3 DIMENSIONS, CLEARANCES, WEIGHT DISTRIBUTION

3.1 - BW05 020-045 - unit without hydronic module (standard)

1
50
900
3.2 - BW05 020-045 - unit with hydronic module (option) and/or unit with option 116E (Victaulic water connection at
the top)
1
700
Legend:
All dimensions are in mm.
Water inlet
Water outlet
A Condenser (water inlet/outlet)
B Evaporator
C Refrigerant inlet/outlet
q
Clearances required for maintenance
Power supply
8
695
1
900
C
A B
1204
B
695
1
700
BW05 020-030
A 1-1/4" Gas
B 1-1/4" Gas
NOTE: Non-contractual drawings.
Refer to the certified dimensional drawings.
For the positioning of the fixing points, weight distribution
and centre of gravity coordinates, also refer to the certified
drawings.
A
1
900
BW05 040-045
2" Gas
2" Gas
VUGFB102
