9.3.2 EP00047 and EP00051

Figure 31: Printed Circuit Board (PCB)

Bus A
J22 120 Ohm
RS485_2_TX+ (1-2)
J26 120 Ohm
RS485_2_RX+
J25 RS485_2_RX+ (4w:2-3,
2w:1-2)
J28 RS485_2_RX- (4w:2-3) J38
J14 RS485_2 (3-5, 4-6)
UM-6007, Rev. 2.2, 2024/07/17
Copyright ADB Safegate, All Rights Reserved
©
Bus B
J32 120 Ohm
RS485_1_TX+
J36 120 Ohm
RS485_1_RX+
J35 RS485_1_RX+
(4w:2-3)
RS485_1_RX- (4w:2-3)
J13 RS485_1 (3-5, 4-6)
CAN
J3 120 Ohm CAN (1-2)
μProc
J16 Boot-GND (2-3)
