Wiring Diagram - Icon Process Controls LevelPro 250B Series Quick Start Manual

LevelPro — 250B Series
®
Battery Powered Liquid Level Display

Wiring Diagram

Dimensions
24-0344 © Icon Process Controls Ltd.
Temporary Deadman |
Optional
Latching Switch*
Turn Off
+ve -ve
*Optional
■ Temporary Deadman : Non-Latching Switch
■ Latching Switch : Need to turn off manually when the device is not
in use.
112.0
Sensor
130.5
4
