PB Heat PBC Series User's Information Manual

Combination gas boilers

Advertisement

Quick Links

U
COMBINATION GAS BOILERS
TO THE INSTALLER:This manual is the property of the owner and must be affixed near the boiler for
future reference.
TO THE OWNER: This boiler should be inspected annually by a Qualified Service Agency.
WARNING
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or death.
– Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
Service Agency
Address
Boiler Model No.
I
SER'S
NFORMATION
SERIES PBC
TO BE COMPLETED BY THE INSTALLER
Serial No.
PB HEAT, LLC
131 S. CHURCH ST • BALLY, PA 19503
M
ANUAL
AVERTISSEMENT
À défaut de suivre les instructions à la lettre, un
incendie ou une explosion risque de causer des
dommages matériels, des blessures ou des pertes
de vie.
– Ne pas entreposer ni utiliser d'essence ou ni
d'autres vapuers ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
– QUOI FAIRE S'IL Y A ODEUR DE GAZ
• Ne pas tenter d'allumer d'appareils.
• Ne toucher aucun interrupteur
électrique. Ne pas utiliser de téléphones
dans le bâtiment ou il y a des odeurs.
• Contacter immédiatement votre
fournisseur de gaz depuis un bâtiment
voisin. Suivre les instructions du
fournisseur.
• S'il est impossible de joindre le
fournisseur de gaz, contacter le service
des incendies.
– L'installation et l'entretien seront assurés
par un installateur ou un service d'entretien
qualifié, ou par le fournisseur de gaz.
Phone No.
Date of Installation:
PBC8023 R1 (02/24-2.5C)
Printed in U.S.A.
©2024 PB Heat, LLC. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PBC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for PB Heat PBC Series

  • Page 1 TO BE COMPLETED BY THE INSTALLER Service Agency Phone No. Address Boiler Model No. Serial No. Date of Installation: PB HEAT, LLC 131 S. CHURCH ST • BALLY, PA 19503 PBC8023 R1 (02/24-2.5C) Printed in U.S.A. ©2024 PB Heat, LLC. All rights reserved.
  • Page 2 ⚠ WARNING Product Safety Information Refractory Ceramic Fiber Product This appliance contains materials made from refractory ceramic fibers (RCF). Airborne RCF, when inhaled, have been classified by the International Agency for Research on Cancer (IARC), as a possible carcinogen to humans. After the RCF materials have been exposed to temperatures above 1800°F (980°C), they can change into crystalline silica, which has been classified by the IARC as carcinogenic to humans.
  • Page 3: Basic Operation

    Basic Operation ⚠ WARNING Service on this boiler should be undertaken only by trained and skilled personnel from a qualified service agency. ⚠ CAUTION Should overheating occur or the gas supply fail to shut off, do not turn off or disconnect the electrical supply to the pump.
  • Page 4 HIGH VENT TEMPERATURE LIMIT SAFETY RELIEF VALVE VENT PRESSURE SWITCH FLAME SENSOR RETURN SENSOR PRIMARY SAFETY CONTROL GAS VALVE Figure 1: Control & Safety Device Locations – PBC-34 through PBC-52 Models HIGH TEMPERATURE LIMIT LOCATION Figure 2: High Temperature Limit Location- PBC-34 through PBC-52 Models...
  • Page 5 Figure 3: Lighting and Operating Instructions...
  • Page 6 Figure 3a: Lighting and Operating Instructions...
  • Page 7 BLOWER Figure 4: Sequence of Operation...
  • Page 8: User Maintenance

    User Maintenance ⚠ WARNING Service on this boiler should be undertaken only by trained and skilled personnel from a qualified service agency. Inspections should be performed at intervals specified in the Installation, Operation and Maintenance Manual and this User’s Information Manual. Maintain manuals in a legible condition.
  • Page 9 Installation, Operation and Maintenance Manual supplied to the installer with the boiler. If a copy of the original Installation, Operation and Maintenance Manual is not available a new copy is available at PeerlessBoilers.com or from your local PB Heat Representative. H. Error Handling 1.
