Detailed Assembly & Setup Instructions
9
Remove the knobs
from the two back
stabilizing brackets
then place the long
thin bracket over the
two back brackets
and then replace the
knobs to hold the unit
into place.
11
Put the back covers (101448 (2) &
101445 (2)) on each cabinet. Align
the holes on the panels over the
pegs and drop down into place and
secure with screws (101837).
13
The user
interface will
turn on. You'll
be prompted
through the
setup process.
15
You'll be
prompted to
set the date
and time
and unit of
measurement.
10
10
12 11 10 9 8 7 14 13
8 7
9 6
10 5
HELPFUL TIPS:
11 4
12 3
13 2
Start with the highest number and
14 1
work your way down to #1.
6 5 4 3 2 1
Make sure that hoses are not kinked.
12
14
16
Using hoses from bags 101580,
101463, & 101738, connect the
back tubing matching the number
from the A or E unit with the
corresponding number on the other
cabinets. Do this for all of the back
connections.
12 11 10 9
6 5 4 3
Plug the power cord into an
outlet.
Select the
connection
type, choose the
network and add
the password.
Select the
default setup.
Select the
system bottle
quantity.
Manual #IxDM_Flavor+_101810 061224
