- Page 1 WOOD PELLET GRILLS ZPG-550A2E OWNER’S MANUAL MON TO FRI, 8:00 A.M. - 5:00 P.M. PACIFIC STANDARD TIME SERVICE CONTACT: 1-833-947-4557/1-833-ZGRILLS EMAIL: support@zgrills.com WEBSITE: www.zgrills.com VN052024...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT SAFETY INFO COMPONENT LIST ASSEMBLY INSTRUCTIONS SUBSEQUENT START-UP OPERATING TIPS MAINTENANCE & CLEANING TROUBLESHOOTING DIGITAL THERMOSTAT CONTROL WIRING DIAGRAM Z GRILLS SUPPORT 3-Y LIMITED WARRANTY INITIAL FIRING INSTRUCTIONS... - Page 4 SAVE THIS MANUAL FOR FUTURE REFERENCE...
-
Page 5: Important Safety Info
IMPORTANT SAFETY INFO GENERAL WARNINGS Please read this entire manual before installation and use of the pellet fuel-burning appliance. Failure to follow these instructions could result in property damage, bodily injury or even death. Contact local building or fire officials about restrictions and installation inspection requirements in your area. - Page 6 DO NOT place anything heavy on top of hopper lid. It is not a shelf and is a tip hazard. Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or ‘freshen up’ a fire in this appliance. Keep all such liquids well away from the appliance when in use.
- Page 7 There is no guarantee that other brands of pellets are suitable for use in Z GRILLS. And Z GRILLS assumes no liability for any loss, damage or injury caused by the use of any other brands of pellets.
-
Page 8: Component List
COMPONENT LIST ITEM DESCRIPTION ITEM DESCRIPTION Grill Chamber Grease Drain Pan holder Hopper Assembly Frame Handle Base Warming Rack Axle Porcelain Grills Hopper Shell Grease Drain Pan Digital Control RTD Temperature Probe Lower Hopper Guard Hinge Axle Hopper Side Handle Lid Handle ,side Auger Tube Bushing Handle Guide... - Page 9 HARDWARE PACKAGE LIST ITEM DESCRIPTION DESCRIPTION Screwdriver Nylon lock nuts5/16-18 Open End Wrench Gasket (OD0.59×ID0.26) Extemal hexagon screw 1/4-20*2- Bolt 1/4-20×1/2 Hex Nut1/4-20 Open End Wrench Gasket (OD0.79×ID0.33) Hexagon Bolt 1/4-20*3/4 Spring Washer (OD0.51×ID0.33) Gasket (OD0.78*×ID0.25)
-
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS PARTS DIAGRAM HOPPER BURNER ASSEMBLY... - Page 11 1. Leg assembly: 1) Use the packing materials under the furnace body, take the right front leg (18) and right rear leg (17), Assemble them into the furnace body through the support hole according to the drawing using screws(C) and gaskets(H). 2) Remove the left front leg (20) and left rear leg (19), Assemble them into the furnace body through the support hole according to the drawing using screws(C) and gaskets(H).
- Page 12 3.Wheels assembly 1.Take out the wheel (24), axle (27), flat washer (E), spring washer (F), and cap nut (G). Assemble them in order according to the diagram from the outside to the inside, and tighten them after assembling. The assembly method on both sides is the same. 2.Place the entire machine upright and use a screwdriver (A) to tighten all the leg screws.
- Page 13 6.Lid handle assembly 1. As shown in the picture, use screws(K) to pass through the washers(L) , lid (10) and lid handle base (9) assemble in sequence into the lid handle (46). The installation method on the other side is the same. After assembly, use an open-ended wrench to tighten it. 7.The chimney, the chimney cap assembly 1.
- Page 14 9.Heat Baffle assembly 1.Place the lower bracket of Heat Baffle (15) onto the bracket of Heat Baffle , as shown in Figure left. 2.After placement, see Figure right. 10.Grease Drain Pan assembly 1.Insert the two square holes at the left end of Grease Drain Pan into the two corners of the bracket in the furnace body, as shown in Figure left.
- Page 15 11.Installing the cooking grate and warming rack,Handle ,shelf 1.Install the Porcelain Grills (4) and Warming Rack (3) into the Chamber. 2.As shown in the figure right, use screws (I) to pass through the legs, frame handle base (26), frame handle (22), and nuts to assemble in sequence.
-
Page 16: Subsequent Start-Up
Temperature Dial to any cooking setting desired. 5.If this step is not successful, see TROUBLESHOOTING or contact Z GRILLS Technical Support to help diagnose the problem. -
Page 17: Operating Tips
OPERATING TIPS 1.Like all grills, the actual temperature of this grill and the cooking times will be affected by external temperature, humidity, wind conditions, quality of pellets, etc. 2.It is beneficial to shelter your grill from the wind. This will aid in temperature output, heat retention and heat recovery time when the lid is open. -
Page 18: Maintenance & Cleaning
2.It is highly recommended that you use Z GRILLS Cover to protect your grill . 3.You can use a high-quality car wax on the outside surfaces of your grill to protect it’s finish. - Page 19 Clean the ash from the interior of the grill periodically. If excessive ash is in the firepot, it may cause the fire to go out. This is especially true in the SMOKE setting. A shop vac is an excellent tool to use for removing the ash. WARNING: MAKE SURE THE GRILL FIRE IS OUT, THE UNIT IS OFF, UNPLUGGED AND COLD BEFORE ATTEMPTING TO CLEAN ASH FROM THE GRILL.
-
Page 20: Troubleshooting
TROUBLESHOOTING CAUTION: Make sure the grill is completely cool and unplugged before you do any inspection, cleaning, maintenance or service work. Potential Problem Solution Cause Make sure the power cord is plugged Power in. Verify there is power at the electrical outlet. - Page 21 Pellets pellets. When contacting customer support Contact please have the following information Z GRILLS available: Your authorized Z Grills Customer dealer, your name, phone number, Get your new parts Service or your address, your Z Grill serial number and Z GRILLS part identification number.
-
Page 22: Digital Thermostat Control Wiring Diagram
DIGITAL THERMOSTAT CONTROL WIRING DIAGRAM... -
Page 23: Z Grills Support
Thank you for purchasing a Z GRILL! If you have any question, please contact customer support or your Z GRILL dealer. Z GRILLS, INC. offers the best technical and sales support in the industry. When calling customer please be prepared to provide the following information: 1.Dealer's name and date of purchase... -
Page 24: 3-Y Limited Warranty
Z GRILLS, Inc. shall not be liable if you install, operate, clean or maintain your grill without following the owners' manual instructions. Misuse, abuse, alteration and natural disasters... -
Page 25: Initial Firing Instructions
Please read this manual carefully and follow it step by step before starting your Z Grills for the first time and each time the grill runs out of pellets. 1.Remove the Porcelain Grills, Grease Drain Pan and Heat Baffle from the interior of the grill.
