- Page 1 YLVA 3 / 3+ Additional 7" screen for the videophone 2 wires ref. 112279 7” 100m www.avidsen.com...
-
Page 2: Table Of Contents
MONITOR FOR COLOUR VIDEO INTERCOM 7" CONTENTS A - SAFETY INSTRUCTIONS 1 - INTRODUCTION 2 - MAINTENANCE AND CLEANING 3 - RECYCLING B - PRODUCT DESCRIPTION 1 - KIT CONTENTS 2 - MONITOR 3 - WALL BRACKET 4 - MAINS ADAPTOR C - INSTALLATION 1 - INSTALLING THE MONITOR 2 - CONNECTIONS... - Page 3 D - USING THE PRODUCT 1 - IDENTIFY AND SPEAK TO THE VISITOR 2 - ACTIVATE THE INTERCOM PANEL FROM THE MONITOR 3 - OPENING AN ELECTRIC LOCK AND AN AUTOMATIC CONTROL SYSTEM (OPTIONAL) 4 - INTERCOM FEATURE 5 - DISPLAY OF ADDITIONAL CAMERA 6 - MONITOR SETTINGS E - TECHNICAL AND LEGAL INFORMATION 1 - TECHNICAL CHARACTERISTICS...
-
Page 5: A - Safety Instructions
MONITOR FOR COLOUR VIDEO INTERCOM 7» A - SAFETY INSTRUCTIONS 1 - INTRODUCTION • The cable between the monitor and intercom panel must not be extended. Avoid junctions This pack includes an additional monitor that is (insulating screw joints, soldered joints, etc.) compatible with the following video intercom references: 3 - RECYCLING... -
Page 6: B - Product Description
Dowels (2 for the monitor, 3 for the intercom panel) 2 - MONITOR 4.3" LCD screen Handset button to answer calls, call another monitor (ref. 112279) or left arrow Microphone Surveillance mode to view the intercom panel Photo viewing button or menu access (hold or right arrow... -
Page 7: Wall Bracket
MONITOR FOR COLOUR VIDEO INTERCOM 7» B - PRODUCT DESCRIPTION 3 - WALL BRACKET The monitor is designed to be fixed to the wall. A wall bracket and the necessary fasteners are included. 4 - MAINS ADAPTER A 230 Vac 50 Hz/17 Vdc 1.5 A mains adapter for powering the monitor is included in the kit. Do not use other power supplies as they could cause irreparable damage to the device and invalidate the warranty. -
Page 8: C - Installation
MONITOR FOR COLOUR VIDEO INTERCOM 7» C - INSTALLATION The recommended installation height for the intercom panel is about 160 cm from the ground and 150 cm from the floor for the indoor unit. 50cm 70° 160cm 150cm NOTE: For obvious safety reasons, the connections must only be made after shutting off the power supply. 1 - INSTALLING THE MONITOR Attach the wall mount to the wall using the screws and wall plugs suited to the support (the screws and plugs supplied are suitable for solid walls). -
Page 9: Connections
MONITOR FOR COLOUR VIDEO INTERCOM 7» C - INSTALLATION 2 - CONNECTIONS • Do not increase the number of insulating screw joints or connectors on the connecting wire between the intercom panel and the monitor • Keep the connecting wire between the intercom panel and the monitor more than 50 cm away from any electromagnetic interference (230 V cable, WiFi device, microwave ovens, etc.) •... -
Page 10: Connection Between The Monitor And The Intercom Panel
IMPORTANT: connect terminals 3 and 4 directly to the opening/closing contact of the automatic control system (automated entryway wired control system input). 2.2 - CONNECTIONS 2.2.1 - CONNECTION KIT 112266 (YLVA 3) + 1 CAMERA (112248) + MONITOR CCTV Monitor ref. 112248 Monitor ref. 112279 Intercom panel... -
Page 11: Connection Kit 112271 (Ylva 3) + 1 Intercom Panel (112273) + Monitor
C - INSTALLATION 2.2.2 - CONNECTION KIT 112271 (YLVA 3) + 1 INTERCOM PANEL (112273) + MONITOR Monitor Monitor ref. 112279 Intercom panel Intercom panel ref. 112273 N.B. The wiring diagram will be equivalent for the Ylva 3+ Compact reference (112272). -
Page 12: D - Using The Product
MONITOR FOR COLOUR VIDEO INTERCOM 7» D - USING THE PRODUCT 1 - IDENTIFY AND SPEAK TO THE VISITOR paragraph), press the button (for the lock) or The visitor presses the intercom panel button (for the automatic control system) to Nils Larsson let a visitor enter. -
Page 13: Display Of Additional Camera
MONITOR FOR COLOUR VIDEO INTERCOM 7» D - USING THE PRODUCT 5 - DISPLAY OF ADDITIONAL CAMERA If you have installed an additional camera (112248), it is possible to display it by pressing on 6 - MONITOR SETTINGS With the screen is on, press the button to display the following screen: Once in the RING sub-menu, press the... -
Page 14: E - Technical And Legal Information
MONITOR FOR COLOUR VIDEO INTERCOM 7» E - TECHNICAL AND LEGAL INFORMATION 1 - TECHNICAL CHARACTERISTICS MONITOR Ultra-flat 7" colour LCD Screen PAL/NTSC Video standard 800 x (RGB) x 480 Resolution with 230 VAC 50 Hz / 17 VDC 1.5 A Power supply mains adapter included 17 VDC 1.5 A (adapter included) -
Page 15: Warranty
• The warranty does not cover damage caused progress of the work on our website at the following by negligence, knocks or accidents. address: http://sav.avidsen.com • None of the parts of this product may be opened or repaired by any persons not Smarthome France undertakes to keep a stock employed by Smarthome France. - Page 16 Smarthome France 19 Avenue Marcel Dassault ZAC des Deux Lions - 37200 Tours - France...
