Valor P2 246LFB Installation Manual

INSTALLATION MANUAL
246LFB/246LFAS 4-Sided Ledgeview Front Kit
CSA approved for use with Valor P2 200 Fireplaces Models only
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and must be
installed for the protection of children and other at-risk
individuals.
The 246LF 4-Sided Ledgeview Front Kit can be installed on
Valor P2 200 fi replaces either in zero clearance or insert
applications.
In ZC applications, the 246 fi ts fl at against the 1/2" non-
combustible board, with the ability to tuck additional
non-combustible materials up to 3/4" thickness behind
the trim.
Note this front extends 1-1/2" below the base of the
appliance. Take this into account if installing a hearth.
Overview
P2 200
engine
Convection
bracket
Backing plate
assembly
4 sided front
assembly
4009492-01
© Copyright Miles Industries Ltd., 2024
P2 Series
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
I N ST A LL E R
L e a v e t h i s m a n u a l
w i t h t h e a p p l i a n c e .
C O N S U M E R
Retain this manual
for future reference.
Note: This kit must be installed
by a qualifi ed installer, service
agency or gas supplier at the time
of the heater installation. These
instructions are to be used in
conjunction with the fi replace
main installation instructions.
26-1/4" [667 mm]
24-1/4" [617 mm]
17-11/16" [450 mm]
1-1/2" [38 mm]
Overhang below bottom of unit
1
