MX-0808-PP-POH
Fixed Pro Plus chassis featuring PoH
HDBaseT out, mirrored HDMI out, HDMI in, IR
input transmission card.
WyreStorm Pro Plus PoH HDBaseT Solutions
Please read these instructions carefully before installing to avoid complications later.
US/CAN/MEX: +1-518-289-1294
MX-0808-PP-POH-Custom
Modular Pro Plus chassis with selection
of customisable analogue and digital PoH
transmission cards.
Thank you for choosing this WyreStorm product.
Toll Free Technical Support: +1-844-280-WYRE (9973)
Instruction Manual
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wyrestorm MX-0808-PP-POH
Summary of Contents for Wyrestorm MX-0808-PP-POH
- Page 1 PoH input transmission card. transmission cards. WyreStorm Pro Plus PoH HDBaseT Solutions Instruction Manual Thank you for choosing this WyreStorm product. Please read these instructions carefully before installing to avoid complications later. US/CAN/MEX: +1-518-289-1294 Toll Free Technical Support: +1-844-280-WYRE (9973)
-
Page 2: Table Of Contents
Basic Remote Control via RS-232 for individual screen control in display zones using Advanced Remote Control a WyreStorm Enado or third party control system – all of which adds up to a powerful package for applications of any size or Advanced Operation budget. -
Page 3: Features
Safety Precautions • Fully 3D compatible – Frame sequential 3D (Blu-ray) and • (MX-0808-PP-POH) - factory configured with 8 standard interlaced stereoscopic 3D (satellite broadcasts etc.) transmission cards: HDBaseT PoH out, mirrored HDMI • Supports all high definition resolutions up to and including WARNING 1080p and standard video formats. -
Page 4: Package Contents
• Flash USB stick containing PC control software and digital copy • 6 / 8 x IR TX Emitters (small sensor for Input source) • 1 x MX-0808-PP-POH main unit - 8 input 8 output Pro • 1 x Printed instruction manual... -
Page 5: Panel Descriptions
IR receive window Confirm selection button Input select buttons (UP/DOWN) Mounting brackets ENTER ii. Rear Panel Description - MX-0808-PP-POH Input/Output port grouping indicator HDBaseT PoH output ports (RJ45 Cat5e/6/7) Duplicate HDMI output ports (mirrors HDBaseT output) LAN port HDMI input ports... -
Page 6: Rear Panel Description -Mx-0808-Pp-Poh-Custom
Rear Panel Description - MX-0808-PP-POH-CUSTOM Card Options HDBaseT out, Mirrored HDMI out, HDMI in, IR in - “Default” card TX-POH-010 as standard on all non-CUSTOM MX-PP-POH matrix models. Offers 70m/230ft HDBaseT transmission including Video, Audio, Control & Power, combined with a duplicate HDMI output to allow simultaneous connection of a second local “mirrored”... - Page 7 Control of source device cannot be routed internally through the matrix - an IR loop port is included on the card for corresponding IR TX port connection using the CAB-IR-LINK WyreStorm IR Link cable (CAB-IR- LINK). Similarly, for RS-232 control a phoenix port breaks-out or injects serial commands to be sent down the HDBaseT link.
-
Page 8: Typical Application
1 Satellite/Cable box 2 cat 5e/6 Line Level Audio 70m/230ft VGA/dvi ir tx hdmi ir rx HDBaseT™ and the HDBaseT Alliance logo are rs232 sub pre-out trademarks of the HDBaseT Alliance Technical support: support@wyrestorm.com EMEA/ROW: +44 (0) 1793 230 343... -
Page 9: All Cards
ii. All Cards PERSONAL AUDIO DEVICE 25w d-class amp 25w d-class amp 25w d-class amp Enhanced 2.1 Audio & HD Enhanced 2.1 Audio & HD Enhanced 2.1 Audio & HD Audio return channel from tv rx-70-poh HD Audio Video Enado controller sonos connect control system... -
Page 10: Connection
Plug the 3.5mm jack of the IR receiver into the IR RX i. Connect an WyreStorm IR link cable between the IR RX port of the display receiver. Place the IR receiver sensor port on the matrix output cards to a control system. -
Page 11: Basic Operation
The corresponding OUTPUT channel number will blink on the display when reached. Finally, switch on the matrix at the rear and your WyreStorm system should now be fully connected and Press the LEFT ARROW or RIGHT ARROW key to ready for use. -
Page 12: Basic Remote Control
So for example, using the previous / next buttons for 1 es connected to the matrix for each individual output Technical Support: support@wyrestorm.com US: +866 677 0053 EU: +44 (0) 1793 230 343 allows you to select the source to be set to display 1 manu-ally. - Page 13 RJ45 OUTPUT links INPUT 3 with IR TX3 for the HDBT OUT 3 HDBT OUT 7 The WyreStorm MX-PP-POH is not only a switcher and for the signal to be combined and communicated for that HDBT OUT 3...
- Page 14 The Call-back function can be turned on/off NOTE The call-back function can be turned on/off by accessing the Wyrestorm COMCTL software. See by accessing the WyreStorm COMCTL software. NOTE The Call-back function can be turned on/off...
-
Page 15: Advanced Remote Control
Typically, unless alternative methods of controlling the matrix are or data manually input should such problems arise, as well as These can be obtained through the Wyrestorm website, by input them manually. control. -
Page 16: Rs-232 Application Scenarios - Understanding Rs-232
A crossover (null-modem) cable can be used to connect two DTE directly, without a modem in between to cross transmit and receive data signals between the two sides. There are numerous variations on how control signals are wired: Technical support: support@wyrestorm.com EMEA/ROW: +44 (0) 1793 230 343... -
Page 17: Routable Rs-232 With Mx-Pp-Poh
Straight-through (DB-9 Crossover (Null-Modern) (DB-9 (DTE) (DCE) (DTE) (DCE) ------- DCD ------- DCD ------- TxD ------- TxD ------- RxD ------- RxD ------- DSR ------- DSR ------- GND ------- GND ------- DTR ------- DTR ------- CTS ------- CTS ------- RTS ------- RTS ------- RI Mark (1) -12v... -
Page 18: Routing Serial Commands From The Mx-Pp-Poh
A 9-pin serial cable should be used between control system and matrix. NOTE If cascading matrices using the TX-POH-020 transmission card to expand distribution, a separate serial cable must be used for each additional matrix connected – serial commands cannot be cascaded. Technical support: support@wyrestorm.com EMEA/ROW: +44 (0) 1793 230 343... -
Page 19: Edid Management - About Edid
EDID Management - EDID Presets About EDID Copy EDID from the HDMI sink ✳ device to the currently selected EDID (Extended Display Identification Data) is input port data generated from each display in the system to 1 2 3 4 communicate the capabilities of the device (720p, 2ch For example, when output-3 select Audio, 1080p, 7.1ch Audio). -
Page 20: Troubleshooting
2) If possible, always use test equipment prior to distribution i.e. the cable, receiver or matrix itself. installation and to troubleshoot any problems. Technical support: support@wyrestorm.com EMEA/ROW: +44 (0) 1793 230 343... - Page 21 10) HDMI lead condition and quality – HDMI cables audio and EDID copy from the AVR may be required or and connectors are delicate and can be damaged much use an embedded EDID in the AMP or Matrix. easier than component or coax cable. Furthermore, NOTE If problems are experienced when an AV lead quality varies dramatically, particularly in lower price...
-
Page 22: Faq
RS-232 control and Ethernet third party control systems with your WyreStorm dealer. on 100m/328ft HDBaseT products, with 70m/230ft HDBaseT products removing Ethernet passthrough 6) IR dropout issues - these can be due to exterior functionality. -
Page 23: Maintenance
HDCP “keys” are assigned to a display when connected to a HDMI device normally. This doesn’t Are WyreStorm products compatible with HDMI 1.4? change when connected to a switch; it just assigns more HDMI 1.4 refers to a list of ‘features’ that a device is of them. -
Page 24: Provided Service
Limited warranty period: 2. Servicing Personnel: Do not attempt to service the All WyreStorm products are covered by a 3 year PARTS unit beyond that described in these operating instructions. and LABOUR warranty. During this period there will be no Refer all other servicing to authorised servicing personnel. -
Page 25: Disclaimer
WyreStorm reserves the right to change software, control codes and specifications without notice. WyreStorm will not be liable for any use of this information or any changes it may make to those products. The use of this information constitutes an agreement by the user to these limitations and exclusions. -
Page 26: Installation Reference Log
Wyrestorm Matrix INPUT installation reference log INPUT Input Source Location Source Details Source resolution & audio Cable number on settings Number Matrix Technical Support: support@wyrestorm.com US: +866 677 0053 EU: +44 (0) 1793 230 343 Technical support: support@wyrestorm.com EMEA/ROW: +44 (0) 1793 230 343... - Page 27 Wyrestorm Matrix OUPUT installation reference log OUTPUT Output Output Location Display Details Display Resolution & Audio Cable number on Settings Number Matrix Technical Support: support@wyrestorm.com US: +866 677 0053 EU: +44 (0) 1793 230 343 US/CAN/MEX: +1-518-289-1294 Toll Free Technical Support: +1-844-280-WYRE (9973)
- Page 28 US: +1 844-280-WYRE (9973) UK:- +44 (0) 1793 230 343 Email: support@wyrestorm.com WyreStorm Technologies reserve the right to change physical appearance or technical specification of this product at any time. Visit wyrestorm.com for the latest information on products.. 151028 Technical support: support@wyrestorm.com...
