To facilitate parts ordering, record the model and serial number of your unit in the space provided on this page. This information may be obtained from the identification plate located on the product. Any questions related to this attachment should be directed to your local Frontier dealer. MODEL:__________________________ DATE: ______________________________ SERIAL NUMBER: ___________________________ (See parts section for location.)
SAFETY STATEMENTS THIS SYMBOL BY ITSELF OR WITH A WARNING WORD THROUGHOUT THIS MAN- UAL IS USED TO CALL YOUR ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY OR THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH. DANGER THIS SIGNAL WORD IS USED WHERE SERIOUS INJURY OR DEATH WILL RESULT IF THE INSTRUCTIONS ARE NOT FOLLOWED PROPERLY.
Page 6
GENERAL SAFETY PRECAUTIONS WARNING! PROTECT AGAINST FLYING DEBRIS Always wear proper safety glasses, goggles, or a face shield when driving pins in or out, or when any operation causes dust, flying debris, or any other hazardous mate- rial. WARNING! LOWER OR SUPPORT RAISED EQUIPMENT Do not work under raised booms without supporting them.
GENERAL SAFETY PRECAUTIONS WARNING! DO NOT MODIFY MACHINE OR ATTACHMENTS Modifications may weaken the integrity of the attachment and may impair the func- tion, safety, life, and performance of the attachment. When making repairs, use only the manufacturer’s genuine parts, following authorized instructions. Other parts may be substandard in fit and quality.
Before performing maintenance, lower the attachment to the ground, apply the brakes, turn off the engine, and remove the key. • Worn, damaged, or illegible safety decals must be replaced. New safety decals can be ordered from your Frontier Dealer. • Never work under a raised attachment. OPERATING ALL ATTACHMENTS •...
Page 9
Do not handle round bales. • Do not exceed the lift capacity of your loader. See loader specifications. ADDITIONAL PRECAUTIONS FOR AD11 & AD12 SERIES DEBRIS BUCKETS & AV20F ROOT GRAPPLE • Do not heap load heavy material where the combined weight of the bucket and the ma- terial could exceed the rated lifting capacity of the loader.
SET-UP GENERAL INFORMATION The AY11 & AY12 Series 4-in-1 buckets, the AD11 & AD12 Series debris buckets, the AR10 & AR12 Series rock buckets, the AV20 root grapple and the AM11 Series Manure Fork with Grapple are shipped completely assembled and ready to install without any set-up required.
INSTALLATION ATTACHING Attaching the equipment listed in this manual is the same as attaching a standard bucket. Follow the attaching instructions in your specific loader manual. If a grapple or 4-in-1 bucket is being installed, relieve pressure from the auxiliary hydraulic lines to be used with equipment per the manufacturer’s manual.
INSTALLATION STORAGE: • Clean the unit thoroughly, removing all mud, dirt, and grease. • Inspect for visible signs of wear, breakage, or damage. Order any parts required and make the necessary repairs to avoid delays upon removal from storage. • Tighten loose hardware and hydraulic connections.
4-IN-1 BUCKET OPERATION AY11 & AY12 SERIES 4-IN-1 BUCKETS Read all Safety Precautions before operating your new attachment. Refer to your machines operator’s manual for attachment operation. All AY11 & AY12 Series 4-IN-1 buckets are designed for various functions such as, dig- ging with the bucket, grabbing with the clam, bulldozing, scraping or backfilling with the back blade and bottom dumping.
Page 14
4-IN-1 BUCKET OPERATION AY11 & AY12 SERIES 4-IN-1 BUCKETS Operate the attachment only when properly seated at the operator’s station. Do not exceed the lift capacity of your loader. See loader specifications. Do not handle round bales. When using the clam, lift the load slightly and make sure that the load is se- cure.
Read all Safety Precautions before operating your new attachment. Refer to your machines operator’s manual for attachment operation. All AD11 & AD12 Series debris buckets are designed to pick up bulky, unusually shaped, or long materials that would not stay in an ordinary bucket.
ROOT GRAPPLE OPERATION AV20F ROOT GRAPPLE Read all Safety Precautions before operating your new attachment. Refer to your machines operator’s manual for attachment operation. All AV20F root grapple is designed to pick up bulky, unusually shaped, or long materials that would not stay in an ordinary bucket. In addition the root grapple is designed to rake large debris into a pile for easy pick up while leaving the soil and small rocks etc.
ROCK BUCKET OPERATION AR10 & AR12 SERIES ROCK BUCKETS Read all Safety Precautions before operating your new attachment. Refer to your machines operator’s manual for attachment operation. All AR10 & AR11 Series rock buckets are designed to collect rocks and debris, allowing the soil to sift through.
MANURE FORK AND GRAPPLE OPERATION AM11 SERIES MANURE FORK AND GRAPPLES Read all Safety Precautions before operating your new attachment. Refer to your machines operator’s manual for attachment operation. All AM11 Series manure fork and grapples are designed for moving loose hay, manure, brush and small branches.
AY11F ONLY = 2 (One fitting on each clam/back blade pivot pin.) AD11 & AD12 Series Debris Buckets = 8 (One fitting on each end of cylinders and on each grapple pin.) AV20F Root Grapple = 2 (One fitting on each grapple pin.) AR10 &...
When replacing parts with safety signs attached, the safety sign must also be replaced. All Safety Decals are free of charge. Contact your local Frontier dealer for replacements. REPLACING SAFETY SIGNS: Clean the area of application with nonflammable solvent.
MAINTENANCE WARNING! Disconnect cylinder carefully from hydraulic hoses after removal from at- tachment. Hydraulic oil under pressure can cause severe injury or death. CYLINDER SEAL REPLACEMENT The following information is provided to assist you in the event you should need to repair or rebuild a hy- draulic cylinder.
Page 22
MAINTENANCE Now insert the seal into the gland from the inner end. Position the seal in its groove, and release and remove the tool. Press the seal into its seat the rest of the way by hand. Install the new piston ring, rod wiper, O-rings and backup washers, if ap- plicable, on the piston.
TROUBLESHOOTING POSSIBLE CAUSE POSSIBLE SOLUTION PROBLEM GRAPPLE OR CLAM Cold Oil. Warm oil at idle speed. FUNCTIONS SLOWLY Oil leaking past cylinder packings. Replace cylinder seal kit. Obstruction in hydraulic lines. Remove obstruction. GRAPPLE OR CLAM Low oil supply. Add oil. FAILS TO FUNCTION.
Page 25
SPECIFICATIONS LOADER SERIES COMPATIBILITY: A=800 SERIES D=600/700 SERIES E=300/400/500 SERIES F=100/200/300/400/500 SERIES G=GLOBAL CARRIER SERIES H=300/400 SERIES AR12 SERIES ROCK BUCKET SPECIFICATIONS Model Compatibility & Size AR12A 84” AR12D 84” AR12G 84” AR12A 93” AR12D 93” AR12G 93” Overall Height (inches) 34.83 Overall Width (inches) 94.15...
BOLT TORQUE BOLT TORQUE SPECIFICATIONS GENERAL TORQUE SPECIFICATION TABLES Use the following charts when determining bolt torque specifications when special torques are not given. Always use grade 5 or better when replacing bolts. SAE BOLT TORQUE SPECIFICATIONS NOTE: The following torque values are for use with extreme pressure lubricants, plating or hard washer applications Increase torque 15% when using hardware that is unplated and either dry or lubricated with engine oil.
AR10 & AR12 SERIES ROCK BUCKET 300, 400, 500, 600, 700 & GLOBAL CARRIER SERIES LOADERS 76314...
Page 69
AR10 & AR12 SERIES ROCK BUCKET 300, 400, 500, 600, 700 & GLOBAL CARRIER SERIES LOADERS ITEM REQ’D PART NO. DESCRIPTION Rock Bucket with 2” Tine Spacing 5MP108652 AR10H 55” Rock Bucket (300/400 Series Loaders) 5MP106177 AR10E 66” Rock Bucket (300/400/500 Series Loaders) 5MP101788 AR10E 75”...
OPTIONAL ROCK BUCKET GRAPPLE AR10 SERIES 66” & 75” ROCK BUCKETS 76314...
Page 71
OPTIONAL ROCK BUCKET GRAPPLE AR10 SERIES 66” & 75” ROCK BUCKETS ITEM REQ’D PART NO. DESCRIPTION ----- Serial Number Identification Tag Location 5MP40151 Warning Decal, High Pressure Fluid 5MP38359 1/4” Hose X 15” 6FJX-6FJX 90° Long 5MP30383 Straight Connector 6MJ-6FJ W/.0625 Orifice 5MP30379 Bulkhead Tee 6MJ-6MJ-6MJ (Includes Nut) 5MP38114...
5MP107610 HYDRAULIC KIT ADAPTS FROM 1/4” BODY COUPLERS TO 1/2” BODY COUPLERS 76314...
Page 75
5MP107610 HYDRAULIC KIT ADAPTS FROM 1/4” BODY COUPLERS TO 1/2” BODY COUPLERS ITEM REQ’D PART NO. DESCRIPTION 5MP17139 Male Coupler 8FBo 1/2” Body 5MP17140 Female Coupler 8FBo 1/2” Body 5MP3338 Straight Connector 8MBo-6FBo INSTALLATION INSTRUCTIONS: Remove existing 1/4” Body couplers from the power and return lines on the attachment. Install Straight Connectors (5MP3338) into the existing fittings.
