Handi-Locker
HANDI-LOCKER
Thankyou for choosing a Stratco Handi-Locker™ Shed for your storage needs. This easily erected shed will provide a compact and secure
solution for all your garden and home storage needs.
Optional items such as masonry anchors, additional Handi-Locker shelving, and peg board systems are available upon request when
ordering your Handi-Locker Shed.
BEFORE YOU START
To ensure that the installation and erection of your Stratco Handi-Locker Shed proceeds smoothly you should:
• Confirm that all of the material listed on the delivery documentation has been supplied.
• Carefully read this leaflet completely to ensure that you are familiar with all the steps involved.
• Ensure that you have the correct tools and equipment for the job.
NOTE: Never attempt to install a shed in windy conditions. For your safety, use heavy gloves when handling steel sheeting and flashings.
TOOLS REQUIRED
• Rivet Gun
• Step Ladder
• Power Drill
• 1/8" Metal Drill Bit
• 5/16" Hex Head Adaptor
• Tape Measure
• Water Based Pen
Shed
™
SHEDS
™
• Square
• Gloves
• Level
INSTALLATION
GUIDE
Advertisement
Table of Contents
Related Manuals for Stratco Handi-Locker Shed
Summary of Contents for Stratco Handi-Locker Shed
- Page 1 SHEDS ™ Thankyou for choosing a Stratco Handi-Locker™ Shed for your storage needs. This easily erected shed will provide a compact and secure solution for all your garden and home storage needs. Optional items such as masonry anchors, additional Handi-Locker shelving, and peg board systems are available upon request when ordering your Handi-Locker Shed.
- Page 2 It is essential to clear and level the site prior to assembling your Handi-locker Shed. Option 2 - Substantial concrete squares may be used at each anchor location as an alternative to a complete concrete floor.
- Page 3 WALL AssembLy Begin the installation by moving the front corner wall panel into The doorway channels are fixed to the edge of both of the front position against the back corner wall panel. The two panels walls (adjacent to the proposed door) with two plain rivets (figure 4). should lap as shown in Figure 1.
- Page 4 Secure the back centre wall panel in place by attaching the top Next, place the sliding door mount along the top front of the shed and bottom rear wall channels. Fix each channel using six plain so that its ends are flush to the edge of the wall ribs (Figure 8). rivets (Figure 6).
- Page 5 attaching the doors Place the door guide ramp over the door guide ramp channel as Mount the sliding doors by inserting the slide rail on the back shown in the detail below, and fix through the back edge of the of the door into the slide mechanism on the sliding door mount two components using four plain rivets (Figure 10).
- Page 6 (Figure 16). Congratulations you have successfully completed your Stratco Handi-Locker Shed. BROCDHL © Copyright January 06 All brands and logos/images accompanied by ® or ™ are trade marks of Stratco (Australia) Pty Limited. Figure 16 www.stratco.com.au...
