WyreStorm MX-1616-SCL: Advanced 16x16 Modular Seamless
Scaling Matrix Chassis with HDMI & HDBT Transmission Cards
MX-1616-SCL
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Read through the
Wiring and Connections
wiring guidelines before creating or choosing pre-made cables.
• Visit the product page to download the latest firmware, document
version, additional documentation, and configuration tools.
Install the latest firmware to ensure that all features described in this
document are available during and after installation.
Recommended Products
To take full advantage of the features of this matrix, WyreStorm recommends the following products be used within this product.
TX-SCL-HDMI
INPUTS
1x HDMI In: Type A Female
OUTPUTS
1x HDMI Out: Type A Female
1x Audio Out: 5-Pin Phoenix
Basic Wiring Diagram
Copyright © 2024 WyreStorm ProAV Corporation |
MX-1616-SCL Quickstart Guide | 240423
section for important
TX-SCL-HDBT
INPUTS
1x HDMI In: Type A Female
OUTPUTS
1x HDBaseT Out: RJ45 Female
1x Audio Out: 5-Pin Phoenix
wyrestorm.com
1 of 4
In the Box
1x MX-1616-SCL Matrix
1x AC Power Cord (US/UK/EU/AU)
1x IR Remote (Batteries not included)
1x IR Extension Cable
1x USB-A to DB9 Cable
2x Mounting Brackets (with Screws)
1x Quick Start Guide
