INSTALLATION MANUAL
OUTBACK® GABLE PATIO
The New Generation Outback® Gable Patio system has been designed and engineered to generate modern and versatile
structures that provide more design flexibility and increased spanning capabilities.
The New Generation Outback® Gable Patio system integrates new bracketry, new fixings, new design options and new
accessories, to produce the best gable patio product on the market today.
This product has been designed with D.I.Y. in mind for ease of installation.
BEFORE YOU START
It is important to check your Local Government Authority requirements before the installation of your new Stratco Outback®
Gable Patio System.
It is the builder's responsibility to ensure any existing structure that an Outback® Gable Patio is being attached to is
adequately reinforced to accommodate the additional loads imposed by the verandah, patio or carport.
Read these instructions thoroughly before starting your project and refer to them constantly during each stage of
construction. Contact Stratco for advice if you do not have the necessary tools or information.
Carefully read these instructions, along with any supporting documentation provided for your Outback® Gable Patio.
Lay out the components in order of assembly on the ground and check them against the delivery note. The 'Component
Index' section in this guide will assist in identifying each part of your Stratco Outback® Gable unit.
Mark out the overall area of your patio location and ensure it is free from obstructions. Ensure there is reasonable access for
materials and working space. Consider the drainage and disposal of run-off water Outback® Gable Patio.
Check the post and beam positions on the ground.
If you do not have all the necessary tools or information, contact Stratco for advice.
OUTBACK
GABLE
®
VERANDAH | PATIO | CARPORT - INSTALLATION MANUAL
