- Page 1 Assembly Instructions INFM7013, INFM7113, INFM7213 Infinity Mounting set Etac Cross 6 / Cross 6 Long 2024-02 Revision 3...
-
Page 2: General Instructions
Particularly important or explanatory information General instructions These instructions shall always be followed when placing the mounting set INFM7013, INFM7113, INFM7213 Mounting set Etac Cross 6 / Cross 6 Long on a wheelchair. To be able to connect Infinity to the wheelchair Infinity also needs to be adjusted according to the assembly instructions that is included in the delivery of Infinity. - Page 3 Mounting set INFM7013, INFM7113, INFM7213 __________________________________________________________________________________ 2. Overview A Center pipe adapter bar B Outer pipe adapter bar C Clamp adapter bar D Holder adapter bar E QR-Pin F Adapter plate G Spacer adapter plate front H Spacer adapter plate rear...
- Page 4 Mounting set INFM7013, INFM7113, INFM7213 __________________________________________________________________________________ 3. Assembly and adjustment of adaptor First mount the adapter plate (F), spacer adapter plate (G & H), washer adapter plate (I). This is kept into place using screws (J) that is tightened on the outside of the frame using spring washer (K) and domed nut (L).
- Page 5 Mounting set INFM7013, INFM7113, INFM7213 __________________________________________________________________________________ Now mount the complete adapter bar that consists of center pipe (A), outer pipe (B) and clamp (C). The complete adapter bar is mounted into the holders (D) by using the QR-pins (E). Make sure the ends of the outer pipe...
- Page 6 Mounting set INFM7013, INFM7113, INFM7213 __________________________________________________________________________________ INFO Now use the leveling tool that is included in the delivery of Infinity. Since the adapter bar have splines inside it will not be possible to get the bubble of the spirit level exactly right.
- Page 7 Mounting set INFM7013, INFM7113, INFM7213 __________________________________________________________________________________ Alt.2 Using the adjustment tool that is included in the delivery of Infinity (not this mounting set), set the angle of the adaptorbar. Only mount the inner pipe on one side and then rotate the center pipe to the correct angle. Now mount the other inne pipe in the same position/angle as the first one.
- Page 8 Decon Wheel AB Södra Ekeryd 119, SE-314 93 Hyltebruk, Sweden Tel: +46 (0)345 40880 Fax: +46 (0)345 40895 E-mail: info@decon.se...
