Lumens Dante OIP-N60D User Manual

Av-h bridge
Hide thumbs Also See for Dante OIP-N60D:
Table of Contents

Advertisement

Quick Links

Download this manual
OIP-N60D/ OIP-N60D, Dante AV-H Bridge
User Manual - English
[Important]
To download the latest version of Quick Start
Guide, multilingual user manual, software, or
driver, etc., please visit Lumens
https://www.MyLumens.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dante OIP-N60D and is the answer not in the manual?

Questions and answers

Related Manuals for Lumens Dante OIP-N60D

Summary of Contents for Lumens Dante OIP-N60D

  • Page 1 OIP-N60D/ OIP-N60D, Dante AV-H Bridge User Manual - English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Package Contents ..............2 Chapter 2 Product Installation ..............3 2.1 I/O Interface ......................3 2.2 Product Installation ....................3 2.3 Description of Indicator Display ................. 4 Chapter 3 Product Operation ..............5 3.1 Operating using the rocker switch ..............5 3.2 Operate via webpages ...................

  • Page 3: Chapter 1 Package Contents

    Chapter 1 Package Contents USB 2.0 cable (1.8 M) OIP –N60D Bridge Locking metal plate (x2) (Type A Type C) M3 metal plate screw (4x4)

  • Page 4: Chapter 2 Product Installation

    Chapter 2 Product Installation 2.1 I/O Interface We recommended using high-performance USB-C cables (10Gbps or higher) 2.2 Product Installation  Using the accessory metal plates Lock the accessory metal plate with screws (M3 x 4) to Screw the metal plate to the desk or other surface as the lock holes on both sides of the OIP Bridge required.

  • Page 5: Description Of Indicator Display

    2.3 Description of Indicator Display Power Status Tally Status Power Standby Tally Startup in progress Flickering Red light (initialization) Red/Green light Signal No Signal In use Red light Green light Preview Green light Program Red light...

  • Page 6: Chapter 3 Product Operation

    Chapter 3 Product Operation 3.1 Operating using the rocker switch Connect the HDMI OUT to the display, press the Menu dial to enter the OSD menu. Move the rocker switch to navigate the menu and adjust the parameters  Rotate: Adjust parameters and Navigate in the menu ...

  • Page 7: Chapter 4 Product Application And Connection

     Launch Zoom, Microsoft Teams, or your preferred conferencing application.  In the application, change the video source to: Source Name: Lumens OIP-N60D 4.2 USB Network Camera Extension (OIP-N40E/OIP-N60D required) OIP supports network bridging. Use OIP-N40E with OIP-N60D to extend the range of USB cameras over the local area network.
  • Page 8 (2) OIP-N60D Webpage Settings [System] > [Output], open USB Extender (3) OIP-N40E Webpage Settings  [System] > [Output] > Extender Source List  [Search new Source] > Click [Available] to select the OIP-N60D > Connection displays Connected (4) USB Camera Screen Output ...

  • Page 9: Chapter 5 Setting Menu

    Chapter 5 Setting Menu Using the rocker switch [Menu] enter the setting menu; the bold underlined values in the following table are defaults. 5.1 OIP-N60D 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Source List Display the signal source list Blank Screen Source...

  • Page 10: Chapter 6 Webpage Interface

    Open the browser, and enter the URL of OIP-N in the IP address bar E.g.: http://192.168.4.147 Enter the administrator’s account and password For a first-time login, please refer to 6.1.10 System- User to change the default password Lumens OIP Bridge  Account: admin  Password: 9999 (Default)

  • Page 11: Webpage Menu Description

    6.3 Webpage Menu Description 6.3.1 Dashboard Function Descriptions Display output, source, and system related information...
  • Page 12 6.3.2 Stream Item Description Search New Source Click to search for devices in the same network segment and display them in a list Search Mode (Only exists in Search from NDI&ONVIF / Only NDI / Only ONVIF non-Dante version) +Add Manually add a device Edit Edit a connected device in the list.

  • Page 13: Dante Controller

    Dante controller To ensure the unit OIP-N60D can be recognized by the Dante Controller after enabling the Dante function, please follow the steps below: 1. Access the OIP-N60D web page 2. Navigate to the [Source] section 3. Select [Dante AV-H] as the source 4.
  • Page 14  Encode Type: AAC  Encode Sample Rate: 48KHz  Audio Volume: Volume adjustment 0~10  Audio Out From: Follow Routing / Follow Stream / Follow Dante  Audio Volume: Volume adjustment 0~10 HDMI Audio Out  Audio Delay: Enable/disable Audio Delay, set the audio delay time (-1 ~ -500 ms) after Enable enabling ...
  • Page 15  PIP: Shrink the Source2 image into a smaller window overlaid on the Source 1 image. Layout Selection: Choose the position Upper left / Upper Right / Lower left / Lower Right Size Selection: Choose the size Small / Normal / Large ...
  • Page 16 1. Size: (unit: 0.1mm) Overall Width: Enter the total width of the display wall Overall Height: Enter the total height of the display wall Video Width: Enter the width of the video signal source Video Height: Enter the height of the video signal source 2.

  • Page 17: System- Output

    6.3.5 System- Output Item Description Device Name/Location  The name is limited to 1 - 12 characters  The location is limited to 1 - 11 characters Device ID/ Location  Please use uppercase and lowercase letters or numbers for characters. Special symbols such as “/”...

  • Page 18: System Network

    6.3.6 System- Network Item Description Ethernet setting for OIP Bridge. Change of setting is available when DHCP function is DHCP disabled. HTTP Port Set HTTP port. The default Port value is 80 6.3.7 System- Date & Time Function Descriptions Display the current device/computer date and time, and set the display format and synchronization method When Manually Set is selected for [Time Settings], Date &...
  • Page 19 6.3.8 System- User Function Descriptions Add/Modify/Delete user account  Supporting 4 - 32 characters for user name and password  Please use uppercase and lowercase letters or numbers for characters. Special symbols or the underlined cannot be used  Authentication Mode: Set the new account management permissions User Type Admin Viewer...
  • Page 20 6.3.9 System – Security Function Descriptions HTTP Authentication: Choose from Digest / Basic / Off 802.1x Setting: Enable / Disable 6.3.10 System – Control Function Descriptions HELLO: Enable this button to make the indicator light on the unit blink for one minute. It will then automatically turn off.

  • Page 21: Maintenance - Update

    6.3.11 Maintenance - Update Item Description Click on the link to the Lumens website and enter the model to obtain the latest Firmware link firmware version information Select the firmware file, and click [Upgrade] to update the firmware Update takes about 2 - 3 minutes...
  • Page 22 Daily Reboot Time: Set the exact time the unit will automatically reboot. (Can only be enabled when SNTP is selected in the Time Setting section.) Reboot Timing: Set the reboot interval, from 1 to 24 hours. 6.3.13 About Function Descriptions Display the firmware version, serial number, and other related information of the OIP Bridge For technical support, please scan the QR Code at the bottom right for assistance...

  • Page 23: Chapter 7 Troubleshooting

    Chapter 7 Troubleshooting This chapter describes problems you may encounter while using OIP Bridge. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurs, please contact your distributor or the service center. Problems Solutions OIP-N40E webpage USB extender...

  • Page 24: Chapter 8 Safety Instructions

    Chapter 8 Safety Instructions Always follow these safety instructions when setting up and using the product: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat. 1.2 Do not place the product on a tilted or unstable trolley, stand or table. 1.3 Please clean the dust on the power plug prior to usage.
  • Page 25  IC Warning This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled "Digital Apparatus," ICES-003 of Industry Canada. Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe B prescrites dans la norme sur le material brouilleur: "Appareils Numeriques,"...

  • Page 26: Copyright Information

    Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
