EN
5.3

ON/OFF BUTTON

Push this button to turn power on and off for the
machine.
Green light on: the electrical circuit of the machine is
ON. The machine prepares to operate.
If you do not use the machine for more than 2
minutes, the machine will turn off.
Lights off: the electrical circuit is OFF.
Do not keep your finger on the button when you
move the machine to prevent accidental start.
5.4

SPEED BUTTON

Push this button to increase cutting speed according to
grass conditions.
Two green lights on: the machine is in "high speed"
settings.
5.5

START THE MACHINE

Figure 10.
1. Push the on/off button.
2. Push the lock-out button and pull the trigger.
3. Push the speed button to adjust the speed
according to the grass condition.
5.6

STOP THE MACHINE

Figure 10.
1. Release the trigger to stop the machine.
5.7

OPERATION TIPS

Figure 11.
Keep clearance between the body and the machine.
Do not operate the machine without guard in place.
Follow these tips when you use the machine:
NOTE
IMPORTANT
WARNING
WARNING
English
• Keep the machine connected to the correctly worn
harness.
• Keep a firm hold with both hands on the machine
while you operate the machine.
• Cut tall grass from the top down.
If grass winds around the trimmer head:
• First, remove the battery pack(s).
• Then, remove the grass.
5.8

CUTTING TIPS

Figure 12.
• Tilt the machine towards the area to be cut. Use the
tip of the cutting line to cut grass.
• Move the machine from right to left to prevent
thrown debris toward the operator.
• Do not cut in dangerous areas.
• Do not force the trimmer head into uncut grass.
• Wire and picket fences cause cutting line wear and
breakage. Stone and brick walls, curbs, and wood
can wear the cutting line quickly.
5.9 ADJUST THE LENGTH OF THE CUTTING
LINE
Figure 13.
While you operate the machine, the cutting line gets
worn and shorter. You can adjust the length of the
cutting line.
1. Hit the trimmer head against the ground while you
operate the machine.
2. Line is automatically released and the cut-off
blade cuts the excess length.
5.10

LINE CUT-OFF BLADE

Figure 14.
This trimmer is equipped with a line cut-off blade
on the guard. The line cut off blade continuously
trims the line to ensure a consistent and efficient cut
diameter. Advance line whenever you hear the engine
running faster than normal, or when trimming efficiency
diminishes. This will maintain best performance and
keep the line long enough to advance properly.
5.11

ADJUST THE CUTTING DIAMETER

Figure 14.
The machine is set at a 330 mm cutting diameter.
You can adjust to a 381 mm cutting diameter.
Set the cutting diameter to 330 mm for greater
runtime and 381 mmfor a larger cutting area.
1. Remove the battery pack(s).
6
NOTE
