4.2

ATTACH THE GUARD

Figure 2.
WARNING
Do not touch the cut-off blade.
1. Remove the screws from the trimmer head with a
Phillips head screwdriver (not included).
2. Put the guard onto the trimmer head.
3. Align the screw holes on the guard with the screw
holes on the trimmer head.
4. Tighten the screws.
4.3

ASSEMBLE THE SHAFT

Figure 3 - 5.
1. Loosen the screw on the coupler.
2. Push in the release button on the lower shaft.
3. Align the release button with the positioning hole
and slide the two shafts.
4. Turn the lower shaft until the button locks into the
positioning hole.
The release button must be fixed in the positioning
hole. Using the wrong hole could lead to personal
injury, or damage to the unit.
5. Tighten the screw with the hex wrench.
4.4

ATTACH THE AUXILIARY HANDLE

Figure 6.
1. Loosen the central knob.
2. Remove the cap and the lower support.
Do not miss the spring in the support.
3. Put the auxiliary handle in the lower support.
4. Put the cap to the lower support.
5. Put the entire block in its housing on the shaft.
6. Set the auxiliary handle in the comfortable
position.
7. Lock the auxiliary handle with the central knob.
4.5

USE THE SHOULDER STRAP

Figure 7 - 8.
1. Attach the carabiner to the carrying ring on the
tool.
2. Put on the shoulder strap.
3. Adjust the length of the strap so that the
carabiner is about the width of a hand below your
right hip.
English
NOTE
NOTE
5

OPERATION

Before you operate the machine, read and
understand the safety regulations and the operation
instructions.
Be careful when you operate the machine.
5.1

INSTALL THE BATTERY PACKS

Figure 9.
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the engine stops
before you install or remove the battery packs.
• Use only 24V battery packs. Do not use dual-
voltage 24/48V battery packs.
• Both battery packs should be installed in the
compartments in order to start the machine.
1. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
2. Push the battery pack into the battery
compartment until the battery pack locks into
place.
3. When you hear a click, the battery pack is
installed.
4. Do the same operation with the other battery
pack.
Optimize the power and performance of your
new 2x24V machine by running with both battery
packs charged to 100%. If each battery has
a different charge state, the run-time of the
machine is subject to the lowest powered battery
(For example: one battery is charged 100%, and
the other is charged 50%, the unit will only run
until the 50% battery is depleted).
5.2

REMOVE THE BATTERY PACKS

Figure 9.
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
3. Do the same operation with the other battery
pack.
5
IMPORTANT
WARNING
WARNING
NOTE
EN
