EN
1

DESCRIPTION

1.1

PURPOSE

This machine is used to cut grass, light weeds, and
other similar vegetation at or around ground level. The
cutting plane must be approximately parallel to the
ground surface. You cannot use the machine to cut or
chop hedges, shrubs, bushes, flowers and compost.
1.2

OVERVIEW

Figure 1 - 35.
On/off button
1
Speed button
2
Lock-out button
3
Trigger
4
Auxiliary handle
5
Upper shaft
6
Coupler
7
Lower shaft
8
Trimmer head
9
Cut-off blade
10
Guard
11
Brush cutter blade
12
Release button
13
Positioning hole
14
Hex wrench
15
Central knob
16
Cap
17
Lower support
18
Spring
19
Carabiner
20
Carrying ring
21
Battery release button
22
Tab
23
Spool cover
24
Screws
25
Spool
26
Slot cover
27
Location housing
28
Slots
29
Metal rod
30
Angle transmission hole
31
Inner ring-nut
32
Gear box
33
Inner cup
34
Outer cup
35
English
Locknut
36
Wrench
37
Direction of rotation
A
Best cutting area
B
Dangerous cutting area
C
2 GENERAL POWER TOOL SAFETY
WARNINGS
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
3

SAFETY

Make sure that you follow all safety instructions.
Refer to Safety Manual.
4

INSTALLATION

4.1

UNPACK THE MACHINE

Make sure that you correctly assemble the machine
before use.
• If parts of the machine are damaged, do not use
the machine.
• If parts are missing, do not operate the machine.
• If parts are damaged or missing, contact the
service center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in
compliance with local regulations.
For your personal safety, do not insert battery before
the tool is assembled completely.
4
WARNING
WARNING
WARNING
WARNING
WARNING
