Server IxD Series Manual page 7

Summary of Assembly Instructions
6 6 6
B2
2
3
5
12 11 10 9 8 7
6 6 6
2
B1
4
6 5 4 3 2 1
Back View Assembly
6
C1
4
Start by stacking unit as shown with backs facing you.
1
5
14 13
Install 2 stabilizing brackets, make sure the
2
threaded shafts are on top.
6
3
A
4
8 8 7
5
9 6
10 5
11 4
5
12 3
13 2
HELPFUL TIPS:
14 1
6
7
HELPFUL TIP:
Have the unit turned 45° to you. This
helps with the assembly process.
Cabinets A & B1 (with base installed) on bottom.
Cabinets B2 & C1 on top.
Install metal connector strip on the threaded shafts.
Screw black knob onto threaded shafts.
Using hoses from bags 101580, 101463,
&101738, snap-in back hoses as shown
making sure to match the numbers at both
ends of the hose.
Start with the highest number and
work your way down to #1.
Make sure that hoses are not kinked.
Hang metal back cover panels. There is one
panel per cabinet. (101448 (2) & 101445(2))
• Align the holes in the panels over the
pegs and drop down into place. Secure
with provided screws (101837)
Rotate the unit so that the front is facing you.
ROTATE
UNIT
45°
(2x) 101448
(2x) 101445
(4x) 101837
7
