OIP-N40E/ OIP-N60D/ OIP-N60D, Dante AV-H
AVoIP Encoder/AVoIP Decoder
User Manual - English
Version OIA001k/ OIB001k
[Important]
To download the latest version of Quick Start
Guide, multilingual user manual, software, or
driver, etc., please visit Lumens
https://www.MyLumens.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OIP-N40E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens OIP-N40E

Summary of Contents for Lumens OIP-N40E

  • Page 1 OIP-N40E/ OIP-N60D/ OIP-N60D, Dante AV-H AVoIP Encoder/AVoIP Decoder User Manual - English Version OIA001k/ OIB001k [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    3.2 Operate via webpages ................... 5 Chapter 4 Product Application and Connection ........6 4.1 HDMI Signal Source Transmission Network (For OIP-N40E) ..... 6 4.2 Virtual USB Network Camera (For OIP-N60D) ..........6 4.3 USB Network Camera Extension (OIP-N40E/OIP-N60D required) ... 7 Chapter 5 Setting Menu ................

  • Page 3: Chapter 1 Package Contents

    Chapter 1 Package Contents USB 2.0 cable (1.8 M) Encoder/Decoder Locking metal plate (x2) (Type A Type C) M3 metal plate screw (4x4)

  • Page 4: Chapter 2 Product Installation

    Chapter 2 Product Installation 2.1 I/O Interface OIP-N40E OIP-N60D USB-C cables are recommended to have a transmission speed specification of 10Gbps or higher 2.2 Product Installation  Using the accessory metal plates Lock the accessory metal plate with screws (M3 x 4) to...

  • Page 5: Description Of Indicator Display

    2.3 Description of Indicator Display Power Status Tally Status Power Standby Tally Startup in progress Flickering Red light (initialization) Red/Green light Signal No Signal In use Red light Green light Preview Green light Program Red light...

  • Page 6: Chapter 3 Product Operation

    Chapter 3 Product Operation 3.1 Operate through the body button Connect the HDMI OUT to the display, press the Menu dial to enter the OSD menu. Through the Menu dial to navigate the menu and adjust the parameters  Rotate: Adjust parameters and Navigate in the menu ...

  • Page 7: Chapter 4 Product Application And Connection

    Chapter 4 Product Application and Connection 4.1 HDMI Signal Source Transmission Network (For OIP-N40E) OIP-N40E can transmit HDMI signal source to IP devices (1) Connection Method  Connect the signal source device to the encoder's HDMI or USB-C input port using HDMI or USB-C monitor transmission cable ...

  • Page 8: Usb Network Camera Extension (Oip-N40E/Oip-N60D Required)

    4.3 USB Network Camera Extension (OIP-N40E/OIP-N60D required) When used with the OIP-N encoder and decoder, it can extend the range of USB cameras through the network to improve installation flexibility. (1) Connection Method  Connect the OIP-N encoder/decoder to the local network ...

  • Page 9: Chapter 5 Setting Menu

    Chapter 5 Setting Menu Through body button [Menu] to enter the setting menu; the bold underlined values in the following table are defaults. 5.1 OIP-N40E 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values NDI/ SRT/ RTMP/ RTMPS/ HLS/...

  • Page 10: Chapter 6 Webpage Interface

    Open the browser, and enter the URL of OIP-N in the IP address bar E.g.: http://192.168.4.147 Enter administrator’s account and password For a first-time login, please refer to 6.1.10 System- User to change the default password Lumens OIP-N Encoder/Decoder  Account: admin  Password: 9999 (Default)

  • Page 11: Webpage Menu Description

    6.3 Webpage Menu Description 6.3.1 Dashboard Function Descriptions Display encoder/decoder output/input, encoding/decoding, and system-related information 6.3.2 Stream (Applicable to OIP-N40E) Item Description Source Choose the signal source Resolution Set output resolution Frame Rate Set frame rate IP Ratio Set IP Ratio...
  • Page 12  Group Name: The group name can be modified here and set with Access Manager - Receive in NDI Tool  NDI|HX: HX2/HX3 is supported  Multicast: Enable/Disable Multicast It is suggested to enable Multicast when the number of users online watching the live image simultaneously is more than 4 ...
  • Page 13 The group name can be modified here and set with Access Manager - Receive in NDI Tool Server IP Discovery service. Check to enter the Server IP address 6.3.4 Audio (Applicable to OIP-N40E) Item Description  Audio In: Enable/disable audio...
  • Page 14  Encode Type: Encode Type AAC  Encode Sample Rate: Set Encode sample rate  Audio Volume: Volume adjustment  Audio In: Enable/disable audio  Encode Sample Rate: Set Encode sample rate Stream Audio Enable  Audio Volume: Volume adjustment ...
  • Page 15 6.3.6 System- Output (Applicable to OIP-N40E) Item Description Device Name/Location  The name is limited to 1 - 12 characters  The location is limited to 1 - 11 characters  Please use uppercase and lowercase letters or numbers for characters. Special Device ID/ Location symbols such as “/”...
  • Page 16 6.3.7 System- Output (Applicable to OIP-N60D) Item Description Device Name/Location  The name is limited to 1 - 12 characters  The location is limited to 1 - 11 characters  Please use uppercase and lowercase letters or numbers for characters. Special Device ID/ Location symbols such as “/”...
  • Page 17 function is closed HTTP Port Set HTTP port. The default Port value is 80 6.3.9 System- Date & Time Function Descriptions Display the current device/computer date and time, and set the display format and synchronization way When Manually Set is selected for [Time Settings], Date & Time can be customized 6.3.10 System- User Function Descriptions...
  • Page 18 6.3.11 Maintenance Item Description Click on the link to the Lumens website and enter the model to obtain the latest Firmware link firmware version information Select the firmware file, and click [Upgrade] to update the firmware Update takes about 2 - 3 minutes...

  • Page 19: Chapter 7 Troubleshooting

    1. Confirm that the cables are fully connected. Please refer to Chapter 4, Product Application and Connection OIP-N40E cannot display the signal 2. Confirm that the input signal source resolution is 1080p or 720p source screen 3. Confirm that USB-C cables are recommended to use specifications...

  • Page 20: Chapter 8 Safety Instructions

    Chapter 8 Safety Instructions Always follow these safety instructions when setting up and using the product: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat. 1.2 Do not place the product on a tilted or unstable trolley, stand or table. 1.3 Please clean the dust on the power plug prior to usage.
  • Page 21  IC Warning This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled "Digital Apparatus," ICES-003 of Industry Canada. Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe B prescrites dans la norme sur le material brouilleur: "Appareils Numeriques,"...

  • Page 22: Copyright Information

    Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
