AN ISO 9001:2015 COMPANY
TRMS DIGITAL MULTIMETER
MODEL - KM 789
OPERATION MANUAL
® ®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kusam-meco KM 789
Summary of Contents for Kusam-meco KM 789
- Page 1 * Digital Lux Meter TRMS DIGITAL MULTIMETER * Network Cable Tester * Power Factor Regulator * Earth Resistance Tester * Digital Panel Meters MODEL - KM 789 * DC Power Supplies * High Voltage Detectors * Calibrators * Gas Detectors * Frequency Counter...
-
Page 2: Table Of Contents
® ® TAKE MEASUREMENTS CAREFULLY AND YOU’LL SPARE TABLE OF CONTENTS YOUR METER AND YOURSELF, SOME PAIN. Nearly every electrical engineer has a hand held Multimeter. We TITLE PAGE sometimes take them for granted, until we damage them or “burn them out”.If you incorrectly connect your DMM to a circuit or have the DMM on wrong setting, you damage the meter and possibly 1. -
Page 3: Safety
® ® 1) SAFETY Optional offer premium test probe assembly using silicone lead wire insulation,at agent’s discretion, is equipped with white inner Terms in this manual insulation layers as wear indicators. Replace them immediately if any of the white layers has become visible. WARNING identifies conditions and actions that could result in serious injury or even death to the... -
Page 4: Cenelec Directives
® ® similar points) of the low-voltage MAINS installation. Examples 4. SPECIFICATIONS : are measurements on MAINS CIRCUITS of household appliances, GENERAL SPECIFICATIONS : portable tools and similar equipment. Display: 4-5/6 digits 60,000 counts. Polarity: Automatic Marking of Electrical and Electronic Equipment (EEE). Update Rate: Do not dispose of this product as unsorted municipal 4-5/6 digits: Max 5 per second nominal... - Page 5 ® ® Overload Protections: Special Features: µA & mA: 0.4A/1000V DC/AC, IR 30kA or better, F fuse ● Record MAX, MIN, & AVG readings A: 11A/1000V DC/AC, IR 20kA or better, F fuse ● Crest (Instantaneous Peak hold) V: 1100V DC/AC rms ●...
-
Page 6: Electrical Specifications
® ® ELECTRICAL SPECIFICATIONS : 1)Accuracy specified from 10% to 100% of range 2)Signal peak absolute values, including DC bias, less than Accuracy is ±(% reading digits + number of digits) or otherwise specified, at 23ºC ± 5ºC & less than 75% relative humidity.Maximum 1000mVpeak Crest Factor <1.6:1 at full scale &... - Page 7 ® ® VFD AC VOLTAGE LoZ Auto-ACV RANGE RANGE ACCURACY ACCURACY 50Hz ~ 60Hz 10Hz ~ 200Hz 1.0% + 40d 6.0000V, 60.000V, 600.00V, 1000.0V 4% + 50d 600.00V, 1000.0V 200Hz ~ 440Hz 1)Accuracy specified from 10% to 100% of range LoZ Auto-ACV Threshold: >...
- Page 8 ® ® Ohms & Conductance Capacitance RANGE 1)2) ACCURACY RANGE ACCURACY 600.00Ω 0.085% + 10d 10.00nF 1.0% + 10d 6.0000kΩ, 60.000kΩ 0.085% + 4d 100.0nF~1000nF 1.0% + 2d 600.00kΩ 0.15% + 4d 10.00µF~1.000mF 1.8% + 4d 6.0000MΩ 1.5% + 5d 10.00mF 2.0% + 4d 3)4)
- Page 9 ® ® DC Loop Current %4~20mA AC Current Burden Voltage RANGE ACCURACY 4mA : 0% (zero) 20mA : 100% (span) 40Hz ~3kHz Resolution: 0.01% Accuracy: ± 25d 600.00µA 600.00µA 0.2mV/µA Temperature 6000.0µA 0.9%+20d 1)2) RANGE ACCURACY 60.000mA 2.0mV/mA -200.0°C to 1090°C 1.0% + 1.0°C 600.00mA -328.0°Fto 1994°F...
- Page 10 ® ® ~ Hz Line Level Frequency Indication: Bar-graph segments & audible beep tones proportional to the field strength Range Sensitivity (Sine RMS) Function RANGE Detection Frequency: 50/60Hz 0.4V 10Hz ~ 50kHz Detection Antenna: Top-left end of the meter 10Hz ~ 50kHz Probe-Contact EF-Detection (Single-pole): For more precise indication of live wires, such as distinguishing between live and 600V...
-
Page 11: Product Description
® ® Analog bar-graph AutoHold Real-Read The analog bar graph provides a visual indication of measurement Accuracy: Specified accuracy ± 50 digits like a traditional analog meter needle. It is excellent in detecting Availability: Resistance, Continuity, LoZ AutoV, VFD Volts, faulty contacts, identifying potentiometer clicks, and indicating Voltage and Current functions signal spikes during adjustments. - Page 12 ® ® Note: 1)Ghost-voltage Buster: Ghost-voltages are unwanted stray signals coupled from adjacent hard signals, which confuse common multimeter voltage measurements. The AutoV mode provides low (ramp-up) input impedance (approx. 2.1kΩ at low voltage) to drain ghost voltages leaving mainly hard signal values on meter readings.
- Page 13 ® ® TRIGGER ACV/dBm/DCV/AC+DCV VFD-ACV µA 600 µA 60mA 6A LEVEL 0 LEVEL 1 6000µA 600mA 10A LEVEL 2 600V 600V LEVEL 3 1000V 1000V Note: It is recommended to direct measure the signals (voltage or current) in auto-ranging mode before activating the ~Hz function DCmV;...
- Page 14 ® ® Note: In dBm function, power up default reference impedance will be displayed for 1 second before displaying the dBm readings. Press dBm-Ω (RANGE) button momentary to select different reference impedance of 4, 8, 16, 32, 50, 75, 93, 110, 125,135, 150, 200, 250, 300, 500, 600, 800, 900, 1000, up to 1200Ω.
- Page 15 ® ® ■ BeepLit™ Continuity This function is having improved convenience for checking wiring connections and operation of switches. Resistance threshold is being used. A continuous beep tone together with display backlight flashing indicate a complete wire. Such audible and visible indications improve continuity readabilities in noisy working environments.
- Page 16 ® ® Note: Note: 1) Discharge capacitor(s) before making capacitance 1)Temperature accuracies assume meter interior has the same measurements. Large value capacitors should be discharged temperature (isothermal stage) of the ambient for a correct through an appropriate resistance load. junction voltage compensation. Allow the meter and the type-K probe set to reach isothermal stage for a significant change of 2) Using BeepLitTM Diode or Capacitance function in a live circuit >...
- Page 17 ® ® μA Current A Current Inputs are made via the input terminals -COM. Press Inputs are made via the input terminals -COM. Press the the SELECT button momentarily to select DC, AC, DC+AC in SELECT button momentarily to select DC, AC, DC+AC in sequence.
- Page 18 ® ® EF-Detection of Electric Field Press EF button momentarily to enter EF-Detection function. Defaults at high sensitivity EF-H. The meter displays “EF-H” when it is ready. If it is too sensitive for your applications, press EF button momentarily to select lower sensitivity “EF-L”. The detected Electric Field strength is indicated as a series of bar-graph segments on the display plus variable beep tones.
- Page 19 ® ® HOLD HOLD feature freezes the display for later view. LCD “ ” turns on. Press the HOLD button momentarily to toggle the HOLD feature. AutoHold Real-Read™ AutoHold feature displays the last latched stable-reading for later view when the test leads are removed from the test points after a significant-measurement session.
- Page 20 ® ® ●The AutoHold gives 3 short-beeps and “- - - - -” flashes to Auto-Power-Off is disabled automatically in this mode. Availability: indicate a null capture after a significant-measurement.It Voltage and Current functions. represents no stable-reading is being latched or that has been Beep-Jack™...
-
Page 21: Maintenance
® ® temporarily during the power-on session. It is designed mainly for Fuse use and replacement production inspection. The Meter uses: Fuse (F1) for A input: ●Disabling/Enabling oC or oF function availability Bussmann DMM-11AR; 11A/1000Vac & Vdc, IR 20kA, F fuse; See Temperature measurement operation description for details. -
Page 22: Test Certificate
® ® MUMBAI WARRANTY Each “KUSAM-MECO” product is warranted to be free from TEST CERTIFICATE defects in material and workmanship under normal use & service. The warranty period is one year (12 months) and begins from the TRMS DIGITAL MULTIMETER date of despatch of goods.
