection Details - Fixed/Dynamic IP Address AirLive WN-151ARM User’s Manual...
  • Page 49 Lease Expires Buttons Release If an IP Address has been allocated to the WN-151ARM (by the ISP's DHCP Server), clicking the "Release" button will break the connection and release the IP Address. If the ISP's DHCP Server has NOT allocated an IP Address for the Renew WN-151ARM, clicking the "Renew"...
  • Page 50 The Subnet Mask associated with the IP Address above. Default The IP Address of the remote Gateway or Router associated with the IP Gateway Address above. The IP Address of the Domain Name Server which is currently used. DNS Server AirLive WN-151ARM User’s Manual...

  • Page 51: Advanced Features

    Advanced Features Overview The following advanced features are provided: • Internet: • • URL filter • Access Control • Dynamic DNS • Options • Schedule • Port Trigger • Port Foward • Port Range Forward • AirLive WN-151ARM User’s Manual...

  • Page 52: Internet

    DMZ host. Note: The DMZ host is effectively outside the Firewall, making it more vulnerable to be attacked. For this reason, you should only enable the DMZ feature when is necessary. AirLive WN-151ARM User’s Manual...
  • Page 53 Click the Configure URL Filter button to open the URL Filter screen and allows you to create or modify the filter strings which determine which sites to be blocked. The URL Filter screen is displayed when the Configure URL Filter button on the Advanced Internet screen is clicked. Figure: URL Filter Screen AirLive WN-151ARM User’s Manual...
  • Page 54 Visit Blocked Sties Internet. For this PC, the URL filter will be ignored. If enabled, you must select the PC to be the trusted PC. Trusted PC Enter the IP address and make it the Trusted PC. AirLive WN-151ARM User’s Manual...

  • Page 55: Access Control

    The Access Control feature allows administrators to restrict the level of Internet Access available to PCs on your LAN. With the default settings, everyone has unrestricted Internet access. Access Control Screen To view this screen, select the Access Control link on the Advanced menu. Figure: Access Control Screen AirLive WN-151ARM User’s Manual...
  • Page 56 If enabled, restrictions set on this screen do not apply to Trusted PCs. Trusted PC "Set Trusted Click this button to add or remove PCs of the Trusted PCs. PCs" Button See the following section for details of the Trusted PCs screen. AirLive WN-151ARM User’s Manual...
  • Page 57 The "Del >>" button will remove the selected PC (in the Trusted PCs list) from the current group. • The "<< Add" button will add the selected PC (in the Other PCs list) to the Trusted PCs group. AirLive WN-151ARM User’s Manual...

  • Page 58: Dynamic Dns

    2. After registration, use the Service provider's normal procedure to obtain your desired Domain name. 3. Enter your DDNS data on the WN-151ARM's DDNS screen, and enable the DDNS feature. 4. The WN-151ARM will then automatically ensure that your current IP Address is recorded at the DDNS service provider's Domain Name Server.
  • Page 59 This message is returned by the DDNS Server. • Normally, this message should be "Update successful" • If the message indicates some problem, you need to connect to the DDNS Service provider and correct this problem. AirLive WN-151ARM User’s Manual...

  • Page 60: Option

    Figure: Options Screen Options Screen Internet Respond to • If checked, the WN-151ARM will respond to Ping (ICMP) packets Ping received from the Internet. • If not checked, Ping (ICMP) packets from the Internet will be ignored. Disabling this option provides a slight increase in security.

  • Page 61: Schedule

    Schedule This Schedule can be used for the Firewall Rules and the URL filter. Figure: Schedule Screen AirLive WN-151ARM User’s Manual...
  • Page 62 "Use this NTP Server" and enter the Server's IP address in the Server fields provided. If this setting is not enabled, the default NTP Servers is used. Current Time This displays the current time on the WN-151ARM, at the time the page is loaded. AirLive WN-151ARM User’s Manual...

  • Page 63: Port Trigger

    If you use Internet applications which use non-standard connections or port numbers, you may find that they do not function correctly because they are blocked by the WN-151ARM's firewall. In this case, you can define the application as a "Port Trigger".
  • Page 64 If the application uses a single port number, enter it in both the "Start" and "Finish" fields. • Finish - Enter the end of the range of port numbers used by the application server, for data you receive. AirLive WN-151ARM User’s Manual...

  • Page 65: Port Forward

    LAN because: • Your Server does not have a valid external IP Address. • Attempts to connect to devices on your LAN are blocked by the firewall in this device. Figure: Port Forwarding Screen AirLive WN-151ARM User’s Manual...
  • Page 66 Enter the port numbers which the Server software is configured to use. Select the protocol (TCP or UDP) used by the Server. Protocol IP Address Enter the desired IP address. Enabled Use this to Enable or Disable support for this Server, as required. AirLive WN-151ARM User’s Manual...

  • Page 67: Port Range Forward

    Enter the end of the range of port numbers used by the application server. Protocol Select the protocol (TCP, UDP or Both) used by the Server. IP Address Enter the desired IP address. Enable Use this to Enable or Disable support for this Server, as required. AirLive WN-151ARM User’s Manual...

  • Page 68: Qos

    WAN Setting Enter the desired value for the DownStream Connection. DownStream Enter the desired value for the UpStream Connection. UpStream Get from WAN Click this button to get the values for DownStream and UpStream from WAN. AirLive WN-151ARM User’s Manual...
  • Page 69 Inbound Rate: Enter the desired rate value. • Priority: Select the desired option (High, Normal, Low) Summary The priority of the application. Priority The Name of this Application or IP Address. Name The general Information of this Application or IP Address. Information AirLive WN-151ARM User’s Manual...

  • Page 70: Administration

    Server". This database is maintained automatically, but you can add and delete entries for PCs which use a Fixed (Static) IP Address. Config File Backup or restore the configuration file for the WN-151ARM. This file contains all the configuration data. Logs & E-mail View or clear all logs, set E-Mailing of log files and alerts.

  • Page 71: Pc Database

    PCs which are "DHCP Clients" are automatically added to the database, and updated as required. • The WN-151ARM uses the "Hardware Address" to identify each PC, not the name or IP address. The "Hardware Address" can only change if you change the PC's network card or adapter.
  • Page 72 If the PC is not available (not connected, or not powered On) you will not be able to add it. Buttons Refresh Update the data on screen. Advanced View the Advanced version of the PC database screen. See below for details. AirLive WN-151ARM User’s Manual...
  • Page 73 Advanced PC Database Screen This screen is displayed if the "Advanced" button on the PC Database is clicked. It provides more control than the standard PC Database screen. Figure: PC Database - Advanced AirLive WN-151ARM User’s Manual...
  • Page 74 • DCHP Client - Reserved IP Address - Select this if the PC is set to be a DCHP client, and you wish to guarantee that the WN-151ARM will always allocate the same IP Address to this PC. Enter the required IP address. Only the last field is required; the other fields must match the WN-151ARM's IP address.
  • Page 75 Update (modify) the selected PC, using the data in the "Properties" box. Selected PC Clear the "Properties" box, ready for entering data for a new PC. Clear Form Refresh Update the data on screen. Click this to view the standard "PC Database" screen. Standard Screen AirLive WN-151ARM User’s Manual...

  • Page 76: Config File

    Config File This feature allows you to download the current settings from the WN-151ARM, and save them to a file on your PC. You can restore a previously-downloaded configuration file to the WN-151ARM, by uploading it to the WN-151ARM. This screen also allows you to set the WN-151ARM back to its factory default configuration. Any existing settings will be deleted.

  • Page 77: Logs

    Since only a limited amount of log data can be stored in the WN-151ARM, log data can also be E-mailed to your PC. Use the E-mail screen to configure this feature.
  • Page 78 Logs Screen Logs Current Time The current time on the WN-151ARM is displayed. Current log data is displayed in this panel. Log Data Buttons There are three (3) buttons • Refresh - Update the log data. • Clear Log - Clear the log, and restart it. This makes new messages easier to read.

  • Page 79: Email

    Enter the address or IP address of the SMTP (Simple Mail Transport Outgoing (SMTP) Mail Server Protocol) Server you use for outgoing E-mail. Mail Sender Enter the mail address of the sender. The E-mail will also show this Address address as the Sender's address. AirLive WN-151ARM User’s Manual...
  • Page 80 SMTP Server. E-mail Alerts Send E-mail alerts You can choose to have alerts E-mailed to you, by checking the desired checkboxes. The WN-151ARM can send an immediate alert when it immediately detects a significant security incident such as •...

  • Page 81: Diagnostics

    Diagnostics This screen allows you to perform a "Ping" or a "DNS lookup". These activities can be useful in solving network problems. An example Network Diagnostics screen is shown below. Figure: Network Diagnostics Screen AirLive WN-151ARM User’s Manual...
  • Page 82 After entering the Domain name/URL, click this button to start the "DNS Lookup Button Lookup" procedure. Routing Click this button to display the internal routing table. This information can be Display used by Technical Support and other staff who understand Routing Tables. AirLive WN-151ARM User’s Manual...

  • Page 83: Remote Administration

    Remote Administration If enabled, this feature allows you to manage the WN-151ARM via the Internet. Figure: Remote Administration Screen Remote Administration Screen Remote Administration Enable Remote Check to allow administration/management via the Internet. (To connect, see below). Management If Disabled, this device will ignore Administration connection attempts from the Internet.
  • Page 84 1. Ensure your Internet connection is established, and start your Web Browser. 2. In the "Address" bar, enter "http://" followed by the Internet IP Address of the WN-151ARM. If the port number is not 80, the port number is also required. (After the IP Address, enter ":" followed by the port number.)

  • Page 85: Routing

    You can ignore the Static Routing page if your network topology is constructed as following: • If your LAN has a standard Router (e.g. Cisco) on your LAN, and the WN-151ARM is to act as a Gateway for all LAN segments, you can enable RIP (Routing Information Protocol).
  • Page 86 • The other Routers must also be configured. See Configuring Other Routers on your LAN later in this chapter for further details and an example. Figure: Routing Screen AirLive WN-151ARM User’s Manual...
  • Page 87 Configuring Other Routers on your LAN It is essential that all IP packets for devices are not on the local LAN be passed to the WN-151ARM, so that they can be forwarded to the external LAN, WAN, or Internet. To achieve this, the local LAN must be configured to use the WN-151ARM as the Default Route or Default Gateway.
  • Page 88 Other Routers on the Local LAN Other routers on the local LAN must use the WN-151ARM's Local Router as the Default Route. The entries will be the same as the WN-151ARM's local router, with the exception of the Gateway IP Address.
  • Page 89 For the WN-151ARM's Routing Table For the LAN shown above, with 2 routers and 3 LAN segments, the WN-151ARM requires 2 entries as follows. Entry 1 (Segment 1) Destination IP Address 192.168.1.0 Network Mask 255.255.255.0 (Standard Class C) Gateway IP Address 192.168.0.100 (WN-151ARM's local...

  • Page 90: Upgrade Firmware

    Upgrade Firmware The firmware (software) in the WN-151ARM can be upgraded using your Web Browser. You must first download the upgrade file, then to select Upgrade Firmware on the Administration menu. You will see a screen like the following. Figure: Router Upgrade Screen To perform the Firmware Upgrade: 1.

  • Page 91: Modem Mode

    This Modem/AP must be a valid device on your LAN, to allow management connections. You must assign a (fixed) IP address which is within the address range used on your LAN, but not within the address range used by your DHCP server. AirLive WN-151ARM User’s Manual...
  • Page 92 When you connect in future, just connect normally, using the IP address you assigned. 1. Start your WEB browser. 2. In the Address box, enter "http://" and the current IP Address of the WN-151ARM as in this example, which uses the WN-151ARM 's default IP Address: http://192.168.1.254...
  • Page 93 Status - displays current settings and status. See the following section for details. • Binding - this screen is the same as in Router mode. Mode Screen This screen is change back to Router mode, if desired. Figure: Mode Screen AirLive WN-151ARM User’s Manual...
  • Page 94 The modem will act like any other ADSL modem. No routing will be performed, and no client login will be done. If a client login is required, it must be performed by your Router/Gateway or by software on your PC. AirLive WN-151ARM User’s Manual...

  • Page 95: Status Screen

    Status Screen In Modem mode, the Status screen looks like the example below. Figure: Status Screen - Bridge Mode AirLive WN-151ARM User’s Manual...
  • Page 96 The IP Address of the WN-151ARM. The Network Mask (Subnet Mask) for the IP Address above. Network Mask MAC Address This shows the MAC Address for the WN-151ARM, as seen on the LAN interface. Wireless SSID 1/2 If using an ESS (Extended Service Set, with multiple access points) this ID is called an ESSID (Extended Service Set Identifier).

  • Page 97: Appendix A - Troubleshooting

    This chapter covers some common problems that may be encountered while using the WN-151ARM and some possible solutions to them. If you follow the suggested steps and the WN-151ARM still does not function properly, contact your dealer for further advice.
  • Page 98 • If the PCs are configured correctly, but still not working, check the WN-151ARM. Ensure that it is connected and ON. Connect to it and check its settings. (If you can't connect to it, check the LAN and power connections.) •...
  • Page 99 Remember that the SSID is case-sensitive. So, for example "Workgroup" does NOT match "workgroup". • Both your PC and the WN-151ARM must have the same setting for WEP. The default setting for the WN-151ARM is disabled, so your wireless station should also have WEP disabled.

  • Page 100: Appendix B - Wireless Lan

    As Wireless Stations are physically moved through the area covered by an ESS, they will automatically change to the Access Point which has the least interference or best performance. This capability is called Roaming. (Access Points do not have or require Roaming capabilities.) AirLive WN-151ARM User’s Manual...
  • Page 101 If WEP is used, the Wireless Stations and the Access Point must have the same settings for each of the following: Off, 64 Bit, 128 Bit For 64 Bit encryption, the Key value must match. For 128 Bit encryption, the Key value must match WEP Authentication Open System or Shared Key. AirLive WN-151ARM User’s Manual...
  • Page 102 PSK must be from 8 to 63 characters in length. The (Pre-shared Key) 256Bit key used for the actual encryption is derived from this key. Encryption The same encryption method must be used. The most common encryption method is TKIP. Another widely-supported method is AES. AirLive WN-151ARM User’s Manual...
  • Page 103 "any" or null (blank) to allow connection to any Access Point. Wireless The Wireless Stations and the Access Point must use the same Security settings for Wireless security. (None, WEP, WPA-PSK, WPA2-PSK, WPA-802.1x). AirLive WN-151ARM User’s Manual...

  • Page 104: Appendix C - Specifications

    ITU G.992.5 Annex M Multi-Mode code support ANSI T1413 support General WAN port: 1 x RJ11 ADSL line LAN port: 1 x RJ45 10/100Mbps Auto MDI/MDI-X Flash: 4MB Memory: 16MB SDRAM Certifications: CE Mark, FCC Class B, RoHS AirLive WN-151ARM User’s Manual...
  • Page 105 802.11b: Direct Sequence Spread Spectrum (DSSS): DBPSK, DQPSK, CCK 802.11g: Orthogonal Frequency Division Multiplexing (OFDM): BPSK, QPSK, 16QAM, 64QAM 802.11n: Orthogonal Frequency Division Multiplexing (OFDM): BPSK, QPSK, 16QAM, 64QAM Channels: USA & Canada: 11 channels Europe: 13 channels AirLive WN-151ARM User’s Manual...
  • Page 106 Power (Orange) LAN (Blue) Wireless (Blue) Internet (Blue) ADSL (Green) Environmental Dimensions: 145(W) x 120(D) x 34(H) mm Product weight: Operating temperature: 0~40°C Operating humidity: 0~85% (Non-Condensing) Storage temperature: -20~60°C Power External power adapter: 12V DC, 1A AirLive WN-151ARM User’s Manual...

  • Page 107: Appendix D - Wireless Network Glossary

    This IEEE standard define the TPC (transmission power control) and DFS (dynamic frequency selection) required to operate WiFi devices in 5GHz for EU. 802.11i The IEEE standard for wireless security, 802.11i standard includes TKIP, CCMP, and AES encryption to improve wireless security. It is also know as WPA2. AirLive WN-151ARM User’s Manual...
  • Page 108 Instead, wireless client are connected directly to each other. The disadvantage of Adhoc network is the lack of wired interface to Internet connections. It is not recommended for network more than 2 nodes. AirLive WN-151ARM User’s Manual...
  • Page 109 For wireless application, there are 2 types of Bridges. WDS Bridge can be used in Point-to-Point or Point-to-Multipoint topology. Bridge Infrastructure works with AP mode to form a star topology. AirLive WN-151ARM User’s Manual...
  • Page 110 When DHCP is used, whenever a computer logs onto the network, it automatically gets an IP address assigned to it by DHCP server. A DHCP server can either be a designated PC on the network or another network device, such as a router. AirLive WN-151ARM User’s Manual...
  • Page 111 Domain Name The unique name that identifies an Internet site. Domain Names always have 2 or more parts, separated by dots. In www.airlive.com, the "airlive.com" is the doman name. DoS Attack Denial of Service. A type of network attack that floods the network with useless traffic. Many DoS attacks, such as the Ping of Death and Teardrop attacks, exploit limitations in the TCP/IP protocols.
  • Page 112 Infrastructure Mode A wireless network that is built around one or more access points to provide wireless clients access to wired LAN / Internet service. The opposite of Infrastructure mode is Ad-hoc mode. AirLive WN-151ARM User’s Manual...
  • Page 113 A Smart Antenna technology designed to increase the coverage and performance of a WLAN network. In a MIMO device, 2 or more antennas are used to increase the receiver sensitivity and to focus available power at intended Rx. AirLive WN-151ARM User’s Manual...
  • Page 114 Point-to- Point Protocol over Ethernet. PPPoE relies on two widely accepted standards: PPP and Ethernet. PPPoE is a specification for connecting the users on an Ethernet to the Internet through a common broadband medium, such as a single DSL line, wireless device or cable modem. AirLive WN-151ARM User’s Manual...
  • Page 115 An IP sharing router is a device that allows multiple PCs to share one single broadband connection using NAT technology. A wireless router is a device that combines the functions of wireless Access Point and the IP sharing router. AirLive WN-151ARM User’s Manual...
  • Page 116 The browser then sends a randomly generated secret key back to the server in order to have a secret key exchange for that session. SSL VPN is also known as Web VPN. The HTTPS and SSH management interface use SSL for data encryption. AirLive WN-151ARM User’s Manual...
  • Page 117 TX output power level limit for 2.4GHz 11g/b is 20dBm at the antenna end. The output power limit for 5GHz 802.11a is 30dBm at the antenna end. UDP (User Datagram Protocol) A layer-4 network protocol for transmitting data which does not require acknowledgement from the recipient of the data. AirLive WN-151ARM User’s Manual...
  • Page 118 WPA (Wi-Fi Protected Access) It is an encryption standard proposed by WiFi for advance protection by utilizing a password key (TKIP) or certificate. It is more secure than WEP encryption. The WPA-PSK utilizes pre-share key for encryption/authentication. AirLive WN-151ARM User’s Manual...
  • Page 119 WMM is a standard to prioritize traffic for multimedia applications. The WMM prioritize traffic\ on Voice-over-IP (VoIP), audio, video, and streaming media as well as traditional IP data over the AP. WMS (Wireless Management System) One of the utility programs that uses to manage multiple wireless AP/Bridges. AirLive WN-151ARM User’s Manual...
