No. Name
1 POWER LED
IN LED
2
OUT LED
3
(1~4)
EDID DIP
4
switch
5
SERVICE
6
IN port
OUT port
7
(1~4)
8
OPTICAL
9
L/R
10 Power port
When the device is powered on, the red LED will be on.
When the HDMI IN port connects an active source device,
the green LED will be on.
When the HDMI OUT 1/2/3/4 port connects a display device and
outputs signal, the corresponding green LED will be on.
Use the DIP switch to set EDID.
[DIP]=111: Copy OUT port sink EDID (as factory default)
[DIP]=110: 4K60(4:4:4), 2.0CH
[DIP]=101: FRL12G_8K_HDR, 2.0CH
[DIP]=100: FRL12G_8K_HDR, 5.1CH
[DIP]=011: FRL12G_8K_HDR, 7.1CH
[DIP]=010: FRL10G_8K_HDR, 2.0CH
[DIP]=001: FRL10G_8K_HDR, 5.1CH
[DIP]=000: FRL10G_8K_HDR, 7.1CH
Firmware update port.
HDMI signal input port, connecting to HDMI source device such as
DVD or PS5 with an HDMI cable.
HDMI signal output port, connecting to HDMI display device such
as TV or Monitor with an HDMI cable.
Optical fiber audio output port.
Analog audio output port.
5V/2A Power input port.
