OUTBACK® GABLE PATIO SUNROOF
The New Generation Outback® Gable Patio system has been designed and engineered to generate modern and versatile structures
that provide more design flexibility and increased spanning capabilities.
The New Generation Outback® Gable Patio system integrates new bracketry, new fixings, new design options and new accessories, to
produce the best gable patio product on the market today.
This product has been designed with D.I.Y in mind for ease of installation.
BEFORE YOU START
It is important to check your Local Government Authority requirements before the installation of your new Stratco Outback® Gable
Patio System.
It is the builder's responsibility to ensure any existing structure that an Outback® Gable Patio is being attached to is adequately
reinforced to accommodate the additional loads imposed by the verandah, patio or carport. Read these instructions thoroughly before
starting your project and refer to them constantly during each stage of construction. Contact Stratco for advice if you do not have the
necessary tools or information.
Carefully read these instructions, along with the 'Outback Gable Installation Guide'. Lay out the main components in order of
assembly on the ground and check them against the delivery note. The 'Components' section identifies each part of your Stratco
Outback Gable Sunroof Bank and shows the location of the components.
If you do not have all the necessary tools or information, contact Stratco for advice. Before starting lay out all components
and check them against the delivery docket. The parts description identifies additional gable parts, and the component layout
diagram indicates their fastening position.
TOOLS AND HARDWARE REQUIRED
• Tape Measure
• Marker or Pen
• Spirit Level
• String Line
• Plumb Line
• Hack Saw
• Tin Snips
OUTBACK
• Angle Grinder
• Post-Hole Digger
• Drill
• 5/16" Hex-Head Driver
• 3/8" Hex-Head Driver
• T30 Torx Driver
• ø3.2mm Drill Bit
GABLE SUNROOF
®
VERANDAH | PATIO | CARPORT - INSTALLATION GUIDE
• ø5.0mm Drill Bit
• ø12mm Drill Bit
• ø16mm Drill Bit
• ø12mm Masonry Drill Bit
• Rivet Gun
• Silicone Gun
• Clamps
• Spanners or Hex-Head
Socket Set
• Adjustable Construction
Props
• Ladders

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Outback Gable and is the answer not in the manual?

Questions and answers

Related Manuals for Stratco Outback Gable

Summary of Contents for Stratco Outback Gable

  • Page 1 Read these instructions thoroughly before starting your project and refer to them constantly during each stage of construction. Contact Stratco for advice if you do not have the necessary tools or information.

  • Page 2: Table Of Contents

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® CONTENTS Adjusting the Closed Louvre Position ........15 Louvres Are Not Fully Closed ...........15 1 - FRAMEWORK PREPARATION Louvres Are Closed Too Tightly ..........15 Rear Attached ................3 Side Attached .................3 6 - RAFTER FLASHING INSTALLATION Rafter Preparation .................3 Side Capping Preparation (Cooldek CGI &...

  • Page 3: Framework Preparation

    Side Beam Centre of Hole SIDE ATTACHED (BEAM CAP LARGE) Where the Outback Gable Patio is attached along the Side Beam that includes a Sunroof Bank, consideration must be given to the position of the attachment fixings. 90mm...

  • Page 4: Gutter Installation

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® GUTTER INSTALLATION Notes: Maintain protective covering on gutters until it is necessary to remove. Layout gutters in relative position to each other prior to 30mm Tag marking. Fold 90° Gutters will share fixings with Louvre Extrusions, Rafter Knuckles, Rafter to Beam Brackets.

  • Page 5: Side Gutter Preparation (Upper End)

    Bottom Gutter Side Gutter (Lower End) Rafter Beam Capping Side Beam FIGURE 2.5 Bottom Gutter FIGURE 2.3 Remove any protective covering from the Side Gutters. Position Side Gutters on each rafter, overlapping the lower SIDE GUTTER PREPARATION (UPPER END) end into the Bottom Gutter mitre (Figure 2.6). Measure the distance between the outside face of the Ridge-to-Rafter Bracket to the back face of the Rafter-to- Beam Bracket (Figure 2.4).

  • Page 6: Louvre Extrusion Installation

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® LOUVRE EXTRUSION INSTALLATION LOUVRE EXTRUSION IDENTIFICATION The Top and Bottom Louvre Extrusions come at a standard Type 1 is the mirror image of Type 2. Each can be identified by 3 metre length. They have square holes in the front face the small round holes at the ‘non-fixed’...

  • Page 7: Louvre Extrusion Preparation (Sunroof Banks Over 3 Metres)

    LOUVRE EXTRUSION PREPARATION (SUNROOF BANKS OVER 3 METRES) If the Sunroof Bank is longer than three metres in length, must butt together. When butted together correctly, the additional Louvre Extrusions will be required. Where a Type Louvre Extrusions will have a spacing of 178mm between 1 Louvre Extrusion is used at the fixed end, a Type 2 Louvre the square holes (Figure 3.3 &...

  • Page 8: Side Beam Preparation (Small Beam Cap)

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® SIDE BEAM PREPARATION (LARGE BEAM CAP) SIDE BEAM PREPARATION (SMALL BEAM CAP) Once all gutters are in place, position the Bottom Louvre Once all gutters are in place, position the Bottom Louvre Extrusion(s) and Mounting Support Flashing(s) (Figure 3.7). Extrusion(s) and Mounting Support Flashing(s) (Figure 3.5).

  • Page 9: Top Louvre Extrusion (Louvre Bank On Both Sides Of Ridge Beam)

    TOP LOUVRE EXTRUSION Ridge Extrusion (LOUVRE BANK ON BOTH SIDES OF RIDGE BEAM) Position the Aluminium Flat Bar atop the Ridge Beam, on top Keep this side of the Top Gutters. Position the Top Louvre Extrusions on top of the Aluminium Flat Bar (Figure 3.9). Cut Line Aluminium Flat Bar FIGURE 3.11...

  • Page 10: Downpipe Outlet Installation

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® DOWNPIPE OUTLET INSTALLATION Cut an opening in the lower corner of the gutter to fit the Drill four ø3.5mm holes and fasten in-place using four rivets size of your specific downpipe outlet. Position the outlet (Figure 3.14 &...

  • Page 11: Louvre Installation

    LOUVRE INSTALLATION END CAP BUSH INSTALLATION Insert End Cap Bushes into each of the square Louvre Extrusion Mounting Holes (Figure 4.0). Using a rubber mallet, tap the bushes into position. Spring Top Louvre Extrusion Spring Bush End Cap Bush Spring with Spring Bush Louvre Blade with End Caps Bottom Louvre Extrusion...

  • Page 12: Using The Remote Control

    LH or RH Actuator kit is provided. Thread the M16 nut on to the end of the Adjustment Bolt The appropriate orientation has been determined by Stratco, so the nut is approximately 20mm in from the end of the based on the opening direction of the Louvres relative to the Adjustment Bolt (Figure 5.2 or 5.3).

  • Page 13: Installing Actuator

    Outback Self-Drilling Screws Thread Nut approx. 20mm 90° on to Bolt Bottom Louvre Extrusion Actuator Outback Cover Circular cut-out with Self-Drilling the flat edge facing up Screws Locate lip centrally between End Cap Bushes FIGURE 5.4 RUNNING ACTUATOR CABLES M16 Nut Note: The Control Box must be unplugged from the mains power.

  • Page 14: Link Rod Preparation

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® LINK ROD PREPARATION The Link Pins should push in and snap fit into place. Repeat this process for the remaining Louvres. Lay the Link Rods on the ground, taking care not to bend them. The short angle should be facing upwards. Leave two holes without Pins at the Drive Arm location.

  • Page 15: Adjusting The Closed Louvre Position

    ADJUSTING THE CLOSED LOUVRE POSITION LOUVRES ARE CLOSED TOO TIGHTLY If the Louvres have over closed, the Link Rod can be seen to Use the Remote Control to drive the Louvres until they are significantly deflect. in the closed position by pressing the ‘Close’ button and allowing the unit to fully close.

  • Page 16: Rafter Flashing Installation

    GABLE SUNROOF INSTALLATION GUIDE ® RAFTER FLASHING INSTALLATION Select the appropriate installation section relative to the configuration of the Outback Gable Patio. SIDE CAPPING PREPARATION (COOLDEK CGI & COOLDEK CLASSIC) The Cooldek Side Capping will cover adjacent Cooldek and must be trimmed to allow it to fit over the Beam Cap at the Side Beam end and parallel with the Ridge Beam at the opposing end.

  • Page 17: Side Capping Preparation (Cgi)

    Fix through the internal face of the Side Capping to the Fix Through the top face of the Side Capping into the crest Side Gutter and Rafter using Outback Self-Drilling Screws at of Cooldek using 12g x 20mm hex head self-drilling screws 500mm centres (Figure 6.3 &...

  • Page 18: Rafter Flashing Preparation (Outback Deck)

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® Measure and mark out trim lines as shown in (Figure 6.6). Fix through the internal face of the Side Capping to the Side Gutter and Rafter using Outback Self-Drilling Screws Using tin snips, trim marked out lines. at 500mm centres (Figure 6.7).

  • Page 19: End Rafter Flashing Installation

    Measure and mark out trim lines as shown in (Figure 6.9). Fix through the internal face of the Rafter Flashing to the Side Gutter and Rafter using Outback Self-Drilling Screws Using tin snips, trim marked out lines. at 500mm centres (Figure 6.10). Fix Through the rear lip of the Rafter Flashing into the Rafter using 12g x 20mm hex Slide Rafter Flashing Side Capping into position between the head self-drilling screws with neoprene washers at 500mm...

  • Page 20: Beam Cap Flashing Installation

    BEAM CAP FLASHING INSTALLATION Self-Drilling Screws with neoprene washers at (ADJACENT COOLDEK CGI & COOLDEK CLASSIC) 500mm centres Note: Install Edge Gutter to Outback Gable Patio before Cover Flashing completing this step. Bottom Louvre Extrusion Hook the Cover Flashing (Cutback) over lip of the Cutback Flashing.

  • Page 21: Ridge Capping Installation

    RIDGE CAP FLASHING INSTALLATION 12g x 20mm Hex Head Self-Drilling Screws with Select the appropriate installation section relative to the neoprene washers at configuration of the Outback Gable Patio. 500mm centres Ridge Cap (Sunroof/CGI) RIDGE CAPPING INSTALLING (LOUVRE BANK ON BOTH SIDES OF RIDGE BEAM) Place the Ridge Cap centrally over the ridge so that it rests flat on either side of the Top Louvre Extrusions.

  • Page 22: Louvre Flashing Installation

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® LOUVRE FLASHING INSTALLATION This should result in a gap at the Bottom allowing any water caught on the flashing to fall into the Bottom Gutter. LINK ROD FLASHING INSTALLATION Fix flashings along the length of each gable rafter using Install Link Rod Flashings along the Link Rods at both ends 12g x 20mm Hex Head Self-Drilling Screws with neoprene of the Louvres.

  • Page 23: Barge Trim Installation

    BARGE TRIM INSTALLATION Slide the downpipe over the previously installed Downpipe Outlet and rivet into position. If Downpipe Elbow joins are Where Sunroof Banks finish at an end rafter, a Barge Trim is required, connect as required to ensure the Downpipe required.

  • Page 24: Troubleshooting

    OUTBACK GABLE SUNROOF INSTALLATION GUIDE ® TROUBLESHOOTING PROBLEM CHECK POSSIBLE CAUSE REMEDY Replace battery in the Flat battery in remote remote control unit with The red LED light on the control unit. new CR3032. remote control unit should illuminate when any of the Replace the entire controller buttons are pressed.
  • Page 25 Louvres have been installed to open in the opposite Actuator assembly is the direction to the original unit opposite ‘Type’ (A or B) Original design plans Contact Stratco to advise design. required for Louvre opening for designated Actuator in reversing the Remote direction.

  • Page 26: Maintenance

    No material that retains water (such as dirt or paving sand) should be placed against the columns. Care must be taken when determining the location of Stratco steel products so that they are not placed in close contact with sources of pollution or environmental factors that could affect the life of the steel. Refer to the ‘Selection, Use and Maintenance’...
