- Page 1 O P E R A T O R ’ S M A N U A L REAR BLADES RB1172 RB1184 RB1196 5WPMAN0148 (Rev. 2/16/2009)
-
Page 2: Introduction
Use only genuine Frontier service parts. Substitute parts will void the warranty and may not meet standards required for safe and satisfactory operation. Record the model number and serial number of your equipment in the spaces... -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........2 GENERAL INFORMATION . -
Page 4: Specifications
SPECIFICATIONS RB1172 RB1184 RB1196 Overall Height 40" (102 cm) 40" (102 cm) 40" (102 cm) Moldboard Height 18" (46 cm) 18" (46 cm) 18" (46 cm) Working Width 72" (183 cm) 84" (213 cm) 96" (244 cm) Moldboard Thickness 5/16" (7.9 mm) 5/16"... -
Page 5: Safety Rules
ENTERS SKIN OR EYES. DO NOT DELAY. and ensure all other controls are disengaged Never allow children or untrained persons to before starting power unit engine. operate equipment. (Safety Rules continued on next page) Safety 5 Frontier RB1172 (Rev. 6/15/2006) - Page 6 Block equipment securely for storage. has been turned off. Hydraulic system leak-down, Keep children and bystanders away from stor- hydraulic system failures, mechanical failures, or movement of control levers can cause equipment age area. 6 Safety Frontier RB1172 (Rev. 6/15/2006)
-
Page 7: Safety Decals
SAFETY & INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Replace Immediately If Damaged! WARNING BLADE MUST BE PROPERLY SECURED OR IT WILL FALL OFF WHEN ANGLING OR REVERSING. Follow all manual instructions and safety rules. Lower blade to ground, shut off tractor, set park brake, and remove key. - Page 8 SAFETY & INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Replace Immediately If Damaged! (Safety Decals continued from previous page) WARNING WARNING CRUSHING AND TO AVOID SERIOUS PINCHING HAZARD INJURY OR DEATH: Be extremely careful Read Operator's Manual handling various parts of the before operating, servicing, WARNING machine.
-
Page 9: Operation 9
OPERATION The operator is responsible for the safe operation of this equipment. Operators must be instructed in and be CAUTION CAUTION capable of the safe operation of the equipment, its attachments and all controls. Do not allow anyone to Always wear relatively tight and belted clothing operate this equipment without proper instructions. - Page 10 Adjust sway blocks or tighten tractor 3-point sway Storage Position chains to eliminate implement side-to-side movement With rear blade raised, place parking stand in lowest during operation. position as shown in Figure 4. Lower rear blade so cut- ting edge and parking stand are flat on the ground. Dis- connect 3-point arms and top link from rear blade.
- Page 11 Angling and Reversing age in place by inserting the pin in the desired hole. (Figure 5) Secure with hair pin clip. For offsetting to the left, posi- Ten holes are provided for angling the blade: five in the tion the linkage on the right side of the frame and forward position (to a maximum angle of 45 degrees) extend the linkage.
- Page 12 Blade Rotation (Figure 9) The blade can be reversed for backfilling. Remove the drop pins and rotate the blade 180 degrees from the forward position. Reinstall the drop pins and secure. The tractor draw bar must be removed or installed in its shortest position to allow the blade to rotate 180 degrees.
-
Page 13: Optional Equipment 13
OPTIONAL EQUIPMENT SINGLE TAILWHEEL KIT 5WP1001533 Attach tailwheel tube assembly (1) to rear of tilt turnta- ble and secure with cap screws (5) and hardened flat washers (4) from turntable. Torque cap screws to 170 Assemble Tailwheel (Figure 10) lbs-ft. (231 N-m). NOTICE Attach yoke assembly (2) to tailwheel tube and secure into position with spirol pin (3). - Page 14 QUICK HITCH BUSHING KIT 5WP1002011 1. Moldboard assembly NOTICE 2. Skid & shaft assembly 3. Right skid shoe bracket Do not use Quick Hitch with Single Tailwheel (not shown) Kit. 4. Left skid shoe Install cap screw (5), sleeve (4), lock washer (6), and bracket hex nut (7) through bottom hole of A-frame as shown.
-
Page 15: Dealer Check Lists 15
DEALER CHECK LISTS PRE-DELIVERY CHECK LIST equipment gross weight must be on front tractor wheels. When adding weight to attain 20% of (DEALER’S RESPONSIBILITY) tractor and equipment weight on front tractor Inspect the equipment thoroughly after assembly to be wheels, you must not exceed the ROPS weight certain it is set up properly before delivering it to the certification. -
Page 16: Owner Service
OWNER SERVICE The information in this section is written for operators BLADE CUTTING EDGE REPLACEMENT who possess basic mechanical skills. Should you need The moldboard blade is reversible and replaceable. help, your dealer has trained service technicians avail- able. For your protection, read and follow all safety Remove the cap screws and hex nuts retaining the cut- information in this manual. -
Page 17: Parts List Index
RB1196 RB1172, RB1184, RB1196 Assembly ....18-19 Quick Hitch Bushing Kit (Optional) ......19 Tailwheel Kit (Optional) . - Page 18 RB1172, RB1184, RB1196 ASSEMBLY 27 - SAFETY DECAL SET 30 - COMPLETE DECAL SET 18 Parts 5WPMAN0148 (Rev. 5/16/2008)
- Page 19 RB1172, RB1184, RB1196 PARTS LIST PART RB1172 RB1184 RB1196 DESCRIPTION 5WP1026709 A-Frame with decals 5WPHBL228 Pin, Clevis 1.00 x 5.00 5WP216241 Bolt, HH 1 In NC x 7 GR8 Washer, Flat 1 In Standard 5WP34279 Nut, Lock 1 In NC...
- Page 20 TAILWHEEL KIT 5WP1001533 (OPTIONAL) PART DESCRIPTION 5WP1001530 Plate, Tailwheel Retainer 5WP57817 Washer, Flat 5/8 SAE Hardened Nut, Lock 5/8 NC 5WP1001534 Bar, Tailwheel Mast Screw, HHCS 5/8 NC x 2 GR5 5WP1001535 Tailwheel Tube Assembly Screw, HHCS 5/8 NC x 4-1/2 GR5 5WP13853 Pin, Spirol 3/8 x 1-3/4 5WP15314...
- Page 21 SKID SHOE ASSEMBLY 5WP18300 (OPTIONAL) PART DESCRIPTION ------------ Moldboard Assembly 5WP27586 Skid & Shaft Assembly 5WP27592 Bracket, Skid Shoe Right (not shown) (earlier model grease fitting located above plate) -or- 5WP1005328 Bracket, Skid Shoe Right (not shown) 5WP27593 Bracket, Skid Shoe Left (earlier model grease fitting located above plate) -or- 5WP1005329 Bracket, Skid Shoe Left...
-
Page 22: Bolt Torque Chart
BOLT TORQUE CHART Always tighten hardware to these values unless a different torque value or tightening procedure is listed for a specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware: SAE for SAE hardware and Metric for metric hardware. Make sure fastener threads are clean and you start thread engagement properly. -
Page 23: Bolt Size Chart & Abbreviations
BOLT SIZE CHART NOTE: Chart shows bolt thread sizes and corresponding head (wrench) sizes for standard SAE and metric bolts. SAE Bolt Thread Sizes 5/16 Metric Bolt Thread Sizes 10MM 12MM 14MM 16MM 18MM ABBREVIATIONS AG .............. Agriculture MPa............Mega Pascal ASABE.... - Page 24 ©2001 Woods Equipment Company. All rights reserved. WOODS and the Woods logo are trademarks of Woods Equipment Company. Frontier Equipment and the Frontier logo are trademarks of Deere & Company. All other trademarks, trade names, or service marks that appear in this man-...
