O P E R A T O R ' S M A N U A L
BOX BLADES
BB5048L
BB5060L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BB5060 and is the answer not in the manual?

Questions and answers

Connie Ford
April 22, 2025

What size coupler goes on BB5072 BB item 2, category one roll pin when using John Deere I match?

1 comments:
Mr. Anderson
May 11, 2025

The Frontier BB5060 is compatible with a Category 1 iMatch™ quick coupler. The BB5072 is not detailed in the provided context, but since the BB5060 is Category 1 compatible, a Category 1 quick coupler is needed when using it with a John Deere iMatch system.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Frontier BB5060

  • Page 1 O P E R A T O R ’ S M A N U A L BOX BLADES BB5060 BB5048L BB5072 BB5060L BB5084 BB5096 5TITE511191 (Rev. 10/14/2011)
  • Page 2: Introduction

    Use only genuine Frontier service parts. Substitute parts will void the warranty and may not meet standards required for safe and satisfactory operation. Record the model number and serial number of your equipment in...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ....................2 GENERAL INFORMATION ................3 SPECIFICATIONS ................... 4 SAFETY RULES ..................... 5-6 DEALER CHECK LISTS ..................7 SAFETY DECALS ................... 8-9 OPERATION ....................10-12 OWNER SERVICE..................12-13 PARTS LIST ....................14-15 BOLT TORQUE CHART .................. 16 BOLT SIZE CHART &...
  • Page 4: Specifications

    SPECIFICATIONS Model BB5060 BB5072 BB5084 BB5096 BB5048L BB5060L Dimensions Working Width, in. (cm) 61.5 (156.21) 73.5 (186.69) 85.5 (217.17) 97.5 (247.65) 50 (127.0) 62 (157.48) Endplate thickness 0.375 (.95) 0.375 (.95) 0.375 (.95) 0.375 (.95) 0.313 (.80) 0.313 (.80) Moldboard thickness 0.188 (.48)
  • Page 5: Safety Rules

    SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide safe equipment can be wiped out by an operator’s single careless act. In addition to the design and configuration of equipment, hazard control and accident prevention are dependent upon the awareness, concern, judgment, and proper training of personnel involved in the operation, transport, maintenance and storage of equipment.
  • Page 6 SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! MAINTENANCE (Safety Rules continued from previous page) • Always wear relatively tight and belted OPERATION clothing to avoid getting caught in moving • Always comply with all state and local lighting and parts.
  • Page 7: Dealer Check Lists

    DEALER PREPARATION CHECK LIST Frontier BB50 SERIES BOX BLADES THIS CHECKLIST IS TO REMAIN IN OWNER’S MANUAL It is the responsibility of the dealer to complete the procedures listed below, then review this checklist with the customer upon the delivery or the sale of this implement.
  • Page 8: Safety Decals

    USE FOR MODEL BB5096 ONLY USE FOR MODEL BB5096 ONLY & PINCHING 5TITE511206 5HDBB5000 5HDBB6000 4 SERIAL NUMBER 7 FRONTIER LOGO 5HDBB7000 5HDBB8000 Warning Label Sheet 8 MODEL NUMBER Part Number 5TITE511211 (Contains Label #s 1, 2, 3, & 7)
  • Page 9 SAFETY and INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Replace Immediately if Damaged! Back View 3 FALLING OFF 5 FRONTIER LOGO 4 SERIAL NUMBER 1 AVOID INJURY 5BB4000 5BB5000 6 MODEL NUMBER 2 CRUSHING & PINCHING Warning Label Sheet Part Number 5TITE511209 (Contains Label #s 1, 2, 3, &...
  • Page 10: Operation

    OPERATION The operator is responsible for the safe operation of this equipment. The operator must be properly trained. Operators should be familiar with the equipment, the tractor, and all safety practices before starting operation. Read the safety rules and safety decals on pages page 5 through page 9. The box blades are designed for a wide range of applications: scarifying, scraping, leveling, grading, and backfilling.
  • Page 11 OPERATION ADJUSTING TOP LINK BACKFILLING The box blade is leveled by adjusting the length of 1. Raise or remove scarifier shanks. the tractor’s top link. 2. Lower the blade to the ground and back up into the fill material. • Shortening the top link will deepen the scarifier 3.
  • Page 12 OPERATION STORAGE WARNING • Block equipment securely for storage (see Figure 2). • Keep children and bystanders away from storage area. OWNER SERVICE The information in this section is written for operators who possess basic mechanical skills. If you need help, your dealer has trained service technicians available.
  • Page 13: Owner Service 13

    OWNER SERVICE REMOVING SCARIFIER SHANKS REPLACING CUTTING EDGE Scarifier shanks have four operating positions in the All box blade models use two 3/8” x 6” (9.53 x 152 mm) blade. They may be removed if scarifying action is not cutting edges. They are interchangeable and reversible. needed.
  • Page 14: Parts List

    PARTS 4-4c A-FRAME HITCH & BB5060, BB5072, BB5084, BB5096 PARTS LIST Item Number Part Number Description 5TITE511197 Box Blade Top Link Bushing w/Hardware 5TITE511198 7/8” x 6” Category 1 Roll Pin w/Lynch Pin 5TITE511193 1/2” x 4” ‘L’ Pin w/Clip Pin (2 pk) 5TITE511164 60”...
  • Page 15 PARTS 2-2a A-FRAME HITCH & BB5048L, BB5060L PARTS LIST Item Number Part Number Description TIFC711112 Category 1 Lift Pin 5TITE511205 48” Cutting Edge 5TITE511164 60” Cutting Edge 5TITE511192 4 Hole Shank 5TITE511193 1/2 x 4 ‘L’ Pin w/Clip Pin (2 pk) 5TITE511163 Bolt Set for Cutting Edge Mounting (6 pk) 5TITE511194...
  • Page 16: Bolt Torque Chart

    BOLT TORQUE CHART Always tighten hardware to these values unless a different torque value or tightening procedure is listed for a specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware: SAE for SAE hardware and Metric for metric hardware. Make sure fastener threads are clean and you start thread engagement properly.
  • Page 17: Bolt Size Chart & Abbreviations

    BOLT SIZE CHART NOTE: Chart shows bolt thread sizes and corresponding head (wrench) sizes for standard SAE and metric bolts. SAE Bolt Thread Sizes 10MM 12MM 14MM 16MM 18MM METRIC BOLT THREAD SIZES ABBREVIATIONS AG ......................Agriculture MPa .......................Mega Pascal ASABE ............American Society of Agricultural & N ........................Newton Biological Engineers (formerly ASAE) NC ....................National Coarse...
  • Page 18 NOTES 18 Notes...
  • Page 19 NOTES Notes 19...
  • Page 20 PART NUMBER 5TITE511191...

This manual is also suitable for:

Bb5072Bb5048lBb5060lBb5084Bb5096
