3.4 - BW05 160-300 - unit without hydronic module (standard)

B
1
1100

3.5 - BW05 160-300 - unit with hydronic module (option)

1
1100
Legend:
All dimensions are in mm.
Water inlet
Water outlet
A Condenser (water inlet/outlet)
B Evaporator
C Refrigerant inlet/outlet
q
Clearances required for maintenance q
Power supply
10
922
A
922
1
700
C
1
700
2950
NOTE: Non-contractual drawings.
Refer to the certified dimensional drawings.
For the positioning of the fixing points, weight distribution
and centre of gravity coordinates, also refer to the certified
drawings.
2300
2013
1
700
A
C
B
1
700
VUGFB102
