4. Specifications

Technical
HDMI Compliance
HDCP Compliance HDCP 2.3, HDCP 1.4
Video Bandwidth
Video Resolution
Color Depth
Color Space
HDR
Audio Formats
ESD Protection
Connection
Input
Output
Control
Mechanical
Housing
Color
Dimensions
Weight
Power Supply
HDMI 2.1
48Gbps FRL and 18Gbps TMDS
Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit,
8K@30Hz 4:4:4 12bit
8/10/12-bit
RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:2:0
HDR, HDR10, HDR10+, Dolby Vision, HLG
HDMI input/output:
LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS,
DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
Audio de-embedding output:
Optical: LPCM / Dolby/DTS 5.1CH
Analog: LPCM 2CH
IEC 61000-4-2:
±8kV (Air-gap discharge) & ±4kV (Contact discharge)
1 × HDMI IN [Type A, 19-pin female]
4 × HDMI OUT [Type A, 19-pin female]
1 × OPTICAL [S/PDIF]
1 × L/R [3.5mm Stereo Mini-jack]
1 × SERVICE [USB Type C, Update port]
Metal Enclosure
Black
176mm (W) × 68mm (D) × 18mm (H)
295g
Input: AC 100-240V 50/60Hz, Output: DC 5V/2A
(US/EU standards, CE/FCC/UL certified)
