- Page 1 Adventus Folding wheelchair adaptor Assembly Instructions...
- Page 2 Adventus Folding wheelchair adaptor, Assembly Instructions Rev0 __________________________________________________________________________________ 1. Overview Picture1 A Holder adapter bar B QR-pin C Adapter bar D Fork adapter bar E Adjustment tool...
- Page 3 Adventus Folding wheelchair adaptor, Assembly Instructions Rev0 __________________________________________________________________________________ 2. Mounting of adapter bar First mount the holder (A). The shape of the holder can vary depending on wheelchair model. Mount the holders so that they still can be moved along the wheelchair chassis. Now mount the adapter bar (C) into the holders (A) by using the QR-Pins (B).
- Page 4 Adventus Folding wheelchair adaptor, Assembly Instructions Rev0 __________________________________________________________________________________ Picture6, Holder mounted on both sides Picture7, Mount the adapter bar into the holders using the QR-pins Picture8, Mounted adapter bar...
- Page 5 Adventus Folding wheelchair adaptor, Assembly Instructions Rev0 __________________________________________________________________________________ 3. Adjustment of adapter bar Step 3.1 Mount the adjustment toll onto the fork (D). Remove the screws in the fork that locks the rotation (see picture bellow). Also make sure that the fork sits in the center of the wheelchair.
- Page 6 Adventus Folding wheelchair adaptor, Assembly Instructions Rev0 __________________________________________________________________________________ Step 3.2 Now rotate both the adapter bar and the fork to a position where the adjustment tool shows the correct angle and the fork doesn’t collide with the footrests. If possible, make sure that the fork doesn’t sit lower than the footrest and that the height, if possible, corresponds to the...
- Page 7 Adventus Folding wheelchair adaptor, Assembly Instructions Rev0 __________________________________________________________________________________ Step 3.3 Reassemble the screw in the hole that is fits the best, se picture bellow for example. Picture13...
- Page 8 Also make sure one last time that the fork is centered and the angle of the adjustment tool is still correct. Picture14 Step 3.5 Check one last time that all screws are properly secured. Now see the user manual of Adventus to continue the installation. This can be downloaded from www.decon.se/en/.
